7.4.cu.ft. Ultra LargeCapacity Electric SteamDryer™ with TurboSteam Technology

7.4.cu.ft. Ultra LargeCapacity Electric SteamDryer™ with TurboSteam Technology

DLEX5000V

7.4.cu.ft. Ultra LargeCapacity Electric SteamDryer™ with TurboSteam Technology

SUMMARY

CAPACITY
7.4 cu.ft.
Dimensions (WxHxD)
29" x 40 7/8" x 33 3/8" (56" with door open)
Steam Technology
Yes
ThinQ®
Yes

All Spec

CAPACITY

  • Capacity

    9.0 cu. ft.

ENERGY

  • ENERGY STAR® Qualified

    Yes

TYPE

  • Design Look

    On-Door Front Control Panel

  • Intelligent Electronic Controls with Dual LED Display

    Yes

  • Touch Buttons

    Yes

  • Dial-A-Cycle™

    Yes

APPEARANCE

  • Design Look

    On-Door Front Control Panel

  • Intelligent Electronic Controls with Dual LED Display

    Yes

  • Dial-A-Cycle™

    Yes

DRYING PROGRAMS

  • 14 Programs

    Sensor Dry: Cotton/Normal, Perm. Press/Casual, Towels, Delicates, Heavy Duty, SteamFresh™ SteamSanitary™, Bedding, LowTemp Dry, Anti-Bacterial, Sports Wear, Download/Super Dry Programs. Manual Dry: Speed Dry, Air Dry

  • 14 Options

    More Time, Less Time, Custom Program, PGM Save, Damp Dry Signal, Wrinkle Care, Child Lock, Wi-Fi Connect, Drum Light, Energy Saver, TurboSteam, Smart Grid Remote Start, Default On/Off

  • 5 Temperature Settings

    High, Medium High, Medium, Low, Ultra Low

  • 5 Drying Levels

    Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry

  • Dry Times

    60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time

CONVENIENCE FEATURES

  • LoDecibel™ Quiet Operation

    Yes

  • End of Cycle Signal

    Yes

  • Drum Light

    Yes

  • Reversible Door

    Yes

  • FlowSense™ Duct Clogging Indicator

    Yes

  • Venting Option

    4 Way Venting

  • Leveling Legs

    4 Adjustable Legs

  • Remaining Time Display/Status Indicator

    Yes

  • 3 Minute Installation Check

    Yes

  • Smart DiagnosisTM

    Yes (v 3.0)

  • ThinQ® (Wi-Fi)

    Smart Grid Ready, Energy Monitoring, Black Box, Remote Control, Home Chat

MATERIALS AND FINISHES

  • Alcosta Aluminized Alloy Steel Drum

    Yes

  • Cabinet

    Painted Steel

  • Control Panel

    Plastic

  • Top Cover

    Painted Steel

  • Door

    Glass / Chrome

  • Door Cover

    Dark Blue Tinted Round Cover

  • Available Colorus

    Graphite Steel (V)

POWER SOURCE

  • Ratings

    CSA Listed

  • Electrical Requirements

    240V, 30 Amps

  • Type

    Electric

  • BTU

    20,000

OPTIONS

  • Pedestal

    WDP4V

  • Pedestal (WxHxD)

    27" x 13 3/5" x 28 2/5"

  • Matching Washer

    WM5000HVA

DIMENSIONS

  • Product (WxHxD)

    27" x 38 11/16" x 29 3/4" (51" D with door open)

  • Carton (WxHxD)

    29 7/32" x 42 7/16" x 33 7/32"

  • Weight (Product/Carton)

    148.6lbs / 151.7 lbs

WARRANTY

  • Warranty

    1 Year Parts and Labour

UPC CODES

  • DLEX5000V

    772454 064531

  • WDP4V

    048231 011198
