Open Frame

Features

Gallery

Specs

Support

Resource

Find a dealer

Contact Us

Open Frame

Share this content.

You can share the items you like with your friends

Open Frame

55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
  • LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B
LG Open Frame, 55XF3E-B

Key Features

  • Real-Time Remote Monitoring
  • Saving System Log Files
  • Smart Brightness Control
  • Slimmer Depth
More
High Brightness1
Outstanding Visibility

High Brightness

The high brightness outdoor display maintains high picture quality and image readability in an outdoor environment even when used for continuous business use (24/7).
Visible with Polarised Sunglasses1
Outstanding Visibility

Visible with Polarised Sunglasses

QWP* enables clear visibility even when the viewer is wearing polarised sunglasses.

*Quarter Wave Plate

Reduced Blackening1
Outstanding Visibility

Reduced Blackening

Even under direct sunlight exposure, this LG display is resistant to blackening effects and provides quality images for outdoor usage.
Smart Brightness Control1
Outstanding Visibility

Smart Brightness Control

The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
High Operating Temperature1
Product Reliability

High Operating Temperature

Even under high operating temperatures of up to 50°C, it presents clearer images without hot spots.
Conformal Coating1
Product Reliability

Conformal Coating

The XF3C signage have been designed with the LG Conformal Coating to provide additional protection to circuit boards in harsh environments such as dust and humidity.
High-Performance with webOS Smart Platform1
Easy Maintenance

High-Performance with webOS Smart Platform

Quad Core SoC* can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app develoment tools.

*SoC = System on Chip
Space Efficiency1
Easy Maintanance

Space Efficiency

The slim depth saves space for installation and makes the enclosure design slimmer.

Key Feature

  • Real-Time Remote Monitoring
  • Saving System Log Files
  • Smart Brightness Control
  • Slimmer Depth
Print

All Spec

PANEL

  • Screen Size (Inch)

    55

  • Panel Technology

    IPS / M+

  • Back Light Type

    Direct

  • Aspect Ratio

    16:9

  • Native Resolution

    1920 x 1080 (FHD)

  • Refresh Rate

    60Hz

  • Brightness

    3,000nit (Typ.), 2,400nit (Min.)

  • Contrast Ratio

    1,300:1

  • Dynamic CR

    500,000:1

  • Color Gamut

    NTSC 67%

  • Viewing Angle (H x V)

    178º x 178º

  • Color Depth (Number of Colors)

    16.7 Million colors

  • Response Time

    8ms (G to G)

  • Surface Treatment (Haze)

    Haze 3%

  • Life time

    50,000Hrs (Typ.)

  • Operation Hours (Hours/Day)

    24/7

  • Portait / Landscape

    YES / YES

  • Transparency

    N/A

  • QWP (Quarter Wave Plate)

    YES

CONNECTIVITY

  • HDMI In

    YES (2ea)

  • HDMI In (HDCP Ver.)

    2.2

  • DP In

    YES (HDCP 1.3)

  • DVI-D In

    YES

  • RGB In

    NO

  • Audio In

    YES

  • RS232C In

    YES

  • RJ45(LAN) In

    YES (1ea)

  • IR In

    YES

  • USB In

    USB2.0 Type A (1ea)

  • HDMI Out

    NO

  • DP Out

    YES

  • Audio Out

    NO

  • Touch USB

    NO

  • External Speaker Out

    YES

  • RS232C Out

    YES

  • RJ45(LAN) Out

    NO

  • IR Out

    NO

  • Daisy Chain

    NO

MECHANICAL SPECIFICATION

  • Bezel Color

    Black

  • Bezel Width

    T/R/L/B : 12/9.9/9.9/12mm

  • Weight (Head)

    26.5Kg

  • Weight (Head+Stand)

    N/A

  • Packed Weight

    32.25Kg

  • Monitor Dimensions (W x H x D)

    1235.5 x 709.4 x 106.8mm

  • Monitor Dimension with Stand (W x H x D)

    N/A

  • Carton Dimensions (W x H x D)

    1344 x 820 x 236mm

  • Handle

    NO

  • VESA Standard Mount Interface

    600 x 400 mm

PROTECTION GLASS

  • Thickness

    N/A

  • Degree of Protection

    N/A

  • Tempered / Chemical strengthening

    N/A

  • Anti-Reflective

    N/A

  • Infrared - Resistance (IR)

    N/A

  • Shatter-Proof

    N/A

FEATURE - HARDWARE

  • Internal Memory (eMMC)

