DVD Home Theatre System

  • DH6631T

Key Features

  • 5.1 CHANNEL
  • 1000W
Bluetooth Compatibility

Bluetooth Compatibility

Stream music wirelessly from smart phones and tablets for a more versatile listening experience.

1080p upscaling

1080p upscaling

Upscales your standard definition DVD discs to near-Full HD quality when connected to an HDTV, breathing new life into your DVD collection.


Enjoy high quality entertainment. Enjoy LG Audio's karaoke function at anytime.

Portable in

Portable in

Simply plug in and play your mobile devices (MP3 player, mobile phone, etc) for convenient and flexible music sharing with the 3.5mm jack.



One remote, total control. You can easily manage your entire AV system with SIMPLINK, which uses control signals transmitted through an HDMI cable. SIMPLINK is compatible with all LG products.



With the LG Home Theater System, Micro and Mini Audio you can not only play files stored on USB devices, but record CD tracks or FM radio programs on your USB, while listening at the same time.

Physical - Size (W x H x D) mm
Main 360x60x316
Front Speaker 250X1150X250
Center Speaker 260x92x73
Rear Speaker 250X1150X250
Subwoofer 133x352x325
CH 5.1
Power Output - Total 1000W (Peak :1100W_LGEAF_only)
Power Output - Front L/R 167WX2 (Peak : 184WX2 )
Power Output - Center 167W (Peak : 184W)
Power Output - Surround L/R 167WX2 (Peak : 184WX2 )
Power Output - Sub-Woofer 167W(Passive) (Peak : 184W)
Design (Mainset)
Front & Rear cabinet (tray) Yes
Home Menu
Home Menu Yes
In & Out Front
Display FLD
Audio In - Portable In Yes
In & Out R/Panel
Video Out - Composite Yes
Audio Input - Audio L/R Yes
Audio Input - Optical 1
HDMI - Out 1
Radio Antenna - FM Yes
Speaker Terminal - Composing of channel 5.1
Speaker Terminal - Terminal Type Push in (Spring)
Simplink Yes
Speaker Level Trim Yes
Speaker Distance (channel delay) Yes
Test Tone Yes
Mute Yes
A/V Sync Delay(Audio Delay) Yes
Dimmer Yes
Sleep Yes
Volume on TV Yes
USB direct recording Yes
TV Sound (direct key) / TV Sound connect (Auto PWR on/off by optical) Yes
Dynamic Range Control On/Off Yes
Bluetooth (Rx / Tx) Yes / Yes
Karaoke - Mic Volume / Echo Volume Yes
Karaoke - Fanfare Yes
Karaoke - Scoring Yes
Karaoke - Howlling Canceller Yes
DISC & AV Format
Playable Disc Type - DVD(NTSC) Yes
Playable Disc Type - DVD(PAL) Yes
Playable Disc Type - DVD-R Yes
Playable Disc Type - DVD-RW(Video) Yes
Playable Disc Type - DVD+R Yes / Yes
Playable Disc Type - DVD+RW(Video mode) Yes
Playable Disc Type - Video CD/Super VCD Yes / Yes
Playable Disc Type - Audio CD Yes
Playable Disc Type - CD-R/CD-RW Yes
Video Format - MPEG2 Yes
Video Format - DivX Yes
Audio Format - LPCM LPCM
Audio Format - Dolby Digital Yes
Audio Format - MPEG 1/2 L2 Yes
Audio Format - MP3/ID3 Tag Yes
Audio Format - WMA Yes
Graphics/Subtitle Format 2bit/ 8bit Sub-picture / Text-based Subtitle
GUI/ Menu Option
Video DAC 148MHZ/12bit
NTSC/PAL Hz 60Hz / 50Hz
Resolution upto 1080p24/60Hz
VBI - WSS/CGMS-A/Closed Caption/Macrovsion Yes
NTSC⇔PAL Conversion Yes
Last Scene memory Yes
Disc (BD, DVD, CD) Playback Specification
Screen Saver Yes
Power Resume Yes
Parental Lock Yes
DVD - 1080p Upscaling Yes
Trick Play - Fast Forward Yes
Trick Play - Fast Back Yes
Trick Play - Forword Slow Yes
Trick Play - Reverse Slow Yes
Trick Play - Pause Yes
Trick Play - Forward Step Yes
Search - Title/Track Yes
Search - Chapter Yes
Search - Time Yes
Repeat Play - Title/Track Yes
Repeat Play - Chapter Yes
Resume Stop Yes
Play Mode - Random Yes
Marker Play Yes
Power Off Consumption 0.18
Power Consumption 100
Tuner Type PLL
Tuning Up/Down Yes
Preset Up/Down Yes
Band(FM) Yes
Preset Memory 50 Station
Front - Model Name S63T2-S
Front - SPL 81.5dB
Front - System Closed type
Front - Woofer Unit 3" Yellow Paper
Front - Impedance
Front - Magnetic Shielding Perfect-Shield
Rear - Model Name S63T2-S
Rear - SPL 81.5dB
Rear - System Closed Type
Rear - Woofer Unit 3" Yellow Paper
Rear - Impedance
Rear - Magnetic Shielding Shielded Type
Center - Model Name S63S2-C
Center - SPL 79.0dB
Center - System Closed type
Center - Woofer Unit 3" Yellow Paper
Center - Impedance
Center - Magnetic Shielding Shielded Type
Subwoofer - Model Name S63T4-W
Subwoofer - SPL 83dB
Subwoofer - System Bass Reflex
Subwoofer - Woofer Unit 7" Cone
Subwoofer - Impedance
Subwooder - Magnetic Shielding Non-Shield
Feature List - Accessory Kit
Instruction Manual Printing Book
Simple Manual Yes
Remote Control Unit - Type CB1
Remote Control Unit - Unified Yes
Remote Control Unit - Battery(Size) AAA*1
Batteries (Remote Controller) Yes
FM Antenna Yes
Speaker Cable Yes (6 EA)
Warranty Card Yes
RCA Code(Video), Yellow, 1P Yes
HDMI Cable Yes
Carton Box Type(Tip on, Offset, Flexo) Tip on
