webOS Box

webOS Box

All Spec

CONNECTIVITY

  • Input

    HDMI (2), DP, USB 2.0 (2)

  • Output

    HDMI, DP(Daisy chain only)

  • External Control

    RS232C In/out, RJ45 In, IR In

MECHANICAL SPECIFICATION

  • Player Dimension (W x H x D)

    258 × 36.5 × 186 mm

  • Weight (Head)

    0.87 kg

  • Carton Dimensions (W × H × D)

    359 x 124 x 314 mm

  • Packed Weight

    1.77 kg

KEY FEATURE(HARDWARE)

  • KEY FEATURE (HARDWARE)

    Internal Memory 8GB (System 4GB, Available 4GB), Wi-Fi Built-in, Thermal Sensor, Power Indicator, Local Key Operation

KEY FEATURE(SOFTWARE)

  • webOS ver.

    webOS 4.0

  • Embedded CMS

    Local Contents Scheduling, Group Manager

  • Fail Over

    Yes

  • Background Image

    No Signal Image

  • Multi-screen

    PIP/PBP(4)

  • Screen Share

    Yes

  • Video Tag

    Yes (4)

  • Play via URL

    Yes

  • Rotation

    Yes (Screen Rotation, External Input Rotation)

  • Gapless Playback

    Yes

  • Tile Mode Setting

    Yes (Max. 15x15)

  • Setting Data Cloning

    Yes (RS-232C, Network, USB)

  • SNMP

    Yes

  • ISM Mode(Image Sticking Minimization)

    Yes

  • Status Mailing

    Yes

  • Power Mgmt.

    Wake on LAN

  • Beacon

    Yes

  • HDMI-CEC

    Yes *Compatibility may differ by equipment.

  • SI Server Setting

    Yes

  • webRTC

    Yes

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10% to 80%

POWER

  • Power Supply

    AC 100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ./Max

    23 W / 27 W

CERTIFICATION

  • Safety

    CB/ NRTL

  • EMC

    FCC Class "A"/CE

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign CMS

  • Control and Monitoring Software

    SuperSign Control/Control+

ACCESSORY

  • Basic

    Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

To access more technical documentation and resources, please visit the LG B2B partner portal.
