Alanfrr Technology
Strong cooling
Tropical Compressor
Health Condition
Product Type
Air Suspended Ceiling
Cooling / heating
Only cooling
Alanfrr Technology
Yes
Fast cooling
Yes
Super energy saving
Yes
Coolers protection of the environment
Yes
Purification of the Clean Air
Yes
Control the rate of air flow
Yes
Noise internal unit level (H / M / L)
49/48/47 dB (A)
Operating range
Up to 54 ° C
Power supply (ø / V / Hz)
1/230/60
Cooling capacity
9.5 Kw (32,400 Btu / h)
Energy used
2.8 kW
Energy Efficiency %
11.6 Btu / hr / W
COP
3.4 W / W
AC current
0.9 A.
Air flow rate (H / M / L)
30.0 / 28.3 / 26.6 CMM
Dehumidify rate
3.6 ℓ / h
Body dimensions (width × height × depth)
1,750 × 650 × 220 mm
Net weight
42.5 kg
AC current
A 12.1
Compressor Type
Rotary double
Sound level (H)
52 dB (A)
(Width × height × depth)
950 × 834 × 330 mm
Net weight
41 kg
Delivery pipes (liquid)
Ø 9.52 mm
Delivery pipes (gas)
Ø 15.88 mm
Exchange (external / internal)
Ø 32 mm / 25 mm
.toul Pipes maximum (the main pipeline)
50 m
Vertical height maximum. (internal external)
30 m
Shops
Yes
Restaurants
Yes
Offices
Yes
