2.2 cu.ft. Over-the-Range Microwave Oven

  • LMH2235ST

Key Features

  • ExtendaVent™ 2.0
  • EasyClean®
  • 2.2 Cu.ft oven capacity
  • QuietPower™ Ventilation System
Catch The Smoke

Catch The Smoke

Reduce smoke and lingering cooking smells with LG’s enhanced ExtendaVent™ 2.0. Where most over-the-range microwaves only cover the rear of the cooktop, ExtendaVent™ 2.0 provides powerful ventilation over virtually the entire cooktop, back to front. That’s what we call clearing the air.



With the new EasyClean® interior, you can have quick and high performance cleaning inside and out without using chemicals.

Largest Capacity*

Largest Capacity*

With largest capacity at 2.2. cu.ft., there's always plenty of room to heat large items.

*Based on manufacturers’ published specifications of over-the-range microwaves as of December, 2013.

QuietPower™ Ventilation System

QuietPower™ Ventilation System

With an Over-the-Range Microwave Oven, strong ventilation is key. That’s why LG has created the QuietPower vent, which does the job quietly, without interrupting your life.

Senses Optimal Temperature for Fast Results

Senses Optimal Temperature for Fast Results

Sensor Cooking technology senses humidity levels within the oven and automatically adjusts cooking time and performance to help provide optimal heating performance.

Oven Capacity 2.2 cu. ft.
Watts 1,000
Exterior Design WideView™ Traditional
Control Type SmoothTouch™ Glass Controls
Display White, VFD Scrolling, 2 Line
Sensor Cook Options 8
Power Levels 10
Defrost Auto, Time and Rapid Defrost
Reheat Sensor Reheat
Popcorn Key Yes
EZ-On Yes
More/Less Yes
Melt/Soften Yes
Custom Set Yes
EasyClean™ Yes
Energy Savings Key Yes
Bi-Level Cooking Rack Yes
Turntable Type DDS
Turntable Diameter 14.2"
Turntable On/Off Yes
Clock Yes
Kitchen Timer Yes
Completion Beeper Yes
Lighting LED
Child Lock Yes
Filtration Charcoal Filter
Vent Grill Type Hidden
Vent Air Flow (CFM) 400
Power Levels 4 (Hi/Mid/Low/Off)
Available Colors Stainless Steel (ST)
Interior Color Gray
Interior (WxHxD) 22" x 11 5/8" x 14 5/8"
Exterior (WxHxD) 29 7/8" x 17 15/16" x 15 7/8"
Shipping Qty. 288 sets / 40ft.
Shipping (WxHxD) 33 1/2" x 20 3/4" x 20 1/2"
Net Weight (lbs) 73.5 lbs
Shipping Weight (lbs) 78 lbs
Limited Warranty 1 Year Parts and Labor (In Home Service) 10 Years Limited on Magnetron (In Home Service)
UPC 048231 319003

What People Are Saying

Rated 1 out of 5 by from Did not last not even 10 months Just stopped heating the food in less than 10 months.
Date published: 2016-04-26
Rated 5 out of 5 by from Great Microwave Love this Microwave! Has all of the bells and whistles we wanted and use.
Date published: 2016-04-17
Rated 1 out of 5 by from IT IS NOT QUITE VENT I purchase friday and it is installed today. first thing i checked for the vent sound. after searching last two weeks for the quietist one. it is horrible worst than my old one. please don't advertise for this reason. I am so disappointed if i did not purchase the matching appliances i was going to return this. also you cannot see inside how stupid it is. so unhappy
Date published: 2016-02-10
Rated 4 out of 5 by from Nice controls but dark interior I like the 2235 because of the glass touch panel, LED stovetop light and extend-a-vent. I dislike it because of the small and dark viewing window and the dark interior. It's important to be able to see the food cooking. On a different note, why can't microwaves have true power rather than cycling the magnetron on and off at full-power? It would provide much gentler heating than zapping it at full power every few seconds.
Date published: 2016-02-04
Rated 5 out of 5 by from Love the features! I have had this microwave for a couple of months and love all the features. I am retired and home most of the day so it gets lots of use. It's styling and features are outstanding, and so far I had no problems.
Date published: 2016-01-27
Rated 4 out of 5 by from Nice looking appliance Purchased this model for it's extend a vent feature. Of course once installed it was the one thing that didn't work. After 2 service visits it is working. The latch that holds the vent in the closed position broke and although I specifically told the service people the problem they sent the service man without any parts. Therefore 2 visits were needed. Hope it holds up now that it is repaired. The microwave is very spacious inside. however it makes more noise than my old GE did.
Date published: 2016-01-20
Rated 5 out of 5 by from Best in Class! I can't say enough positive things about this microwave. We have had it for about three months now and use it daily. Not only does it cook food accurately and evenly, it is extremely quiet! It's high capacity sets it apart from others in its class. Another unique feature is the extended pop-out vent that allows more cooking fumes to be extracted from the air. The front of the microwave is also very easy to clean, as advertised. I highly recommend this microwave to anyone!
Date published: 2015-11-02
Date published: 2015-09-14
  • 2016-05-24T13:41CST
  • bvseo_cps, prod_bvrr, vn_cps_3.2.1
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_33
  • loc_en_US, sid_MD05122420, PRD, sort_mostRecent
  • clientName_LG
  • bvseo_sdk, java_sdk, bvseo-
  • CLOUD, getReviews, 4ms

