32" class (31.51" diagonal) with Integrated Pro:Idiom

  • 32LY560M

Key Features

  • HOSPITAL SAFETY STANDARD COMPLIANT
  • CONVENIENT FOR PATIENTS AND HOSPITAL STAFF
  • EASY MANAGEMENT

HOSPITAL SAFETY STANDARD COMPLIANT

HOSPITAL SAFETY STANDARD COMPLIANT
CONVENIENT FOR PATIENTS AND HOSPITAL STAFF

CONVENIENT FOR PATIENTS AND HOSPITAL STAFF

EASY MANAGEMENT

EASY MANAGEMENT
Reduced Total Cost of Ownership

Reduced Total Cost of Ownership

Using LG's optional Pro:Centric server, you can remotely manage cloning and channel mapping for TVs in patient rooms without having to visit each room. EzManager’s auto configuration function makes installation quick and easy. EzManager guides the installer to set up the TV with simple steps without having to set up the menu manually, saving time and cost.

Effectively Manage Patient Room TVs

The USB Cloning feature allows you to simply copy the TV settings onto all TVs using a USB stick, a process that is fully automated to save time without having to set each TV one by one.

Effectively Manage Patient Room TVs
Pro:Centric Applications Platform

Pro:Centric Applications Platform

Interactive Patient Room Experience An industry leading television that supports the Pro:Centric platform, LG’s new LY560M allows healthcare facilities to customize the patient room experience. Pro:Centric provides an easy way for the LY560M to interface with interactive program guides, games and internet data feeds, as well as applications designed to connect patients to services such as dietary menus and patient room information.

The LY560M Pro:Centric Applications Platform

The LY560M Pro:Centric Applications Platform
Free-To-Guest Remote Management Devices

Free-To-Guest Remote Management Devices

Remote management functions also supported via the Pro:Centric server. The Pro:Centric Application software can be remotely added at a later date to deliver the benefits of LG’s Applications features (Weather, EPG, Billboards...)

LG's Free-To-Guest Cost Effective Solution

When using LG televisions in Free-To-Guest hospital installations there are now two options for remote management of TV settings such as virtual channel mapping, cloning of installer menu settings, and other settings: 1. LG's Pro:Centric server (PCS150R) Both remote management options avoid having to visit rooms to change television settings, thereby saving labor charges to carry out this work.

LG's <span>Free-To-Guest</span> Cost Effective Solution
MHL (Mobile High- Definition Link)

MHL (Mobile High- Definition Link)

MHL connects smart phones to the TV instantly, mirroring content in HD quality, just like connecting a PC through an HD cable. Moreover, it allows you to control the phone’s content on the TV with a remote control.

Clone using a USB Memory Device

The Installer sets up a master TV with the preferred menu settings. A USB memory device is plugged into the master TV. Menu items are selected to "Learn From TV" and stored on the USB memory device. The USB stick is then plugged into a target TV. Menu items are selected to "Teach To TV". The USB device is then unplugged and is ready to engage with the next target TV.

Clone using a USB Memory Device
<span>energy guide for 32LY560M</span>

energy guide for 32LY560M

The estimated annual energy cost determined in accordance with 16 CFR Part 305.5 for model 32LY560M is $6. “Your energy cost depends on your utility rates and use. The estimated cost is based on 11 cents per kWh and 5 hours of use per day. For more information, visit www.ftc.gov/energy.”1 1FTC Television labeling rule (18 CFR Part 305, as added by 76 Fed. Reg. 1038 (Jan 6, 2011)).

Pro:Idiom Global Leading Digital Rights Management System

Pro:Idiom unlocks access to premium content to help assure rapid and broad deployment of HDTV and other high value digital content. Pro:Idiom has been designed specifically for users of premium HDTV content from cable, satellite, or video on demand (VOD) services, and is thus designed to lower costs and reduce maintenance needs. This leading DRM system is embraced for its security solution, which prevents illegal copying of copyrighted content.

Cloning Option

The LY560M Healthcare TV has a convenient time and expense saver feature. A select number of Commercial menu items are cloning capable. This allows the cloning of a master TV to all other TVs of the same model. This can be easily accomplished by using a standard USB memory device. This time saving technique will allow the installers to program the preferred commercial settings from a master TV to all the required target televisions in a hospital facility in a matter of just a few minutes per TV.

PANEL
Panel TechnologyDirect LED
Panel Size (Measured Diagonally)32” Class (31.51”)
Native Resolution1366 x 768 (HD)
Frame Rate60Hz
Response Time9ms
Viewing Angle(HxV)178° x 178°
BROADCASTING SYSTEM
AnalogYes (NTSC)
DigitalYes (ATSC /QAM/VSB)
AUDIO
Audio Output10W + 10W
Sound ModeYes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
Sound System2.0 ch
Virtual SurroundYes
Sound OptimizerYes (3 Modes: Normal, Wall-Mount Type, Stand Type)
INTERFACE (Side)
HDMI In1 Side
USB (2.0)1 Side
AV In1 (22", 28" Only)
INTERFACE (Rear)
RF In1 Rear
Pillow Speaker Interface1 Rear
AV In1 (32", 42" Only)
Digital Audio Out1 Rear (Optical)
RGB In (D-sub 15pin)1 Rear
PC Audio Input1 (Sharing with AV In)
HDMI In1 Rear
LAN (RJ45)1 Rear (Service Only)
MPI Port (RJ12)1 Rear
External Speaker Out (3.5mm phone jack)1 Rear (3.5mm phone jack)
PTC Configuration (phone jack type)1 Rear
CABINET
Bezel Width (on/off) (mm)11.6mm/10.5mm
Depth (mm)55.5mm
Without Stand28.8” x 17.2” x 2.2”
Weight (Without Stand)13.2 lbs
Carton32.1” x 20.1” x 6.0”
Weight (Carton)15.9 lbs
VESA™ Standard Mount Interface200mm x 200mm
ColorTitan Metallic
Flame RetardantYes (Back Cover only)
SPECIAL FEATURES
HDMI-CECYes
HTNG-CECYes
DRMYes (Pro:Idiom)
Welcome ScreenYes
Lock ModeYes
Logical Channel MapYes
RF(1/2Tuner)Yes, RF (1Tuner)
Pro:Centric ApplicationYes
MHLYes
Self DiagnosticYes
Installer MenuYes
HCAP (GEM/FLASH/HTML)Yes (GEM/Flash)
EzManagerYes
Pro:CentricYes (Single Tuner)
Multi IR CodeYes
IR OutYes (MPI only)
Kensington LockYes
External Speaker OutYes
USB CloningYes
VIDEO
Picture ModeYes (6 Modes: Vivid, Standard, Eco, Cinema, Sport, Game)
Triple XD EngineYes
Aspect RatioYes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
POWER
Stand-by< 0.3W
Watts (typical)23.8W
Power SourceAC 120V ~ 50/60H
Power Cord Length1.87mm
WARRANTY
WARRANTY2-Year Limited Warranty (Parts/Labor)
REQUIRED LISTINGS
SafetycUL, UL, FCC, NOM
RoHSYes
Energy Star 6.1Yes
UPC
32LY560M7 19192 91606 7
