20" class (19.5"/494.03mm diagonal) Zero Client TERA2

  • 20CAV37K-B

Key Features

  • Our V series Zero Clients utilize a Teradici® TERA 2 Chipset, Amazon WorkSpaces, and Vmware; to deliver a powerful, secure, virtual computing solution; while reducing system building including maintenance costs as well. LED backlight technology, also provides a bright and clear display to facilitate a comfortable computing experience for daily office work and multimedia applications.

AWARD OF EXCELLENCE WINNER

Tech & Learning magazine has awarded our product as New Product Winner in its prestigious 31-year-old recognition program. Every year it honors innovative applications that break new ground as well as those that added significant enhancements to proven education tools.

<span>AWARD OF EXCELLENCE WINNER</span>

HIGH PERFORMANCE VIRTUAL COMPUTING

LG’s 19CNV42K-B, 23CAV42K-BL and CBV42-B utilize a Teradici® TERA 2 Chipset and VMware to deliver a powerful and secure virtual computing solution. Compared to a traditional desktop computing system, the V series allows advanced computing with greater security while reducing system building and maintenance costs. LED backlight technology also provides a bright and clear display to facilitate a comfortable computing experience for daily office work and multimedia applications. The LG Cloud Monitor (Zero Client) combined with a Teradici PCoIP Processor and VMware Software result in an innovative ‘PCoIP Virtual Computing’ solution.

Case Study: Corona Norco Unified School District

Corona Norco Unified School District selected LG zero client displays that not only provide quality products that met its budget requirements, but also provide additional technology support and contribute to overall energy savings across the district. With Teradici, the monitors have centralized computing that makes the routine management of student labs and courseware easier to maintain.

<span>Case Study: Corona Norco Unified School District</span>
PANEL
Size (Inch)20" (19.5”)
Panel TypeAH-IPS
Color Depth (DFC)16.7M
Pixel Pitch (mm)0.2907(H)x0.2915(V)
Resolution1440 x 900
Brightness (Typical)250 cd/m2
Contrast Ratio1,000:1(Typ) 5,000,000:1(DFC)
Response Time (on/off)14ms (GTG)
Viewing Angle (CR≥10)178°/178°
Aspect Ratio16:10
Surface TreatmentNon-Glare
SYSTEM
ProcessorTeradici Tera2321 PCoIP Chip
Memory512MB
ProtocolPCoIP
Networking10/100/1000 Ethernet
SIGNAL (INPUTS / OUTPUTS)
D-Sub (in)Yes
DVI (out)Yes (Span)
USBYes (2.0, 6 ea) * 4 Back, 2 Front
Mic InYes
Headphone OutYes
EthernetYes (10 / 100 / 1000)
SPEAKER
Built-in SpeakerYes (5W x 2)
POWER
TypeAdapter (19V DC)
Input100 ~240 , 50/60Hz
Normal On (Typ)18W (Monitor), 22W (PCoIP)
Power Save/Sleep Mode (Max)0.5W (Monitor), 5.5W (PCoIP)
DC Off (Max)0.5W
UPoE ReadyYes (via AUPoE Adapter) * AUPoE sold separately
STAND
PivotYes (90°)
VESA Mount™100mm x 100mm
Base DetachableYes
Swivel (Angle)±180°
Tilt (Angle)'-5°(front) / 35°(rear)
Height (Range)130mm
CABINET
W x D x H (With Stand)17.9 x 10.2 x 14.6 (inch)
W x D x H (Without Stand)17.9 x 2 x 11.8 (inch)
Box (WxHxD)20.6 x 7.9 x 11.8 (inch)
Weight (with Stand)9.3 lbs.
Weight (Without Stand)7.9 lbs.
Box Weight12.4 lbs.
VESA100 x 100 (mm)
CERTIFICATION
UL(cUL)Yes
TUV-TypeYes
FCC-B, CEYes
RoHSYes
STANDARD CERTIFICATION
UL(cUL)Yes
TUV-TypeYes
FCC-B, CEYes
RoHSYes
ACCESSORIES
D-Sub CableYes
Power CordYes
OTHERS
Warranty3-Year Limited Warranty
TAA CompliantYes
UPC7 19192 20071 5
