DLGY1702W
7.3 cu.ft. Ultra Large Capacity High Efficiency Front Control SteamDryer™ with SteamFresh™
  • Ultra Large 7.3 cu. ft. Capacity
  • Front Control Design
  • Steam Technology
  • SteamFresh™ Cycle
  • ENERGY STAR® Qualified
7.3 cu.ft. Ultra Large Capacity High Efficiency Front Control SteamDryer™ with SteamFresh™

SUMMARY

  • Dryer Type
    Gas
    SteamDryer™
    Yes

CAPACITY

  • Capacity
    7.3 cu. ft.

APPEARANCE

  • Design Look
    Front Control
    Front Electronic Control Panel with LED Display
    Yes
  • Touch Buttons
    Yes

ENERGY

  • ENERGY STAR® Qualified
    Yes

DRYING PROGRAMS

  • No. of Programs
    12
    Programs (Sensor Dry)
    Cotton/Normal, Perm. Press/Casual, Heavy Duty, Small Load, Bulky/Bedding, Anti-Bacterial, Towels, Delicates, SteamFresh™, Wrinkle Free
  • Programs (Manual Dry)
    Speed Dry, Air Dry
    No. of Options
    8
  • Options
    More Time, Less Time, Wrinkle Care, Custom Program, Child Lock, Damp Dry Signal, End of Cycle Signal, Rack Dry
    Temperature Settings
    High, Medium High, Medium, Low, Ultra Low
  • Drying Levels
    Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
    Manual Dry Times
    60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time

FABRIC CARE FEATURES

  • SteamFresh™ Cycle
    Yes
    Wrinkle Free Cycle
    Yes
  • Sensor Dry
    Yes
    Precise Temperature Control with Variable Heater
    Yes

CONVENIENCE FEATURES

  • LoDecibel™ Quiet Operation
    Yes
    SmartDiagnosis™
    Yes
  • FlowSense™ Duct Clogging Indicator
    Yes
    Anti-Bacterial Cycle
    Yes
  • Wrinkle Care Option
    Yes
    Remaining Time Display/Status Indicator(s)
    Yes
  • End of Cycle Signal
    Yes
    Child Lock
    Yes
  • Drum Light
    Yes
    Reversible Door
    Yes
  • Leveling Legs
    4 Adjustable Legs
    Venting Option
    Electric: 4 Way Venting / Gas: 3 Way Venting
  • 3 Minute Installation Check
    Yes

MATERIALS AND FINISHES

  • NeveRust™ Stainless Steel Drum
    Yes
    Cabinet
    Painted Steel
  • Control Panel
    Plastic
    Top Cover
    Plastic
  • Diamond Glass Door
    Transparent (White), Dark Gray Tint (Graphite Steel)
    Available Colors
    White (W), Graphite Steel (V)

POWER SOURCE

  • Ratings
    CSA Listed
    Electrical Requirements
    120V, 15 Amps (Gas) / 240V, 30 Amps (Electric)
  • Type
    Gas/Electric

OPTIONS

  • LP Conversion Kit
    4948EL4002B
    Side Venting Kit
    383EEL9001B

DIMENSIONS

  • Product (WxHxD)
    27" x 40 5/32" x 28 3/8" (50 1/4" D with door open)
    Carton (WxHxD)
    29 1/2" x 43 7/10" x 31 1/4"
  • Weight (Product/Carton)
    136.4 lbs. / 154.9 lbs.

Warranty/UPC

  • Limited Warranty
    1 Year Parts and Labor
    UPC
    048231013680
What people are saying
Rated 5 out of 5 by from A Drying Beauty! Love this dryer! Drys more quickly than our last dryer and solved our workflow problem of having to wait for drying once the washer completes. The dryer vent flow sensor is also brilliant and should be standard on all dryers as a safety measure. Thanks LG!
Date published: 2018-03-28
Rated 5 out of 5 by from Great Dryer - I'd get again. I really like the dryer. Lots of options - so many we don't use them all. Some of the features we do use a lot - ADD EXTRA TIME, washing shoes on the attachment that fits in the dryer, BULKY ITEMS, STEAM. The only fault is that the top of the dryer is glass. Our's shattered for some reason. Luckily it was still under warranty so it was taken care of.
Date published: 2018-03-27
Rated 5 out of 5 by from Dries Fast and Easy My husband and I had to replace the dryer we had because the repair it needed wasnt worth it - it would have been more beneficial to just buy a new one. I did some research after talking with a rep at Home Depot - we ordered this one. I couldnt be happier. The clothes are thoroughly dry in a timely manner and it is super quiet. Great value! I have also used the steam function to get out stubborn wrinkles.
Date published: 2017-03-15
  • y_2019, m_7, d_19, h_20
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_7
  • loc_en_US, sid_MD05083319, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 220ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Then, will the side venting kit allow this dryer (gas version) to vent to the Left when facing the dryer?

Asked by: JeffInsd
Instructions with regards to the venting of the LG 7.3 cu.ft. Ultra Large Capacity High Efficiency Front Control SteamDryer™ with SteamFresh™, Model # DLGY1702W are given for when you are facing the unit, so venting to the left can be done. The reason that right side venting (when facing the unit) is not available on Gas Dryers is because the Gas Valves, Igniters, etc. are placed on that side and would interfere with the vent duct...^IFV
Answered by: LGJoel
Date published: 2015-10-01

installation for gas dryer

what is the clearance needed from wall to back of dryer for gas installation?
Asked by: mbkitchen
We appreciate your interest in the LG 7.3 cu.ft. Ultra Large Capacity High Efficiency Front Control SteamDryer™ with SteamFresh™, Model # DLGY1702W. The recommended installation clearances for this unit will depend on the location in which you are looking to install it, however, for a recessed location or closet installation, the recommended spacing for the rear is 5 inches but you should also consider additional spacing for ease of installation or servicing and for wall, door and floor moldings...^IFV
Answered by: LGJoel
Date published: 2015-08-22

I need to know where, on the back of the machine, is the vent hole? left right or center? Hopefully on the left side, as our vent to the outside is on the far left side of the wall, about 4 inches from the left corner.

Asked by: robert222

What bulb does the dlg1702 dryer use?

Asked by: kfk10
