GSCD Ultra Light Series
Certification
CE,FCC,ETL
Environment
RoHS
Pixel Configuration
3 in 1 SMD
Pixel Pitch
10.41
Module Resolution(WxH)
48x24
Module Dimensions(WxH,mm)
500x250mm
Weight per Module(Kg)
1.3
No. of Modules per Unit Case(WxH)
2x4
Unit Case Resolution(WxH)
96x96
Unit Case Dimensions(WxHxD, mm)
1000x1000x86
Unit Case Surface Area(m²)
1
Weight per Unit Case(kg/unit)
19
Weight per Square Meter(Kg/m²)
19
Physical Pixel Density(Pixels/m²)
9,216
Unit Case material
Aluminum Profile
Service access
Front or Rear (Select one Only)
Min. Brightness(After Calibration)
5000 cd/m²
Colour Temperature
6500
Visual Viewing Angle(Horizontal)
160
Visual View Angel(Vertical)
136
Brightness Uniformity
97%
Colour Uniformity
±0.003CxCy
Contrast Ratio
10,000
Processing Depth(bit)
14
Frame Rate(Hz)
50/60
Refresh Rate(Hz)
3,840
Power Consumption(W/Unit, Max)
650
Power Consumption(W/Unit, Avg)
216
Power Consumption(W/m²) Max
650
Power Supply(V)
100 to 240
Input
HDMI, Single- link DVI, Audio Input
Output
4 x RJ45 ,HDMI- Loop, DVI- Loop
Control
RJ45 , USB In/Out
Power
AC-100-240V-50/60HZ
Life time (Half Brightness)
100,000
Operating Temperature(℃)
-20℃ to +50℃
Operating Humidity
10~99%RH
IP Rating Front
IP65
IP Rating Rear
IP65
