Discontinued Product

Wash Smart, Wash Well

3.6 cu.ft. Large Capacity Front Load Washer with Dual LED Display

WM2301HR

  • This product has been DISCONTINUED. But you can see all of our current Washers here: See all Washers
Rating / Reviews
Be the first to review

Enlarge

3.6 cu.ft. Large Capacity Front Load Washer with Dual LED Display

WM2301HR

DOWNLOAD PDF
SHOW  HIDE SUMMARY
  • Design Style
  • Stackable
  • Dial-A-Cycle™
  • ENERGY STAR Compliant
  • Warranty
  • Type of Display
  • Dimensions (WxHxD)
  • Capacity (cu.ft.)
  • Designer Color
  • Number of Programs
  • Number of Wash/Rinse Temps
  • Number of Options
  • Direct Drive Motor
  • LoDecibel™ Quiet Operation
  • TrueBalance™
  • Delay Wash
  • Spin Speed (Max)
  • Front Loader
  • Yes
  • Yes
  • Yes
  • 1 year (parts and labor), 2 years (control board) 10 years (motor), Lifetime on drum
  • LCD
  • 27" x 38 11/16" x 29 3/4"
  • DOE 3.6
  • Wild Cherry Red
  • 9
  • 5
  • 10
  • Yes
  • Yes
  • Yes
  • Yes
  • 1200 RPM
SHOW  HIDE SIZE AND WEIGHT
  • Width
  • Height
  • Depth
  • Depth with Door Open
  • Carton (WxHxD)
  • Weight (Product)
  • Weight (Shipping)
  • 27"
  • 38 11/16"
  • 29 3/4"
  • 51"
  • 29 1/2" x 42 1/4" x 31 1/4"
  • 190 lbs
  • 208.5 lbs
SHOW  HIDE WASH PROGRAMS
  • Program Names
  • Wash/Rinse Temps
  • Spin Speeds (RPM)
  • No. of Water Levels
  • No. of Soil Level
  • Options
  • Sanitary (158°F), Drain + Spin, Baby Wear, Bulky/Large, Cotton/Normal, Perm Press, Delicates, Hand Wash/Wool, Speed Wash
  • Extra Hot/Cold, Hot/Cold, Warm/Warm,Warm/Cold, Cold/Cold
  • Extra High (1200 max), High (1020/980), Medium (980/600), Low (950/600/400), No Spin
  • Auto-adjusts to load size
  • 5
  • Prewash, Rinse & Spin, Extra Rinse, Stain Cycle, Water Plus, Load Size, Tub Clean, SpinSense™, Delay Wash (up to 19 hours), Custom Program
SHOW  HIDE FABRIC CARE FEATURES
  • Allergiene™
  • SenseClean™ System
  • SteamWash™ System
  • RollerJets™ and Forced Water Circulation
  • No
  • Yes
  • No
  • Yes
SHOW  HIDE CONVENIENCE FEATURES
  • 4 Tray Dispenser
  • TrueSteam™ Generator
  • TrueBalance™ Anti-Vibration System
  • SmartDiagnosis™
  • Load Sense
  • Status Indicator(s)
  • End of Cycle Signal
  • Child Lock
  • Auto Suds Removal
  • Forced Drain System
  • Internal Water Heater (1000W)
  • Leveling Legs
  • Auto Balancing
  • 10° TilTub™
  • Prewash, Main Wash (with liquid detergent cup), Bleach, Softener
  • No
  • No
  • Yes
  • Yes
  • Yes
  • Yes
  • Yes
  • Yes
  • Yes
  • Yes
  • 4 Adjustable Legs
  • Yes
  • No
SHOW  HIDE MOTOR
  • Motor Type / Motor Speed
  • Axis
  • Direct Drive / Variable
  • Horizontal
SHOW  HIDE MATERIALS AND FINISHES
  • NeveRust™ Stainless Steel Drum
  • Easy Loading TilTub™
  • Cabinet
  • Control Panel
  • Top Plate
  • Transparent Door Glass
  • Door Rim
  • Available Colors
  • Yes
  • Yes
  • Painted Steel
  • Plastic
  • Painted
  • Yes
  • Chrome
  • White
SHOW  HIDE OPTIONS
  • Pedestal
  • Pedestal (WxHxD)
  • Stacking Kit
  • Yes
  • 27" x 13 3/5" x 28 2/5"
  • Yes
SHOW  HIDE POWER SOURCE
  • Ratings
  • Electrical Requirements / Type
  • UL Listed
  • 120V, 10 Amps / Electric
Back to Top

LG’s sleek, sophisticated, intelligent front load washer is available with a 3.6 cu.ft. capacity tub, available in White and Wild Cherry Red.LG front load washers require approximately 3/4 less water than top loaders. All LG washing machines have the Energy Star rating.

Design, features and specifications subject to change without notice. Screen images simulated and/or dramatized. Some features in videos may not be available on all models. Please refer to the TECHNICAL SPECIFICATIONS tab for a complete list of features by model.
Design, features and specifications subject to change without notice.
