3D Blu-ray Disc Playback & M-DISC™ Support

  • BU20N

Key Features

  • Silent Play: Reduces Noise from Disc Spin During Movie Playback
  • Supports 3D Blu-ray Disc Playback
  • Supports BDXL (100GB Triple Layer) Disc
  • Jamless Play: Smooths Out Playback of Damaged Blu-ray or DVD Discs
SUSTAINED TRANSFER RATE
CD-ROM 3.6 MB/s (24x) max.
BD-ROM 26.97 MB/s (6x) max.
DVD-ROM 11.08 Mbytes/s (8x) max.
SUMMARY
Drive Type Internal
TRANSFER RATES - WRITE (MAX)
Type Ultra Slim Blu-ray / DVD Writer
BD-R(DL) 2x CLV, 4x PCAV, 6x CAV
BD-RE (SL/DL/TL) 2x CLV
CD-R 10x CLV, 16x PCAV, 24x CAV
CD-RW 4x, 10x CLV, 16x ZCLV
DVD-R (SL) 2x CLV, 4x PCAV, 8x CAV
DVD+R (DL) 2.4x CLV, 6x ZCLV
DVD+RW 2.4x, 3.3x CLV, 4x, 6x, 8x ZCLV
DVD+R (SL) 2.4x CLV, 4x PCAV, 8x CAV
DVD-R (DL) 2x CLV, 4x, 6x ZCLV
DVD-RAM 2x, 3x CLV, 5x PCAV
M-Disc DVD(DVD+R) 4x PCAV
DVD-RW 2x, 3x CLV, 4x, 6x ZCLV
BD-R (SL/LTH) 2x CLV, 4x PCAV, 6x CAV
BD-R (TL) 2x CLV, 4x PCAV
BD-R (SL) 2x CLV, 4x PCAV, 6x CAV
BD-R(QL) 2x CLV, 4x PCAV
M-DISC BD (BD-R) 2x CLV, 4x PCAV
HOST INTERFACE
Internal (Drive) SATA
COMPLIANCE
RoHS Yes
Safety UL UL 60950-1 Second Edition
C-UL CSA C222 No. 60950-1 Second Edition
TÜV EN 60950-1 / EN60825-1
SEMKO EN 60950-1 / EN60825-1
Laser Safety Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-q/IEC 60825-1
EMC CE Marking, C-Tick Mark, BSMI, FCCI, KC, CU, FCC Part 15 Class B Digital Device, ICES-003 Digital Apparantus
SYSTEM REQUIREMENTS
CPU Intel@ Pentium D 3.2GHz or Higher (with USB 2.0)
Recommended CPU Intel Core 2 Duo P8600 2.4GHz or higher
RAM 1GB or Higher
HDD 30GB or more of available space (60GB for Blu-ray Disc authoring)
BD Movie Playback: CPU Following CPU recommended -Intel: E6400 or higher
Graphic Card- nVidia GeForce 7600GT or higher / GeForce 8400 or higher. Graphic Card Driver shall meet AACS compliance criteria.
Graphic Card- ATI ATI Radeon HD 2400 or higher Graphic Card Driver shall meet AACS compliance criteria.
TRANSFER RATES - READ (MAX)
DVD-RW 8x CAV
DVD-Video (CSS Compliant Disc) (SL/DL) 8x CAV
DVD-ROM (SL/DL) 8x CAV
DVD-RAM 2x, 3x CLV, 5x PCAV
DVD-R (SL/DL) 8x CAV
DVD+RW 8x CAV
DVD+R (SL/DL) 8x CAV
CD-R/RW/ROM 24x/24x/24xCAV
CD-DA 24x CAV
BD-ROM (SL/DL) 6x CAV
BD-R (SL/DL) 6x CAV
BD-R (TL/QL) 6x CAV
BD-R (SL/LTH) 6x CAV
BD-RE (SL/DL) 6x CAV
BD-RE (TL) 4x PCAV
BDMV (AACS Compliant Disc) (SL/DL) 6x CAV
OTHER FEATURES
Other Features Silent Play, Jamless Play
ACCESS TIME (1/3 STROKE)
DVD-ROM 200ms typ.
BD-ROM 250ms typ.
CD-ROM 200ms typ.
BUFFER SIZE
Buffer Size 4MB Buffer Under-run prevention function embedded
OPERATING SYSTEMS
Operating Systems Windows 8.1, Windows 8, Windows 7, Windows Vista, Windows XP
DIMENSIONS (W xH xD)
Dimensions (WxHxD) 5.0"x0.3"x5.0"(128x9.5x127mm)
WEIGHT
Weight 122 +/-10g (Without Bezel)
WARRANTY/UPC
UPC 058231312591

What People Are Saying

  • bvseo_sdk, java_sdk, bvseo-2.3.0.0
  • CLOUD, getReviews, 4ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

We're here to support you with our product.

View BU20N Product Support

Contact us for any support inquiries.

ASK & ANSWER

Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

I purchased 3d blu-ray playback slim portable blu-ray writer. The box does NOT say windows 10. Does it work with window 10? how do I make it work?

Asked by: GMP1
I have it in my MSI laptop. Windows 10. Works fine.
Answered by: noahphense
Date published: 2017-02-05

I need to know what software to buy to make it work

Asked by: Staggerwing58
We appreciate your interest in this Optical Drive. The software recommended by the manufacturer is the CYBERLINK software, which should have come with the drive itself. For additional information or assistance, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2016-11-10

Hi, noticed that the write specs do not include BD-RW on the BU20N Blu-ray player; the specs only show BD-R. What is the difference between BD-R and BD-RW? Thanks!

Asked by: PaniBasia
BD-R is read only BD-RW is read writable
Answered by: Staggerwing58
Date published: 2016-11-06

Hello, What type of playback or write software is compatible with this slim drive?

Asked by: touKS
LER O AUDIO DTS
Answered by: JARBAS
Date published: 2016-10-08

Adapter to fit two of these into a single 5.25" bay ?

Asked by: Bob357
