55TC3D
Interactive Digital Board
  • Brightness(Typ.): 450 cd/m²
  • Touch Type: P-Cap(Ag Metal Mesh)
  • Touch Point: Max. 40 points
  • Interface: HDMI (3), DP, DVI, RGB, RS232C, RJ45, USB (2), OPS USB, Touch USB (2), Wi-Fi Built-in

component-OBScountrySelectDesc

Interactive Digital Board
*Installation of the PC client app (IDB Duo) is required. Go to the 'Tech Spec' section of this page for the minimum requirements and then download the app from the 'Business Resources' section.
*The menu design (GUI) is subject to change without notice.

ACCESSORY

  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Touch Pen Tip (1ea)
    Optional
    OPS Kit (KT-OPSA), Wall Mount(LSW350A/B)

CONNECTIVITY

  • External Control
    RS232C in/out, RJ45 in
    Input
    HDMI (3), DP, DVI-D, RGB, Audio in, USB 3.0, USB 2.0, OPS USB 2.0
  • Output
    Touch USB 2.0 (2)

ENVIRONMENT CONDITIONS

  • Operation Humidity
    10% to 80%
    Operation Temperature
    0°C to 40°C

PANEL

  • Brightness (Module, Typ., cd/m²)
    450
    Native Resolution
    1,920 x 1,080 (FHD)
  • Screen Size
    55”

PHYSICAL SPECIFICATION

  • Bezel Width
    32.7mm (T), 33.4(L/R), 38.8 mm(B)
    Carton Dimensions (W x H x D)
    1,369 x 890 x 210 mm
  • Monitor Dimension (W x H x D)
    1,276.4 x 751.9 x 63.9 mm
    Packed Weight
    36.1kg
  • VESA™ Standard Mount Interface
    300 x 300 mm
    Weight (Head)
    30.1kg

POWER CONSUMPTION

  • Smart Energy Saving
    ≤ 70W
    Typ.
    ≤ 100W

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign Premium
    Control and Monitoring Software
    SuperSign Link

STANDARD (CERTIFICATION)

  • EMC
    FCC Class “A”/CE/KCC
    Safety
    UL/cUL/CB/TUV/KC

TOUCH

  • Touch type
    P-Cap (Ag Metal Mesh)
    Interface
    USB 2.0
  • Protection Glass Thickness
    3.2T (Anti-Glare)
    Multi touch point
    Max. 40 Points
  • Available object size for touch
    More than Ø 6mm
    Accuracy
    2mm

MINIMUM REQUIREMENTS FOR LG PRESENTER

  • OS (Windows 32bit or 64bit)
    Windows 7, Windows 10
    OS (macOS)
    macOS 10.12 Sierra, MacOS 10.13 High Sierra
  • CPU (Windows)
    2.7GHz+ Dual Core Broadwell or higher
    CPU (macOS)
    Any CPU which supports Sierra or High Sierra
  • Memory
    4GB RAM
    Hard Drive
    1GB of free space
  • Graphics Hardware (Windows)
    Intel Iris or higher, Nvidia, ATI
    Graphics Hardware (macOS)
    Any GPU which supports Sierra or High Sierra