We're here to support you with our product.

View LMH2235ST Product Support

Contact us for any support inquiries.


Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

purchased LMH2235ST over the range microwave what is the recommended distance for the gap from microwave to stove

Asked by: jv3002
We appreciate your interest in this microwave oven. While there is no listed distance between the bottom of the microwave and the oven, the required gap between the overhead cabinet, to which the microwave mounts, must be 30” above the surface of the range. This will allow for sufficient spacing for the microwave oven.
Answered by: NeilE
Date published: 2015-09-12

our upper cabinet depth is 15". What microwave will allow venting out of the front rather than the top?

We recently purchased Model:LMV2031 and the maximum upper cabinet depth is 13" to allow for top room venting. Do you have other models that will room vent when the upper cabinet depth is 15"?
Asked by: PapaW
We appreciate your interest in these LG microwave ovens. It appears that all of our current microwave models are designed to provide room venting, blowing upward, and yet are slightly under the 15” depth
Answered by: NeilE
Date published: 2015-10-12

Where to find install instructions

I just purchased a home and bought this microwave. Have not moved in yet and would like to know how to install this. Does it mount to the wall?If so I would like to open the wall and install blocks of wood to mount it,and patch and paint the wall.before I move in.
Asked by: Pipeslinger
It comes with a wall bracket for stabiltiy, but the weight is carried by screws that hold it up from the top. You'd better plan on a cabinet of some sort over the microwave. Mounting instructions are included.
Answered by: Zeddy
Date published: 2015-04-19

External ventilation connection option on this microwave

Can this microwave be connected to already existing external ventilation connection or does it only recirculate the vent air? Are there other OTR 30" microwaves that do external vent if this one does not?
Asked by: bmcole1
Yes, it will work with external vent. Exactly fit my existing pipe, so it's probably "standard".
Answered by: Zeddy
Date published: 2015-02-24

External ventilation option?

Does this microwave offer an optional external vent through the top? If so, what size vent does it use. It would be nice if the installation instructions were online so that questions such as these would be easily answered.
Asked by: MaLum
Yes, it will vent externally. The fitting is included with the oven. Mine's already installed so I can't measure it, but it exactly fit the vent pipe I had from the last microwave oven. Hope this helps.
Answered by: Zeddy
Date published: 2015-02-24

I'm trying to find recommended clearances on this micro. trying to order cabinetry for above it.

the install manual won't come up, and I'm trying to find out how far off the floor to the bottom of micro do you recommeng?
Asked by: bonn
The minimum clearance is 30" from the bottom of the cabinet to the cooking surface or countertop. Please see attached - page 3 of Installation Manual.
Answered by: My2Cents
Date published: 2015-05-23

I recently purchased this microwave as part of a total kitchen remodel. We put in a gas range under the microwave.

What clearance should I have from the stove top to the bottom of the microwave. The range is also LG with 5 burners.
Asked by: JayBKitchen
Minimum clearance is 30" from the bottom of the cabinet to the cooking surface or countertop. This measurement is the same for gas or electric. This will leave approximately 17" between your cooking surface and the bottom of the MW with the slide out exhaust included in this measurement (19" without the exhaust installed). If additional data is required please contact LG Support for installation documentation.
Answered by: My2Cents
Date published: 2015-12-01

vent extender on new microwave will not click in to close

Asked by: alamojoe
We regret the trouble you have experienced with this microwave oven accessory. If the latch is not operating properly, then the unit will likely require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at
Answered by: NeilE
Date published: 2015-02-09
