CL_Giant-C_01

AdaptAble™ Controls

AdaptAble™ Controls provide the space saving and convenience without compromising capacity while retaining easy to reach controls. The controls are always at a convenient height and are versatile enough to match your needs.

CL_Giant-C_02

Installation Flexibility

Install your laundry to meet your needs and space with side by side or stack configuration. Easy to bring and reinstall your products even though you move to new house.

* Specific parts sold separately are required to stack machine.

CL_Giant-C_03

Easy Sliding System

The Easy Sliding System allows for quick and easy maintenance. The innovative sliding mechanism enables you to service the down stack without having to completely remove the upper stack. By sliding the upper stack equipment, it is easy to access important parts in both the upper and lower stack.
*Washer & Dryer Stack Only

CL_Giant-C_04

Dual Lock System

LG’s double locking system for the front panel and coin vault access provides increased security.

*Coin Washer & Dryer Stack Only
*Model : F1069FDP, RN1329AN1, RV1329AN1, GCWP1069QD, GD1329QGD, GD1329QED

CL_Titan-C_05

Easy Access Lint filter

LG Commercial washers are equipped with detergent injection supply. This system controls 5 individual trigger signals for liquid supply injection. This makes it very simple for your detergent suppliers to connect their liquid supply system to the machine.

CL_Titan-C_06

Inverter
Direct Drive™

Unlike the traditional belt and pulley, the LG Commercial Laundry drum is directly attached to the motor providing superior durability and reliability. Less parts equal less repairs.

CL_Titan-C_07

Premium Powder Coated

Our powder coated finish creates the same durability as it does when painting a car. It is sure to last long and provide an easy to clean exterior.

CL_Titan-C_08

Multi Heat Treatment

To ensure superior performance LG heat treats the shaft which connects our drums and motors. This protects against gradual wear and tear.

CL_Giant-C_09

Multiple Damper Vibration Reduction

Multiple dampers absorb vibration and reduce noise creating a quieter washing environment.

CL_Titan-C_10

Multiple Damper Vibration Reduction

Multiple dampers absorb vibration and reduce noise creating a quieter washing environment.

CL_Titan-C_11

Steel Control Panel

The front access panel is constructed of strong coated steel – not plastic, to enhance reliability and provide an important security barrier for the coin box and vault as well as the machine control assembly.

CL_Titan-C_12

Stainless Steel Drum for Washer

The stainless steel drum helps prevent clothes from staining or damages during the wash cycle.

CL_Titan-C_13

Tempered Glass

The tempered glass door is less susceptible to breakage and scratching, while the transparent cover allows for easy viewing.

CL_Titan-C_14

Energy Saving

The tempered glass door is less susceptible to breakage and scratching, while the transparent cover allows for easy viewing.

CL_Titan-C_15

Space Saving

The small cabinet size with bigger washing capacity and stackable design allows more customers and more machines in limited space.

CL_Titan-C_16

Atomizing System

The Atomizing nozzle sprays fresh water onto the clothes and the door. This helps produces a rapid fill so clothes are soaked sooner and longer providing a better washing performance. It also cleans the door glass every time the water sprays on it, reducing your burden of cleaning any excess soap residue.

CL_Titan-C_17

Optimized Washing System

When an LG Commercial Washer detects over-suds during a washing cycle, it moves into a suds reduction process which delivers a better washing performance.

CL_Titan-C_18

10° Tilted Drum

LG’s Commercial Washer tub is tilted at 10°. It enables the washer to have a higher level of water in the tub than the competition. This allows us to use less water while not sacrificing superior washing performance.

CL_Titan-C_19

Embossed Inner Drum

The surface of the embossed inner drum increases the amount of contact with fabric. This creates better washing action and helps remove more dirt and stains.

CL_Titan-C_20

Tub Cleaning System

A dirty tub from hours of long operation can affect washing performance. Our tub cleaning program helps you keep a clean tub even in the busiest locations.

CL_Titan-C_21

Customized Program

Users can design their own programs such as washing time, rinse time, water level, etc. and save up to 20 washing programs to meet optimized washing performance.

*Washer Single Only

CL_Titan-C_22

Easy Programming

Intuitive programming controls allow operators to choose from a variety of functions and programs, including price, cycle time, cycle parameters, spin-speed and more, ensuring that all washing requirements are met.

CL_Titan-C_23

Easy Repair System

LG Commercial Laundry products are all front service accessible. Valuable service time will never be wasted gaining access to key service elements.

CL_Titan-C_24

Multilingual Readout

Our mission is to make customers happy and enjoy doing laundry with LG Commercial machines. Easy to read directions in multiple languages.

