Key Features
- 24 cu. ft. Capacity
- Multi-Air Flow Freshness System
- Swing Door Freezer
- Sophisticated Style & Design
AVAILABLE COLORS:
24 cu. ft. Large Capacity Swing Door Bottom Freezer Refrigerator
$1499.99
Suggested Price
Largest Capacity.*
Get the space you need in a refrigerator that's right for your kitchen. With 24 cu. ft. of space, this largest capacity bottom mount refrigerator offers ample room to meet your storage needs.
Convenient Access.
Having the fresh food section above the freezer, bottom freezer refrigerators put the food you use at eye level. The Swing Door freezer is well designed with maximum space efficiency and easy roll-out drawers.
Fresher is better.
Multi-Air Flow Freshness System is designed to maintain superior humidity and temperature levels to help keep your food fresher, longer. Digital sensors constantly monitor conditions within the refrigerator and strategically-placed vents in every section to help surround your food with cool air no matter where you put it.Fresher is better.
Adaptable and Easy Access Storage.
Full width door shelving is designed to easily accommodate items of different shapes and sizes to allow for more fresh food space. Adjustable door drawers fold-in to create more vertical storage space and accommodate tall food items.
Great Light.
LED panels in the refrigerator provide an exceptionally bright interior and saves energy over traditional lighting.
Follow the tips below to make sure your LG product will fit in the space intended.
Download Measure First
| Door Type | Bottom Freezer |
|---|---|
| Total Capacity | 24.1 cu. ft. |
| Size (W x H x D) | 32 3/4" x 69 7/8" x 34 7/8" |
| Color | Stainless Steel |
| Refrigerator | 16.40 cu. ft. |
|---|---|
| Freezer | 7.70 cu. ft. |
| Total | 24.1 cu. ft. |
| Energy Rating | ENERGY STAR® Qualified |
|---|---|
| Ice System | Factory Installed Ice Maker |
| Daily Ice Production | 2.0 lbs |
| Ice Storage Capacity | 4.0 lbs |
| Smart Cooling® System | Yes |
| Multi-Air Flow Cooling | Yes |
| Temperature Sensors | 6 |
| Linear Compressor | Yes |
| Display Type | Membrane (Green LED) |
| Hidden Hinges | Yes |
| Temperature Controls | Electronic/Digital |
| Door Alarm | Yes |
| Child Lock | Yes |
| LoDecibel™ Quiet Operation | Yes |
| SmartDiagnosis™ | Yes |
| No. of Shelves | 1 Full / 2 Split |
|---|---|
| Folding Shelf | Yes |
| Cantilevered Shelves | Yes |
| Shelf Construction | Hybrid Cantilevered Shelving |
| Crisper Bins | 2 Humidity Crispers |
| Glide N’ Serve® | Yes |
| Refrigerator Light | Premium LED |
| No. of Shelves/Bin | 5 Total (3 Full, 1 Flip-Up + Dairy) |
|---|---|
| Door Bin Construction | Clear |
| Dairy Corner | Yes |
| Drawers | 2 |
|---|---|
| Handle | Smart Pull® Freezer Handle |
| Ice Bin | Yes |
| Freezer Light | Premium LED |
| Contour Door | Yes |
|---|---|
| Hidden Hinges | Yes |
| Surface | Coated Metal, Stainless Steel |
| Back | Flush & Metal Cover Over Mechanical Parts |
| Available Colors | Smooth White, Stainless Steel |
| Handles | Matching Commercial Handles |
| Depth with Handles | 34 7/8" |
|---|---|
| Depth without Handles | 33" |
| Depth without Door | 29" |
| Depth (Total with Door Open) | 62 3/4" |
| Height to Top of Case | 68 5/8" |
| Height to Top of Door Hinge | 69 7/8" |
| Width | 32 3/4" |
| Door Edge Clearance with Handle | 4 1/4" |
| Door Edge Clearance without Handle | 2" |
| Installation Clearance | Sides 1/8", Top 1", Back 1" |
| Weight (Unit/Carton) | 249 lbs. / 271 lbs. |
| Carton Dimensions (WxHxD) | 34 3/8" x 70 1/2" x 36 6/8" |
| Limited Warranty | 1 Year Parts and Labor, 7 Years on the Sealed System, 10 Years on Linear Compressor |
|---|---|
| UPC | 048231 785983 |
What People Are Saying
Rated 5 out of
5 by
Norman 1130 from
Great Unit. Very accessible to everything in the refrigerator without straining or bending to find it. Very large items fit in the door. Just the best functional unit we have ever had.
Date published: 2016-01-23
Rated 3 out of
5 by
euonymous from
Very nice, but...
We bought this refrigerator nearly a year ago and have been happy with it. If you leave the door open for a few seconds it has an annoying chime to let you know, but that is probably a good thing. In the last month we have started to experience a very loud grinding noise which lasts maybe 3 seconds. It happens once every week or two. We're going to have it serviced, but since the noise isn't predictable we have some concern about being able to remedy it. Right now I would not recommend it, but that may change.
Date published: 2015-06-09
Rated 5 out of
5 by
Pagan from
Everything we expected it to be - good reputation
24 cubic feet in a 33" wide space is hard to find, this is about it and it's a nice unit!
Makes lots of ice
Big fridge drawers, and the third drawer is neat and use-able!
LED lighting is bright, easy to see all areas.
Spill proof shelving can save a mess before it happens.
Alarm telling you the door is open too long is a great feature too!
Buy this fridge!
