Screen Size
49" (123cm)
Panel Technology
IPS
Aspect Ratio
16:9
Resolution
1,920 x 1,080 (FHD), M+ (WRGB)
Brightness
3000cd/m² (Typ.) through front protective glass
Viewing Angle (H x V)
178 x 178
Response Time
8 ms (G to G BW, Typ.)
Surface Treatment
AGLR (Haze 3%), QWP
QWP Polarizer
Yes
Life time
50,000 Hrs
Operation Hours
24Hrs
Orientation
Portrait only
Input
HDMI, DP, DVI-D, Audio In, USB 3.0
Output
DP, External Speaker out
External Control
RS232C In/out, RJ45 In
Front glass
6.8 mm (AR, Laminate Safety Vandal Glass)
Bezel Colour
Black
Bezel Width
103.0 mm (T), 262.0 mm (B), 46.5 mm (L/R)
Monitor Dimension (W x H x D)
701 x 1,445 x 179 mm
Weight (head)
58.6 kg
Packing Dimensions (W x H x D)
863 x 1,624 x 333 mm
Packed Weight
73.4 kg
Special features
Temperature Sensor, Auto Brightness Sensor, Pixel Sensor, Cooling FAN, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory 8GB (System 4GB + Available 4GB), USB Cloning, Easy Brightness Control, Wake on LAN, Fail Over, DP Daisy Chain, Control Manager
Operation Temperature
-30°C to 50°C
Operation Humidity
5% to 100%
Dust / Water Proofing
IP56
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Consumption (Typ./Max)
270 W / 400 W
Power Consumption (Smart Energy Saving)
145 W
Safety
AS/NZS 60950,CB Scheme
EMC
AS/NZS CISPR32,RCM(Class A)
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Basic
Remote Controller, Manual (EIG, ESG), Regulation Book, Phone to RS232C Gender, USB Cable, HDMI Cable
Optional
Enclosure Stand (ST-491X, ST-493X), Circuit Breaker & Surge Suppressor (KT-PS)