Category Measure Washer
(Non-Heater)
Washer
(Heater)
Dryer
(Gas)
Dryer
(Electric)
Drum
Volume
cu.ft (l) 3.6 (102.7) 3.6 (102.7) 7.3 (207) 7.3 (207)
Capacity lb (kg) 22.5 (13) 22.5 (10.2) 22.5 (10.2) 22.5(10.2)
Dimensions
(WxHxD)
in. (mm) 27x38.7x30.2
(686x983x767)
27x38.7x30.2
(686x983767)
27x38.7x30.1
(686x983x764)
27x38.7x30.1
(686x983x764)
Electric
Ratings
V/Hz/A 120/60/5
220~240/50/5
220~240/50/15~17.5 120/60/5
220~240/50/2.4
120(240)/60/26
220~240/50/22.5
Electric
Ratings
(Continuation)
V/Hz/A 220/60/5 - 220/60/3 220/60/21
240/50/19.5
Inverter
Direct Drive
Motor
- O O - -
Intelligent
Electronics
Controls
- O O O O
Heating
System
W 3,600 - O
Pricing
Program
- Special
Vended Price
Special
Vended Price
Special
Vended Price
Special
Vended Price
Category Measure Washer
(Non-Heater)
Dryer
(Gas)
Drum Volume cu.ft (l) 5.2 (147) 9.0 (254)
Capacity lb (kg) 35 (15) 30 (13.6)
Dimensions
(WxHxD)
in. (mm) 29x40.8x32
(737x1,036x814)
29x40.2x42.9
(737x1,022x1,090)
Electric Ratings V/Hz/A 120/60/5
220~240/50/5
220/60/5
120/60/10
Inverter Direct Drive Motor - O -
Intelligent Electronics Controls - O O
Heating System W 1,000
(Only for Tub Clean)
-
Drain System - Gravity Drain -
Pricing Program - Special Vended Price Special Vended Price
Emergency Stop Button - O (OPL Only) -
Auto Dosing Interface - O -
Damper - 4 Friction Dampers -
Category Measure Washer
(Non-Heater)
Washer
(Heater)
Dryer
(Gas)
Dryer
(Electric)
Wash Speed RPM 50 50 - -
Extract Speed
(High)
RPM 1,150 1,150 - -
G-force G 413 413 - -
Water Consumption gal (l) 13.4 (50.8) 13.4 (50.8) - -
Noise Level
(Sound Power)
dB Lower than 62 Lower than 62 - -
Program Duration in Minutes
(Default)
min 36 60
(60℃ Program)
- -
PCB Fuse - Main Control Board V/amps 220~240/8
120/12
220~240/8 - -
PCB Fuse - Filter Assembly amps 15 15 - -
Heating Type - - - Gas Electric
Type of Drying W - - Ventilation Ventilation
Air Flow CFM - - 160 160
Motor V/Hz/KW - - 120/60/0.4
220~240/50/0.3
220/60/0.4
120/60/0.4
220~240/50/0.3
220/60/0.4
Gas Ratings KW/BTU - - 5.8/20,000 -
Heating Element W - - - 5,400*
*4,500W for some countries due to power limitation (e.g. Australia)
Category Measure Washer
(Non-Heater)
Washer
(Heater)
Dryer
(Gas)
Dryer
(Electric)
Drum
Volume
cu.ft (l) 3.6 (102.7) 3.6 (102.7) 7.3 (207) 7.3 (207)
Capacity lb (kg) 22.5 (13) 22.5 (10.2) 22.5 (10.2) 22.5(10.2)
Dimensions
(WxHxD)
in. (mm) 27x38.7x30.2
(686x983x767)
27x38.7x30.2
(686x983767)
27x38.7x30.1
(686x983x764)
27x38.7x30.1
(686x983x764)
Electric
Ratings
V/Hz/A 120/60/5
220~240/50/5
220~240/50/15~17.5 120/60/5
220~240/50/2.4
120(240)/60/26
220~240/50/22.5
Electric
Ratings
(Continuation)
V/Hz/A 220/60/5 - 220/60/3 220/60/21
240/50/19.5
Inverter
Direct Drive
Motor
- O O - -
Intelligent
Electronics
Controls
- O O O O
Heating
System
W 3,600 - O
Pricing
Program
- Special
Vended Price
Special
Vended Price
Special
Vended Price
Special
Vended Price
  • Dimensions and weights are approximate.
  • Design, features and specifications subject to change without notice.
  • Some models may not be available for sales in certain countries.
