Key Features

Brightness : 500cd/m²
Bezel : 0.9mm (T/B/L/R even bezel)
Depth : 86.2 mm
Interface : HDMI, DVI, RGB, IR, Daisy-chain (DP, RS232C, RJ45)

Inquiry to Buy

Add to Compare

component-OBScountrySelectDesc

Key Features

Brightness : 500cd/m²
Bezel : 0.9mm (T/B/L/R even bezel)
Depth : 86.2 mm
Interface : HDMI, DVI, RGB, IR, Daisy-chain (DP, RS232C, RJ45)

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

VM5C Series

Near Borderless Design

A near borderless design of 0.9mm even panel bezel and the 1.8mm BtB (Bezel to Bezel) size enables immersive and near seamless viewing experiences on assembled video wall screens.

Smart Platform

Built-in SoC* and Synced Playback

Built into this signage display is a Quad-Core processor. This is the engine behind the webOS display platform that allows fast loading of apps and menus, as well as multi-tasking between apps. This results in quick access to content and smooth playback.

*Soc: System-on-Chip.

Smart Platform

webOS 2.0

The webOS 2.0 platform provides powerful and convenient tools to create, including app development materials.

Superior Picture Quality

Clear Viewing Angle

The VM5C panels allow you to enjoy fantastic picture quality with less variation from wider viewing angles. Featuring consistent colour temperature and less change in contrast, LG IPS panels boast excellent image reproduction.

Superior Picture Quality

Uniform Brightness

LG has improved backlight brightness uniformity by reducing the shadowing effect on the screen edge. This provides the new VM5C panels with greater visibility and consistent brightness across the screen.

Superior Picture Quality

Image Gap Reduction

The VM5C includes an image improvement algorithm that can adjust to objects located in the boundary of the bezel for a more seamless viewing experience.

Enhanced Content Management

LAN Daisy Chain Performance
A LAN daisy chain allows you to execute commands to control and monitor the screens and even update their firmware.

Convenient Options

Guide Bracket / Classified Port

A guide bracket is an attachment that ensures the video wall remains flat. The classified in/out port helps prevent errors when connecting a daisy chain.

Convenient Options

Control Buttons

With 8 control buttons, it's easy to operate various functions of the 49VM5C, such as controlling the OSD (On Screen Display) and changing the input source.

PANEL

Screen Size

49” (123 cm)

Panel Technology

IPS
Aspect Ratio

16 : 9

Native Resolution

1,920 x 1,080 (FHD)
Brightness

500 cd/m²

Contrast Ratio

1,300:1
Viewing Angle (H x V)

178° x 178°

Guaranteed Operating Hour

24 hrs / 7 days

CONNECTIVITY

Input

HDMI, DP, DVI-D, OPS, Audio, USB3.0, USB 2.0, RGB

Output

DP, Audio
External Control

RS232C, RJ45, IR Receiver

PHYSICAL SPECIFICATION

Bezel Width

0.9 mm (Even bezel) / Bezel to Bezel: 1.8 mm

Monitor Dimension (W x H x D)

1,075.6 x 605.8 x 86.2 mm
Weight (Head)

17.5 kg

Carton Dimensions (W x H x D)

1,214 x 775 x 263 mm
Packed Weight

23.2 kg

VESA™ Standard Mount Interface

600 x 400 mm

ENVIRONMENT

Operation Temperature Range

0°C to 40°C

Operation Humidity Range

10% to 80%

POWER

Power Supply

100-240V~, 50/60Hz

Power Consumption (Typical)

120W
Power Consumption (Smart Energy Saving)

70W

STANDARD(CERTIFICATION)

Safety

AS/NZS 60950, CB Scheme

EMC

AS/NZS CISPR32, RCM (Class A)
Energy Rating (EPA)

Energy Star 7.0

MEDIA PLAYER COMPATIBILITY

OPS Type Compatible

Yes

External Media Player Attachable

Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

SuperSign Premium

Yes

SuperSign C

Yes

ACCESSORIES

Basic

Remote Controller, Power Cable, DP Cable, Manual, IR receiver, RS-232C Cable, LAN Cable, Guide Bracket, Screws

Optional

Wall Mount (Landscape: WM-L640V, Portrait: WMP640V), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
