Minibeam LED Projector With Built-In Battery and Screen Share

  • PH550

Key Features

  • Triple Wireless Perfection
  • Bluetooth Sound Compatible
  • Go wireless. Phone to Projector
  • Built in Battery up to 2.5 hours
  • Enjoy cinematic 100inch class size
  • Light Weight and Slim Design

Triple Wireless Perfection

No messy cables anymore.
Just wireless phone mirroring, bluetooth sound, and portable battery.

Bluetooth Sound Compatible

Wirelessly stream sound directly from projector to Bluetooth compatible sound system such as home audio, headphone and portable speaker for a seamless listening experience.

Go wireless. Phone to Projector

Unlike conventional projectors, LG’s Screen share provides wire-free experiences when connect with PC, smartphones, or tablets.

Built in Battery up to 2.5 hours

Don’t worry about power connection.
Carry it anywhere like a mobile theater.

Enjoy cinematic 100inch class size

Minibeam gives you a cinematic viewing experience up-to an extra large 100 inch class size, so everyone in the room can enjoy the home theater experience.

Light Weight and Slim Design

Enable to carry anywhere easily.
Just take it in your brief case, small bag or pouch and enjoy.

Enjoy 100inch on-air TV anywhere

Be it the TV tuner, Minibeam is able to receive over-the-air TV signals to enjoy real-time sports games and TV show with up to 100 –inch class size.

Wired Smartphone Mirroring

Easy wired mirroring with smart devices of iOS/Android.

**compatible with slimport / MHL / AV adaptor

Simple USB Plug & Play

Just plug and play USB to watch movies, picture, music and office files like Presentation, Excel, and Word

Enjoy 3D at Once

Just Link your 3D glass and enjoy. Unlike other 3D projector, no need to buy additional program with extra-cost. Even more, it plays contents in USB directly.

30,000 Hours of Entertainment

The projector’s pure LED lamp displays natural and rich colors, and will last up to an estimated 30,000 hours. It means that the lamp does not have to be replaced for 10 years even if the projector is used 8 hours every day.

Projection System
Native Resolution HD(1280x720)
Brightness (Lumen, lm) 550
Contrast Ratio (Full On Full Off)100,000:1
Noise (High Brightness)Typ 30dB(A) ↓
Noise(Normal)Typ 24dB(A) ↓
Noise ( Economic)Typ 23dB(A) ↓
Uniformorty(JBMMA 9point)90% ↑
Projection Lens - FocusManual
Projection Lens - ZoomFixed
Projection Image (Screen Size)25" ~ 100"
Projection Image -(Standard)40"@1.24m
Projection Image (Throw Ratio)1.4
Projection Offset100%
Light source -TypeRGB LED
Light source -Life High Brightness30,000 Hrs
General Specification
Menu Language English/Spanish /French/Portuguese /Russian/Arabic/ Indonesian/ Persian
Aspect Ratio Control4:3/Just scan/Original/Full Wide/ 16:9/14:9/Zoom/Cinema Zoom
Sound 1W + 1W Stereo
BatteryBuilt-in type (up to 2.5H)
Net Size (mm) (W x D x H)174 x 109.5 x 44
Net Weight (kg or g)650g
Power Consumption (Max.) 60W
Stand-by Power0.5W ↓
Power SupplyAdapter
Operation Temp0 ~ 40℃
Input Signal Compatibility - RFDTV/ATV
Input Signal Compatibility - Digital(HDMI)1080p/1080i/720p/576p
Input Signal Compatibility RGBUp to WSXGA+(1680x1050@60Hz)
Input Signal Compatibility - Component Video1080p/1080i/720p/576p/576i
Input Signal Compatibility - Composite Video576i
Input/Output Terminals
RGB in1
RGB(PC) Audio in1
Composite(AV) in Phone to AV in
Composite(AV) Audio inPhone to AV in
Component (YPbPr)RGB to Component in
Component (YPbPr) Audio inRGB to Component in
Audio Out1 (Φ3.5)
HDMI1 (MHL)
USB1 (Type A)
RF IN1 (DVB-T only)
Main Features
3D 3D Optimizer
Digital Keystone CorrectionYes (Vertical)
Auto KeystoneYes (Vertical)
Picture Still Yes
Plug & Play(RGB, DVI/HDMI Input) Yes
Auto Source Detection (Auto Input Search)Yes
Quick(Instant) Power on/off Yes(on 10 Sec off 2 Sec)
Auto Sleep (Off)Yes
Sleep Timer Yes
BlankYes (Blue, Green)
Image FlipHorizontal/Vertical
Color Temperature AdjustmentYes
Black Level ControlYes
Expert controlvADJYes
Gamma CorrectionYes
Noise ReductionYes
Closed CaptionYes (Teletext, Subtitle)
Automatic Standby Yes
Added Features
USB Host (DivX, MP3, Photo) Yes (HD DivX)
File(Office) ViewerYes
DTV Tuner Yes (DVB-T2) (TBD)
Wireless Mirroring Screen Share
Wired Mirroring - MHLYes
Wired Mirroring - Apple Digital AV AdapterYes
Wired Mirroring - SlimportYes
Bluetooth Yes
Self Diagnosis Yes
Design
Cabinet ColorWhite
Local KeyJoystick
Kensington LockYes
Leg-StandYes
Accessory
Carry BagPouch
Manual (Full or Simple Book) (TBD)Quick Setup Guide
CD ManualYes
Warranty CardYes
3D Glasses- DLP Link Glasses (sold separately)
Tripod hole (for Tripod, Ceiling mount)Yes
Phone to AV (Composite)1
Adaptor1
Power cord1
Remote controlRemote (Card Type) + Battery
Conformances(Regulation)CE/CB
