THE WORLD'S FIRST 84 INCH LG ULTRA HD TV

  • 84LM9600

  • Discontinued Product

Key Features

  • ULTRA HD
  • 8.3 MEGAPIXELS
  • 84'' GIGANTIC SCREEN
  • 2.2 SPEAKER SYSTEM
Common Spec
Display Type LED Plus
Screen Size ( Inch ) 84
LCD Specification
Resolution 3840 x 2160
Frame Rate TruMotion 240 Hz
Dynamic Contrast Ratio 10M:1
Local Dimming Yes
Video
Triple XD Engine Yes
Aspect Ratio 6 modes( 16:9, Original, 4:3, 14:9, Zoom 1 Zoom 2)
Picture Mode 7 Modes(Intelligent sensor, Vivid, Standard, Cinema,Game, isf Expert1, isf Expert2)
Picture Wizard II (Customised Easy Self Callibration) Yes
AV Mode 3 Modes (Off / Cinema / Game)
Resolution Upscaler (Plus/Basic) Plus
Audio
Mono/Stereo/Dual (MTS/SAP) Yes/Yes/Yes
Audio Output (Watts - THD 10%) 10W x 2 + 15W Woofer x 2
Speaker System 3 Way 10 Speaker
Sound Mode 7 Mode (Music / Cinema / Sport / Game / Standard / Vivid / User setting)
Clear Voice II Yes
Mute Yes
Sound Optimizer 3 modes(Normal, Wall-Mount Type, Stand Type)
CINEMA 3D
3D Type (SG/FPR/AR/GPR/Non-Glass) FPR
Format Auto Detection Yes
3D to 2D Convert Source Yes
2D to 3D Convert Source Yes
3D Depth Control Yes
3D Viewpoint Control Yes
Dual Play/3d Yes
Smart TV
Home Dashboard 2.0 Yes
App Store Yes
Full Web Browser Yes
3D World (3D Contents Streaming) Yes
Smart Phone Remort Support Yes
Network
Wifi Ready
MHL Yes
Windows 7 Certified Yes
SIMPLINK (HDMI CEC) Yes
DLNA (Movie / Photo / Music) Yes
Media Link Yes
WiFi Display Yes
Special
Smart Energy Saving Yes
Intelligent Sensor Yes
Input Labeling Yes
Side Interface
HDMI/HDCP 1.4 (3D Auto Setting/ARC) 4
USB 2.0 3 (1: Hub)
Rear Interface
RF In Yes (1)
AV In 1 (Gender)
Component In (Y,Pb,Pr) + Audio 1 (Gender)
Digital Audio Out (Coaxial/ Optical) Yes (1)
PC Audio Input Yes (1)
LAN (Wired) Yes (1)
RGB In (D-sub 15pin) - PC Yes (1)
Power (W)
Voltage, Hz 100~240Vac 50-60Hz
Stand-by 0.3W ↓
Weight (Kg)
SET (w/o stand) 68.2
SET (w/ stand) 79.4
In Carton 94.5