Date published: 2015-04-29
Rated 4 out of
5 by
Scott106 from
Rating applies replacement refrigerator
We had this refrigerator for a very short time when it began to make "grinding" noises and not holding the temperature setting. I contacted Sears (which is where it was purchased) and, since it was within the 30 day return policy, it was replaced with like kind. Since then, the new one has been very quiet and has been holding the temperature. We are happy with the refrigerator at this point.
Date published: 2015-01-07
Rated 5 out of
5 by
euonymous from
Great refrigerator/freezer
It works fine and is much quieter than our old Amana refrigerator/freezer. If you keep a door open overly long it plays a tune to wake you up, which is amusing. The freezer is nice and fairly accessible. I guess there's no good way to design a small freezer for accessibility, but this is acceptable and it works nicely. Lots of space. Small point: the door handle is smooth so it cleans nicely unlike matte finish appliances which always seem to hold the dirt. Good purchase, good product.
Date published: 2014-12-02
Rated 5 out of
5 by
DMOctober from
Very pleased
I ended up spending a little more than i planned on a new fridge but i'm glad i did. It runs quietly and i love the bottom freezer. Side by side didn't work for me because the fridge is located next to a wall. The delivery man swapped the door to open to the left and solved all my problems.
Date published: 2014-11-19
Rated 5 out of
5 by
Trisha from
Happy Consumer!
I have been shopping and researching for months for a very specific style and quality. I am so happy to have waited and purchased this refrigerator.
The interior lighting is excellent. I love the ease of having everything within reach up top. The freezer drawer closes smoothly. The ice dispenser is precisely located (the ice is abundant). It is very solid. It is quiet and very attractive.
I previously had a side by side with water and ice in the door. I was not happy with the look or more importantly the problems that came with faulty water dispensing.
Date published: 2014-10-08
Rated 5 out of
5 by
Rife from
Big unit for narrow space!
The webpage has the features, and I'm here to say it's a great fridge! We chose LG for good reviews, even from repair techs! This was an "online-only" special and well priced so we took a chance we'd like it!
24 cubic feet in a 33" wide space is hard to find, this is about it and it's a nice unit!
Makes lots of ice, cubed or crushed.
Big fridge drawers, and the third drawer is neat and use-able!
LED lighting is bright, easy to see all areas.
Spillproof shelving can save a mess before it happens.
Alarm tellin you the door is open too long is a great feature too!
Buy this fridge!
Date published: 2014-06-16
We're here to support you with our product.
View LBC24360ST Product Support-
Warranty Information
View manufacturer warranty information
-
Register Your Product
Get the most out of your ownership
-
Manuals and Downloads
Download owner's manuals and documentation
-
Help Library
Help yourself to helpful product information
-
Video Tutorials
Learn how to install & operate your LG product
-
Request a Repair
Submit an online service request
-
Other Support Options
More help with your LG product
Contact us for any support inquiries.
-
Live Chat
Chat with an LG Support Representative.
Weekdays 8am-8pm CST -
Telephone
Call an LG Support Representative.
(800) 243-0000 Consumer (6am-midnight CST)
-
Email
No time to chat? Send LG Support your inquiry.
ASK & ANSWER
Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.
where do i order parts for this fridge.it swings left handed now,i want it to swing right handed
Parts and accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts.
Date published: 2016-07-22
What hardware is needed for my LG Model #lrbn20512ww
We appreciate your interest in this refrigerator. It is uncertain to what type of hardware is being referred for this product. Please contact our Customer Interactive Center at 800-243-0000 for additional information.
Date published: 2016-04-09
I need parts for my freezer door on my LG refrigerator
Parts and accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts.
Date published: 2016-02-09
convert to split shelves
Can you purchase the rear bar and shelves to convert from 2 full size shelves to adjustable 1/2 shelves?
I apologize, but no; it will not be possible to provide information relating to the modification of a product to something different than the original specifications.
Date published: 2015-03-30
CAN THE GLASS FROM THE SHELF COME OUT OF THE FRAME.
ON ONE OF THE ADJUSTABLE SHELF'S STUFF HAS GOTTEN UNDER THE GLASS ON THE BACK BETWEEN THE FRAME AND THE GLASS IT WILL NOT SOAK CLEAN AND IT LOOKS GROSS. WHEN I LOOK AT THE BOTTOM IT LOOKS LIKE THERE TWO TABS THAT HOLD THE GLASS & FRAME BUT I CANT FIGURE HOW TO GET IT TO OPEN. HELP PLEASE THANK YOU
We regret the trouble you have experienced with this refrigerator. The upper two shelves both appear to be constructed in a manner, so as to not be taken apart. Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number of the Refrigerator Shelves is MHL62812402.
Date published: 2015-02-19
The ice maker
Does the ice maker has a water filtration system?
No ice maker
Date published: 2015-01-10
How do I get the shelf out about the crisper drawers
I have liquid spilled under the glass on the shelf above the crisper drawers. I can't get it to come out so I can clean it. What can I do
We regret the trouble you have experienced with this product. The glass for the shelf over the crisper drawers is designed to be lifted out from inside the drawers. Open and/or remove the crisper drawers and lift the glass from beneath it. Information about this can be found on page 40 of your owner’s manual.
Date published: 2014-07-23
Does the LBC24360SW have a linear compressor
The spec sheet on this website indicates that it does under the warranty statement but, none of the other literature mentions it. I just ordered this model but my hopes of the linear compressor are fading.
We appreciate your interest in this refrigerator. According to our service materials on this model, it would appear that this model was designed with a ROTARY Compressor. It appears that this one notation mentioned may have been in error.
Date published: 2014-06-25