    8GB

  • Wi-Fi/BT (Built-in)

    NO

  • Temperature Sensor

    YES

  • Auto Brightness Sensor

    YES

  • Pixel Sensor

    NO

  • Proximity Sensor

    NO

  • Current Sensor

    NO

  • BLU Sensor

    NO

  • Humidity Sensor

    YES

  • Acceleration(Gyro) Sensor

    NO

  • Power Indicator

    YES

  • Local Key Operation

    NO

  • FAN (Built-in)

    YES

FEATURE - SOFTWARE

  • OS Ver. (webOS)

    webOS 3.0

  • Local Contents Scheduling

    YES

  • Group Manager

    NO

  • USB Plug & Play

    YES

  • Fail over

    YES

  • Booting Logo Image

    YES

  • No Signal Image

    NO

  • RS232C Sync

    YES

  • Local Network Sync

    YES

  • Backlight Sync

    YES

  • PIP

    NO

  • PBP

    NO

  • Screen Share

    NO

  • Video Tag

    YES (2 Video Tag)

  • Play via URL

    NO

  • Screen Rotation

    YES

  • External Input Rotation

    YES

  • Gapless Playback

    YES

  • Tile Mode Setting

    YES

  • Setting Data Cloning

    YES

  • SNMP

    YES

  • ISM Method

    YES

  • Auto Set ID

    YES

  • Status Mailing

    YES

  • Control Manager

    YES

  • Cisco Certification

    NO

  • Crestron Connected

    NO

  • Smart Energy Saving

    YES

  • PM mode

    YES

  • Wake on LAN

    YES

  • Network Ready

    NO

  • Beacon

    YES

  • HDMI-CEC

    YES

  • SI Server Setting

    YES

  • webRTC

    NO

  • Pro:Idiom

    NO

  • Brightness Compensation

    NO

  • W/B Setting by Grey scale

    NO

  • Scan Inversion

    NO

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0 °C to 50 °C (w/o Direct Sunlight, Direct Sunlight in Cooling System) 0 °C to 40 °C (Direct Sunlight)

  • Operation Humidity

    10 % to 80 %

POWER

  • Power Supply

    AC 100-240V~, 50/60Hz

  • Power Type

    Built-in Power

POWER CONSUMPTION

  • Typ.

    250W (Full White) 230W (IEC 62087)

  • Max.

    300W

  • BTU (British Thermal Unit)

    853 BTU/Hr(Typ.), 1024 BTU/Hr(Max.)

  • DPM

    0.5W(DP, DVI-D, HDMI)

  • Power off

    0.5W

SOUND

  • Speaker (Built-in)

    NO

CERTIFICATION

  • Safety

    IEC 60950-1 / EN 60950-1 / UL 60950-1

  • EMC

    FCC Class "A" / CE / KC

  • ERP / Energy Star

    NO / NO

  • ePEAT(US only)

    NO

OPS COMPATIBILITY

  • OPS Type compatible

    NO

  • OPS Power Built-in

    NO

SOFTWARE COMPATIBILITY

  • SuperSign CMS

    YES

  • SuperSign Control+

    YES

  • SuperSign WB

    NO

  • SuperSign Cloud

    NO

  • Promota

    NO

  • Mobile CMS

    NO

  • Connected Care

    YES

LANGUAGE

  • OSD

    English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic

ACCESSORY

  • Basic

    Remote Controller(including battery 2ea), Power Cord, HDMI Cable, IR Extension Kit, Manual (ESG&EIG)

  • Optional

    AN-WF500 (Stand is not available)

SPECIAL FEATURE

  • Overlay Touch Compatibility

    N/A

  • Smart Calibration

    N/A

  • Tilt (Face up)

    N/A

  • Tilt (Face down)

    N/A

  • IP Rating

    N/A

  • Conformal Coating (Power Board)

    YES

  • Power Protection

    N/A

  • Direct Sunlight

    YES

DEDICATED FEATURE - TOUCH

  • Available Object Size for Touch

    N/A

  • Response Time ('Paint' app on Windows 10 PC)

    N/A

  • Accuracy (Typ.)

    N/A

  • Interface

    N/A

  • Protection Glass Thickness

    N/A

  • Protection Glass Transmission

    N/A

  • Operating System Support

    N/A

  • Multi Touch Point

    N/A

To access more technical documentation and resources, please visit the LG B2B partner portal.
