All Spec

PANEL

  • Screen Size

    55"

  • Resolution

    1,920 x 1,080 (FHD)

  • Brightness

    350

CONNECTIVITY

  • Input

    HDMI(2), DVI-D, RGB, Audio

  • Output

    Audio

  • External Control

    RS232C in/out, RJ in, IR Receiver, USB

PHYSICAL SPECIFICATION

  • Bezel Width

    11.9mm (T/R/L), 18mm (B)

  • Monitor Dimension (W x H x D)

    1238mm x 714.9mm x 54mm(38.6mm:Thinnest Part)

  • Weight (Head)

    17.5kg

  • VESA™ Standard Mount Interface

    300 x 300

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10 % to 80 %

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ.

    70 W

  • Smart Energy Saving

    55 W

STANDARD(CERTIFICATION)

  • Safety

    UL / cUL / CB / TUV / KC

  • EMC

    FCC Class "A" / CE / KCC

  • ErP / Energy Star

    NA / Yes (Energy Star 7.0)

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible

    No

  • External Media player Attatchable

    Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign W

  • Control and Monitoring Software

    SuperSign C

ACCESSORY

  • Basic

    Remote Controller(include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver

  • Optional

    Stand(ST-492T), Media player, Wall bracket(LSW350B), VESA Adapter(AM-B330S)

COMPLIANCE INFORMATION

The safety information for accessories is included with the safety information for the product and is not provided separately.

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
