3D Blu-ray Disc Playback & M-DISC™ Support

  • CU20N

Key Features

  • Silent Play: Reduces Noise from Disc Spin During Movie Playback
  • Supports 3D Blu-ray Disc Playback
  • Supports BDXL (100GB Triple Layer) Disc
  • Jamless Play: Smooths Out Playback of Damaged Blu-ray or DVD Discs
SUMMARY
Drive Type Internal
SUSTAINED TRANSFER RATE
CD-ROM 3.6 MB/s (24x)
BD-ROM 26.97 MB/s (6x)
DVD-ROM 11.08 MB/s (8x)
CONTENTS
Ultra Slim BD-ROM / DVD Writer Yes
OPERATING SYSTEMS
OPERATING SYSTEMS Windows 8.1, Windows 8, Windows 7, Windows Vista, Windows XP
OTHER FEATURES
Jamless Play Yes
Silent Play Yes
BUFFER SIZE
BUFFER SIZE 4 MB (Buffer Under-run prevention function embedded)
TRANSFER RATES - WRITE (MAX)
Type Ultra Slim BD-ROM / DVD Writer
CD-R 10x CLV, 16x PCAV, 24x CAV
CD-RW 4x, 10x CLV, 16x ZCLV
DVD-R (SL) 2x CLV, 4x PCAV, 8x CAV
DVD+R (DL) 2.4x CLV, 6x ZCLV
DVD+RW 2.4x, 3.3x CLV, 4x, 6x, 8x ZCLV
DVD+R (SL) 2.4x CLV, 4x PCAV, 8x CAV
DVD-R (DL) 2x CLV, 4x, 6x ZCLV
DVD-RAM 2x, 3x CLV, 5x PCAV
M-DISCDVD(DVD+RSL) 4x PCAV
DVD-RW 2x, 3x CLV, 4x, 6x ZCLV
HOST INTERFACE
Internal (Drive) SATA
COMPLIANCE
RoHS Yes
Safety UL UL 60950-1 Second Edition
C-UL CSA C222 No. 60950-1 Second Edition
TÜV EN 60950-1 / EN60825-1
SEMKO EN 60950-1 / EN60825-1
Laser Safety Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-q/IEC 60825-1
EMC CE Marking, C-Tick Mark, BSMI, FCCI, KC, CU, FCC Part 15 Class B Digital Device, ICES-003 Digital Apparantus
SYSTEM REQUIREMENTS
CPU Intel® Pentium® D 3.2GHz or Higher (with USB 2.0)
Recommended CPU Intel Core 2 Duo P8600 2.4GHz or higher
RAM 1GB or Higher
HDD 30GB or more of available space
BD Movie Playback: CPU Following CPU recommended -Intel: E6400 or higher
Graphic Card: Card recommended with following GPU (Graphic Processing Unit) - ATI ATI Radeon HD 2400 or higher Graphic Card Driver shall meet AACS compliance criteria.
Graphic Card- nVidia GeForce 7600GT or higher / GeForce 8400 or higher. Graphic Card Driver shall meet AACS compliance criteria.
TRANSFER RATES - READ (MAX)
DVD-RW 8x CAV
DVD-Video (CSS Compliant Disc) (SL/DL) 8x CAV
DVD-ROM (SL/DL) 8x CAV
DVD-RAM 2x, 3x CLV, 5x PCAV
DVD-R (SL/DL) 8x CAV
DVD+RW 8x CAV
DVD+R (SL/DL) 8x CAV
CD-R/RW/ROM 24x/24x/24xCAV
CD-DA 24x CAV
BD-ROM (SL/DL) 6x CAV
BD-R (SL/DL) 6x CAV
BD-R (TL/QL) 6x CAV
BD-R (SL/LTH) 6x CAV
BD-RE (SL/DL) 6x CAV
BD-RE (TL) 4x PCAV
BDMV (AACS Compliant Disc) (SL/DL) 6x CAV
ACCESS TIME (RANDOM)
CD-ROM 200 ms typ.
BD-ROM 250 ms typ.
DVD-ROM 200 ms typ.
TYPE
Internal Yes
DIMENSIONS (W x H x D)
Dimensions (WxHxD) 5.0" x 0.5" x 5.0" (128 x 9.5 x 127 mm)
WEIGHT
Weight 122 +/-10g (Without Bezel)
WARRANTY/UPC
UPC 058231312881
