Certification
CE,FCC,ETL,CB
Controller
Embedded
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.56
Screen Resolution (WxH)
1,920x1,080
Module Dimensions (WxH, mm)
250 x 281.25
No. of Modules per Screen (WxH)
12 x 6 (Total 72)
Screen Dimension (W x H x D, mm)
3,004 × 1,692 × 36.5 (Thickest 70)
Screen Surface Area (㎡)
5.06
Screen Weight (kg)
132
Physical Pixel Density (pixels/m²)
409,600
Flatness of Unit Case (mm)
±0.2
Unit Case Material
Aluminum
Service Access
Front
Environment
RoHS, REACH
Min. Brightness (After Calibration)
500 nit
Color Temperature
3,200~9,300
Visual Viewing Angle (H × V)
160° x 160°
Brightness Uniformity
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/Screen, Max.)
1,700
Power Consumption (W/Screen, Avg.)
680
Power Consumption (W/m², Max.)
336
Power Consumption (BTU/h/Screen, Max.)
5,800
Power Consumption (BTU/h/Screen, Avg.)
2,321
Power Consumption (BTU/h/㎡, Max.)
1,146
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
2,880
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0°C to +40°C
Operating Humidity
10 ~ 80%RH
IP Rating Front
IP30
IP Rating Rear
IP20
Speaker
Built-in(9W+9W)
