43” Class (42.7” diagonal) Edge-lit LED IPTV with Integrated Pro:Idiom® and b-LANtm

  • 43LX774H

Key Features

  • Pro:Centric® SMART
  • Integrated Pro:Idiom® DRM Technology
  • webOS & Media Share Features
  • Commercial Swivel Stand

Pro:Centric® SMART

The LX774H is the latest in the line of Pro:Centric TVs that provide a unique and dedicated hotel applications hosting platform for LG's system integrators' interactive applications, enabling delivery for a wide range of custom applications tailored to both hotel management and guests' needs. LG Pro:Centric SMART offers extended customizable tools: HTML5, Java and Flash. Using these tools, partners can optimize the TVs by editing and developing their own enhanced service design to increase the visual impact on guests.

Pro:Idiom®

GLOBAL LEADING DIGITAL RIGHTS MANAGEMENT (DRM) SOLUTION

Pro:Idiom unlocks access to premium content to help ensure rapid and broad deployment of HDTV and other high value digital content. Pro:Idiom has been designed specifically for users of premium HDTV content from cable, satellite, or video on demand (VOD) services, and is intended to lower costs and reduce maintenance. This leading DRM system is embraced for its security solution, prevents illegal copying of copyrighted content.

Smart Share

LG Smart Share ® allows guests to use the TV to access and view data shared either by wired DLNA Certified ® devices connected to the same LAN as the TV or by wireless LG devices using LG’s Smart Share application with Wi-Fi Direct ®.

Screen Share

Screen Share enables screen sharing with a Miracast ® or Wireless Display (WiDi) capable device (e.g., a laptop with Intel ® hardware).

Bluetooth Sound Sync (Bluetooth 3.0)

Bluetooth Sound Sync allows guests to listen to audio from a Bluetooth-enabled mobile device through the TV’s speakers.

* Support devices for Bluetooth Sound Sync : Android (above v4.4 KitKat) / iOS based Mobile Device

SoftAP

SoftAP enables the TV to function as a 2.4 GHz wireless access point for up to five devices.

DIAL

DIAL (Discovery and Launch) allows guests to play selected application media on the TV from a device with DIAL capability. The device may be used to cast any application for which a TV-compatible application has been created/selected.

Pre-loaded Apps

Guests can be served with bandwidth-worry-free pre-loaded applications, including Accuweather, Crackle, HULU, Web Browser, and YouTube (other applications may be added in the future, subject to licensing terms).

DISPLAY
Diagonal Size42.8"
TypeEdge LED
Resolution1,920 x 1,080 (FHD)
Dynamic Contrast Ratio1,000,000:1
Static Contrast Ratio1,200:1
Viewing Angle Degree178°/178°
Response Time (G to G)8m/s
Frame Rate60 Hz
BROADCASTING SYSTEM
AnalogNTSC
DigitalATSC / VSB / Clear QAM
MPEG-2 / MPEG-4 H.264 DECODINGYes
VIDEO
Triple XD EngineYes
Real Cinema 24p (3:3 Pulldown)Yes
Dynamic Color EnhancerYes
Aspect RatioYes 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)
AUDIO
Audio Output / Speaker System10W + 10W / 2.0 ch
Sound ModeYes 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
Optical Sound SyncYes
Wireless Sound SyncYes
GENERAL FEATURES
Pro:Centric ® TypePro:Centric Smart
Pro:Centric ® Hybrid Streaming (IP&RF)Yes
Pro:Centric ® ApplicationYes
Pro:Centric ® RF2 Tuner
Pro:Centric ® HCAP (SDK)GEM / Flash / HTML
Smart FeaturesSmart Share, DLNA, WiDi, Miracast, Wi-Fi Direct, DIAL, Bluetooth Sound Sync., SoftAP, Web Browser, Magic Remote (Optional), Supported Wi-Fi Standards (802.11a/b/g/n/ac)
ManagementRemote Diagnostics / EZ-Manager Wizard (for Auto Configuration)
InteractivityHTNG / HDMI-CEC
Digital Rights ManagementPro:Idiom
RJP CompatibilityYes
USB MediaMoving Picture Playback (MPEG), Picture (JPEG), Audio Codec (AC3, EAC3, AAC, Mpeg, MP3, PCM)
Advanced Setting OptionAuto Off / Auto Sleep, Smart Energy Saving, Motion Eye Care
Anti-theft SystemKensington Lock, Credenza/Security Screw Hole, Lock Down Plate, Commercial Grade Stand
COMMERCIAL FEATURES
YesWelcome Screen (Splash Screen), FTG Mode, Instant On, IR Out, External Speaker Out, Public Display Mode, USB Cloning, Logical Channel Map, Multi-IR Code
INTERFACE
SideHDMI In (2), USB 2.0
RearRF In, AV In (Sharing with AV In), Component Audio In, Optical Digital Audio Out, HDMI Input (2), USB 2.0, PC Audio Input (Sharing with Component Audio In), LAN Port (2), RJ45, External Speaker Out, TV Link Configuration, PTC Configuration, MPI Port
ACCESSORIES
YesPower Cable (5.9 ft.), Owner’s Manual / Easy Setup Guide
DIMENSIONS
Bezel Width (L/R, U, B) : on bezel based14.9, 12.5, 17.6 (mm)
Bezel Width (L/R, U, B) : off bezel based12.6, 10.2, 15.3 (mm)
Vesa (mm)200 x 200
WxHxD / weight (w/o stand)38.3" x 22.3" x 2.2" / 22.5lbs
WxHxD / weight (with stand)38.3" x 24.6" x 12.8" / 30.0lbs
WxHxD / weight (Carton)41.3" x 25.8" x 5.6" / 35.1lbs
Stand(±20/45/90°) Swivel
POWER
Voltage Hz100 ~ 240V, 50/60Hz
Typical (Watts)56.3
Stand-by (Watts)< 0.5
STANDARD APPROVAL
SafetyUL
EnvironmentFCC
Etc.RoHS, UL, NOM
UPC
43LX774H719192919709
