LG Ultra Stretch Signage

86BH5F

Key Features

Brightness(Typ.) : 500 cd/m²
Aspect Ratio: 58:9
Bezel: 4.4 mm(L/R), 5.9 mm(T/B)
Depth: 81.7mm
Interface: HDMI (3), DP, USB(2), Audio, DVI-D, RS232C, RJ45, IR

All Spec

PANEL

Screen Size: 217 cm (86)

Panel Technology: IPS

Back Light Type: Direct

Aspect Ratio: 58:9

Native Resolution: 3840 x 600 (FHD)

Refresh Rate: 60Hz

Brightness: 500nit (Typ.)

Dynamic CR: 500,000:1

Color Gamut: NTSC 72%

Viewing Angle (H x V): 178º x 178º

Color Depth (Number of Colors): 1.07 Billion colors

Response Time: 8ms (G to G)

Surface Treatment (Haze): Haze 3%

Operation Hours (Hours/Day): 24/7

Portait / Landscape: YES / YES

CONNECTIVITY

HDMI In: YES (3ea)

HDMI In (HDCP Ver.): 2.2/1.4

DP In: YES (HDCP 2.2/1.3)

DVI-D In: YES (HDCP 1.4)

Audio In: YES

RS232C In: YES

RJ45(LAN) In: YES (1ea)

IR In: YES

USB In: USB2.0 Type A (2ea)

DP Out: YES

Audio Out: YES

RS232C Out: YES

RJ45(LAN) Out: YES

Daisy Chain: Input : HDMI, DP, DVI-D / Output : DP

MECHANICAL SPECIFICATION

Bezel Color: Black

Bezel Width: T/R/L/B : 5.9/4.4/4.4/5.9mm

Weight (Head): 20.5Kg

Packed Weight: 38.2Kg

Monitor Dimension (W x H x D, mm): 2158.3 x 348.5 x 81.7mm

Handle: YES

VESA™ Standard Mount Interface (mm): 600 x 200 mm

Carton Dimensions (W x H x D, mm): 2290 x 599 x 228mm

FEATURE - HARDWARE

Internal Memory (eMMC): 8GB

Wi-Fi/BT (Built-in): YES

Temperature Sensor: YES

Auto Brightness Sensor: YES

Current Sensor: YES

Local Key Operation: YES

FEATURE - SOFTWARE

OS Ver. (webOS): webOS 4.0

Local Contents Scheduling: YES

Group Manager: YES

USB Plug & Play: YES

Fail Over: YES

Booting Logo Image: YES

No Signal Image: YES

RS232C Sync: YES

Local Network Sync: YES

PBP: YES (4PBP)

Screen Rotation: YES

External Input Rotation: YES

Tile Mode Setting: YES

Setting Data Cloning: YES

SNMP: YES

ISM Method: YES

Auto Set ID: YES

Status Mailing: YES

Control Manager: YES

Crestron Connected: YES

Smart Energy Saving: YES

PM mode: YES

Wake on LAN: YES

BEACON: YES

HDMI-CEC: YES

ENVIRONMENT CONDITIONS

Operation Temperature: 0 °C to 40 °C

Operation Humidity: 10 % to 80 %

POWER

Power Supply: AC 100-240V~, 50/60Hz

Power Type: Built-in Power

POWER CONSUMPTION

Max.: 240W

Typ.: 220W

Power off: 0.5W

DPM: 0.5W

Smart Energy Saving (70%): 100W

Others-BTU (British Thermal Unit): 751 BTU/Hr(Typ.), 819 BTU/Hr(Max.)

CERTIFICATION

Safety: CB / NRTL

EMC: FCC Class "A" / CE / KC

ERP / Energy Star: YES(EU Only) / NO

OPS COMPATIBILITY

OPS Type compatible: YES (Piggyback)

SOFTWARE COMPATIBILITY

SuperSign Control+: YES

SuperSign WB: YES

Mobile CMS: YES

Connected Care: YES

LANGUAGE

OSD: English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic

ACCESSORY

Basic: Remote Controller(including battery 2ea), Power Cord, DP cable, RS-232C Cable, IR/Light sensor receiver, Manual

Optional: OPS Kit(KT-OPSF)

SPECIAL FEATURE

IP Rating: IP5X

Conformal Coating (Power Board): YES
