98UH5E-B
UH5E Series
  • Brightness(Typ.) : 500 cd/m²
  • Bezel : 14.9 mm (Even, Off-Bezel)
  • Depth : 69.4 mm (without Handle)
  • Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR/ External Speaker Out

component-OBScountrySelectDesc

UH5E Series

Superior Picture Quality

Superior Picture Quality1 Superior Picture Quality2
  • True Color, Immersive View

    The UH5E series is large enough to display content and get undivided attention from various viewers. LG IPS panel features a wide range of angle to deliver clear content regardless of the position of viewers. Each pixel in the IPS panel reproduces image colors true-to-life, without distortion.

  • Vivid Color Details with Ultra HD

    The UHD resolution allows users to view details even when zooming in on the display, with four times higher definition than FHD. The UH5E ensures stable UHD video playback with HEVC(High Efficiency Video Coding).

*The availability of "Signage 365 Care" service can differ by region, so please contact the LG sales representative in your region for further details.

ACCESSORY

  • Basic
    Remote Controller, Power Cord, QSG, IR/Light Sensor Receiver, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT
    Optional
    Speaker (SP-2200)

CERTIFICATION

  • EMC
    FCC Class "A" / CE / KC
    ErP / Energy Star
    Yes (EU Only) / N/A
  • Safety
    CB / NRTL

CONNECTIVITY

  • External Control
    RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In
    Input
    HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
  • Output
    DP, Audio (Off/Fixed/Variable), External Speaker

ENVIRONMENT CONDITIONS

  • Operation Humidity
    10% to 80%
    Operation Temperature
    0°C to 40°C

MECHANICAL SPECIFICATION

  • Bezel Width
    14.9 mm (Even) * Off-Bezel
    Carton Dimensions (W x H x D)
    2,342 x 1,386 x 402 mm
  • Monitor Dimension (W x H x D)
    2,191.8 x 1,246.8 x 69.4 mm (without Handle)
    Packed Weight
    123 kg
  • VESA™ Standard Mount Interface
    800 x 400 mm
    Weight (Head)
    88 kg

MEDIA PLAYER COMPATIBILITY

  • OPS Type Compatible
    No

PANEL

  • Brightness(Typ.,cd/m²)
    500
    Resolution
    3,840 x 2,160 (UHD)
  • Screen Size
    98"

POWER

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

POWER CONSUMPTION

  • Smart Energy Saving
    294 W
    Typ. / Max.
    420 W / 560 W

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control / Control+
