Screen Size
86" (217cm)
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
3,840 x 2,160 (UHD)
Brightness
500cd/m²
Contrast Ratio
1,200:1
Dynamic CR
4,000,000:1 (DTV Label only)
Viewing Angle (H x V)
178° x 178°
Response Time
8ms (G to G)
Surface Treatment
Low Haze 3%
Life Time
50,000 Hrs
Operating Hours
24 Hrs
Orientation
Portrait and Landscape
Input
HDMI, DP, DVI-D, Audio, USB 3.0, SD Card
Output
DP, Audio
External Control
RS-232C, RJ45, IR Receiver, Pixel Sensor
Bezel Colour
Black
Bezel Width
14.7mm
Monitor Dimension (W x H x D)
1,926.2 x 1,097.2 x 61mm (without logo / handle)
Weight (head)
49kg
Carton Dimensions(W × H × D)
2,073 x 1,260 x 292mm
Packed Weight
61.1kg
VESA™ Standard Mount Interface
600 x 400mm
Additional
Temperature Sensor, Auto Brightness Sensor, Tile Mode (up to 15x15), Natural Mode@Tile Mode, ISM Method, Internal Memory (8GB, System 4GB), Wi-Fi built-in (802.11n), USB Cloning, Content Scheduling, Sync mode, PM mode, Fail Over, Wake on LAN, BEACON (On/Off), Embedded Template, PIP/PBP (2/3/4)
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built In Power
Power Consumption (Typ.)
275W
Power Consumption (Smart Energy Saving)
193W
Safety
AS/NZS 60950, CB Scheme
EMC
AS/NZS CISPR 22, RCM (Class A)
Energy Rating
N/A
OPS type compatible
Yes
External Media Player Attachable
Yes (MP500 / MP700)
SuperSign W/Lite
Yes
SuperSign C
Yes
Accessory
Remote Controller (include battery 2ea), Power Cord, QSG, DP cable (2.6M), Regulation Book, Phone to RS-232C Gender, Memory Cover
Optional
Pixel Sensor (KT-SP0), Media Player, OPS Kit (KT-OPSA), HDBaseT (EB-B100)
