32LT340CBTB
LT340C Series
32"
  • Quick Menu
  • Hotel Mode
  • USB Cloning
  • WOL (Wake on LAN)
  • SNMP
  • Crestron Connected® (Network Based Control)

component-OBScountrySelectDesc

LT340C Series
  • EASIER MAINTENANCE

    EASIER MAINTENANCE1 EASIER MAINTENANCE2
  • Real-Time Remote Monitoring

    In case of malfunctions or errors, real-timeremote care is available. When an error occurs, a notification can be sent through the SNMP(Simple Network Management Protocol) protocol.

  • Power & Network in One Line

    WOL(Wake-on-LAN) enables users to send a message through network to turn on displays. This greatly simplifies the installation and maintenance processes as only a single wire is required for power and network connection.

* It is a network based control system.
Available AV control systems may differ by regions.

DISPLAY

  • Inch
    32H"
    Resolution
    1,366 x 768 (HD)
  • Backlight Unit Type
    Direct

BROADCASTING SYSTEM

  • Digital
    Yes (DVB-T2 / C)

VIDEO

  • HDR / HDR Dolby Vision
    - / -

AUDIO

  • Audio Output
    5W + 5W
    Speaker System
    2.0 ch

FEATURES

  • Hospitality
    Quick Menu (3.0), USB Cloning, Wake On LAN, SNMP, Self Diagnostics (USB), HTNG-CEC (1.4), Simplink (HDMI-CEC, 1.4), IR Out, Multi IR Code, Hotel Mode / Installer Menu, Insert Image, Lock mode (Limited), Welcome Video / Screen, One Channel Map, External Speaker Out, RJP Compatibility, USB Auto playback / USB Auto playback+, Auto Off / Sleep Timer, Smart Energy Saving, Crestron ConnectedⓇ (Network Based Control), Time Scheduler, Cromecast anti cover (optional), Anti-theft System (Kensington Lock, Credenza / Security Screw Hole, Lock Down Plate)

JACK INTERFACE

  • Set Side
    Headphone Out, HDMI In (1.4), USB (2.0), CI Slot
    Set Rear
    HDMI In (1.4), USB, RF In, AV In (Phone Jack Type), Digital Audio Out (Phone Jack Type), RGB In, RS-232C (Control & Service), RJ45 (SNMP & MHEG), External Speaker Out (Spk-out 1, 4W (Stereo, R: 2.0W, L: 2.0W, 8Ω))

DIMENSION (UNIT: MM / KG)

  • Vesa
    200 x 200
    W x H x D / Weight (with stand)
    739 x 472 x 168 / 4.9
  • W x H x D / Weight (without stand)
    739 x 441 x 74.6 (84) / 4.85
    W x H x D / Weight (Shipping)
    812 x 510 x 142 / 6.1

POWER (UNIT : WATTS)

  • Voltage, Hz
    TBD
    Typical
    TBD
  • Stand-by
    TBD

GENERAL

  • Region
    ASIA
