86UL3Q-E component-copyModelName
4K UHD Signage

Key Features

Choose your Size

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (86UL3Q-E)
    $
    $
    LG Members Price
Total
Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (86UL3Q-E)
    $
    $
    LG Members Price
Total
4K UHD Signage

LG webOS UHD Signage

LG webOS UHD Signage LG webOS UHD Signage
* All images in this page are for illustrative purposes only.
Superb Picture Quality with Ultra HD Resolution Superb Picture Quality with Ultra HD Resolution

Superb Picture Quality with Ultra HD Resolution

With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle provides clear contents.
High-Performance with LG webOS 6.1 High-Performance with LG webOS 6.1

High-Performance with LG webOS 6.1

LG webOS 6.1 is available on the UL3Q series for smooth execution of multiple tasks. The LG webOS smart signage platform enhances user convenience with an intuitive GUI*.
* GUI : Graphical User Interface
Easy Installation with Uniform Bezel Design Easy Installation with Uniform Bezel Design

Easy Installation with Uniform Bezel Design

The UL3Q series features perfectly balanced horizontal and vertical bezels, creating a visually harmonious display solution. Its specialized design simplifies installation in retail environments while delivering a truly immersive viewing experience. The sophisticated, symmetrical bezels enhance the aesthetic appeal of any space, transforming ordinary displays into elegant focal points.
Adaptive Viewing Experience Adaptive Viewing Experience

Adaptive Viewing Experience

Experience enhanced flexibility with the UL3Q's innovative Face Up/Down tilt support. Whether mounted high or low, each display can adjusted to better meet viewers at eye level, promoting maximum engagement regardless of installation height. This versatility optimizes both spatial efficiency and visual comfort, delivering clear information from various viewing angles.
* 76”/86” are not supported.
** This display tilts up/down up to 15 degrees; do not exceed this rangeto prevent damage.
Remote Monitoring and Control Remote Monitoring and Control

Remote Monitoring and Control

This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at anytime from their mobile phone & PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time.
Built-In Brightness Sensor Built-In Brightness Sensor

Built-In Brightness Sensor

The UL3Q's front-mounted sensor automatically adjusts brightness to match various lighting conditions, helping to optimize viewing quality and energy efficiency without manual intervention. This adaptive feature helps maintain consistent display performance while supporting power savings, delivering improved visual experience that responds to environmental changes.
Advanced Security Architecture Advanced Security Architecture

Advanced Security Architecture

The UL3Q incorporates LG’s Enhanced Kernel Protection (EKP) technology, safeguarding critical data from unauthorized access and potential security threats. This commitment to information security is validated by the ISO/IEC 15408 Common Criteria EAL2 certification, providing businesses with the confidence that their sensitive content and operations remain protected in today’s challenging security landscape.
Award-Winning Sustainability Award-Winning Sustainability

Award-Winning Sustainability

The UL3Q series embodies LG Display's ESG commitment: "Better Life for All." This company-wide dedication to environmental responsibility has earned the prestigious 2025 EcoVadis Platinum medal, placing us among the top 1% of global companies for sustainability excellence.
LG ConnectedCare LG ConnectedCare

LG ConnectedCare

Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, supporting the stable operation of clients' businesses.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
EPEAT Registered EPEAT Registered

EPEAT Registered

The Electronic Product Environmental Assessment Tool (EPEAT) is a method for several layers of customers to evaluate the effect of a product on the environment. UL3Q is EPEAT Bronze-certified* display which means that it meets all the required criteria in Computers and Displays category.
* Registered on May, 2025
Close
PANEL
  • Screen Size (Inch)
    86"
    Panel Technology
    ADS
  • Back Light Type
    Direct
    Aspect Ratio
    16:9
  • Native Resolution
    3,840 x 2,160 (4K UHD)
    Refresh Rate
    60 Hz
  • Brightness
    350 nits
    Contrast Ratio
    1,200:1
  • Dynamic CR
    1,000,000 : 1
    Color gamut
    DCI 80%
  • Viewing Angle (H x V)
    178 x 178
    Color Depth (Number of Colors)
    1.07 Billion Colors (Advanced 10 bit)
  • Response Time
    8m (G to G)
    Surface Treatment (Haze)
    1%
  • Life time
    30,000 Hrs
    Operation Hours (Hours/Day)
    16 / 7
  • Portait / Landscape
    Yes / Yes
MECHANICAL SPECIFICATION
  • Bezel Color
    Black
    Bezel Width
    12.9 mm (Even)
  • Weight (Head)
    31.8 kg
    Packed Weight
    42.6 kg
  • Monitor Dimensions (W x H x D)
    1,926.6 × 1,098 × 60 mm (Without IR)
    Carton Dimensions (W x H x D)
    2,080 × 220 × 1,255 mm
  • Carton Dimensions(W x H x D) with pallet
    1,950×1,266×285mm
    Handle
    NO
  • VESA Standard Mount Interface
    600 × 400 mm
ENVIRONMENT CONDITIONS
  • Operation Temperature
    0 °C to 40 °C
    Operation Humidity
    10 % to 80 %
POWER
  • Power Supply
    AC 100-240 V ~, 50/60 Hz
    Power Type
    Built-In Power
POWER CONSUMPTION
  • Typ.
    205 W
    Max.
    287 W
  • Smart Energy Saving (70%)
    143.5 W
    DPM
    0.5W
  • Power off
    0.5W
    BTU (British Thermal Unit)
    699.489 BTU/Hr (Typ.), 979.284 BTU/Hr (Max.)
CERTIFICATION
  • Safety
    CB
    EMC
    FCC Class "B" / CE
  • ePEAT(US only)
    Yes
    ErP / Energy Star
    No (NewErP) / Yes
OPS COMPATIBILITY
  • OPS Type Compatible
    No
    OPS Power Built-in
    No
SOFTWARE COMPATIBILITY
  • SuperSign CMS
    YES
    SuperSign Control+
    YES
  • SuperSign WB
    YES
    SuperSign Cloud
    YES
  • Mobile CMS
    YES
    Connected Care
    YES
SOUND
  • Speaker (Built-in)
    10 W × 2
LANGUAGE
  • OSD
    English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Türkiye, Arabic, Polski
ACCESSORY
  • Basic
    Remote Controller, Power Cord, Regulation Book, Easy Setup Guide, Warranty Card, Phone to D-Sub9 Gender
SPECIAL FEATURE
  • Conformal Coating (Power Board)
    YES
