LG’s highly efficient advanced inverter V technology

  • US-Q246C4A4

  • Discontinued Product

Key Features

  • INVERTER V technology
  • Low Noise 19dB
  • Anti Bacterial Air Filter
  • Jet Cool
  • Fresh Dry
Capacity
Cooling 3700 ~ 22000 ~ 24000 Btu/h
Elec. Rating
Power Supply 1Φ, 220~240V, 50Hz
Power Supply Cable 3 x 1.5 No.*㎟
Power and Transmission Cable 4 x 0.75 No.*㎟+No.*㎟ (Including Earth)
Power Input (Cooling) 2010 W
Running Current (Cooling) 9.5 A
Starting Current (Cooling) 9.5 A
EER 3.21 W/W
Circuit Breaker 20 A
RPM (Cooling) 1650Po/1400H/1200M/1000L/850S-Low
Air Flow Rate
Indoor,Max 19.5(689) ㎥/min(CFM)
Outdoor,Max 50.0(1,766) ㎥/min(CFM)
Special Function
Moisture Removal 1.9 Kg/h
Refrigerant & Charge(at 5m) R410A, 1,410 g
Additional Refrigerant Charge 30 g/m
Sound Level
Indoor,H/M/L/SL 45 / 40 / 35 / 29 dB(A)+1
Outdoor,Max 53 dB(A)+1
Compressor
Type Twin Rotary
Model GKT176MF
Motor Type Brushless DC Motor
Oil Type POE
Oil Charge 470 cc
Condenser
Tube Type Cu Cond
FPI 18 FPI
Raw × Column 2 × 28
Fan(Indoor)
Type Cross Flow Fan
Motor Type BLDC
Motor Output 30 W
Fan(Outdoor)
Type Propeller, Fan
Motor Type BLDC
Motor Output 85 W
Piping Connections
Liquid Side 6.35(1/4) mm(in)
Gas Side 15.88(5/8) mm(in)
Max. Piping Length 20(65.6) m(ft)
Max. Elevation Difference 10(32.8) m(ft)
Drain Hose
O.D , I.D 21.5,16.0(0.85,0.63) mm(in)
Dimensions
Indoor (W*H*D) 1030*325*250 mm
40.6*12.8*9.84 inch
Pack Indoor (W*H*D) 1095*394*302 mm
43.1*15.5*11.9 inch
Outdoor (W*H*D) 870*655*320 mm
34.3*25.8*12.6 inch
Pack Outdoor (W*H*D) 1002*696*422 mm
39.4*27.4*16.6 inch
Net Weight
Indoor 12.6(27.8) kg(lbs)
Outdoor 42.5(93.7) kg(lbs)
Set Weight
Indoor 15(33.1) kg(lbs)
Outdoor 46.2(101.9) kg(lbs)
Operation Range
Cooling (Indoor) 18 ~ 32 (64.4 ~ 89.6) ℃(℉)
Cooling (Outdoor) 18 ~ 48 (64.4 ~ 118.4) ℃(℉)
Tool Code(Chassis)
Indoor + Outdoor SC + UE
