24 cu.ft. Largest Capacity 33” Wide Top-Mount

  • LTCS24223S

  • Stainless Steel

Key Features

  • 24 cu.ft.
  • Contoured Doors with Pocket Handles
  • Full Width Pantry Drawer
  • Factory Installed Ice Maker
Largest Capacity*

Largest Capacity*

This top-mount refrigerator has the largest capacity in the 33” wide category, featuring 24 cu. ft. of total storage space in the refrigerator and freezer.

Keep it crisp.

Keep it crisp.

Humidity-controlled crispers help maintain humidity levels, to help extend the life of your fruits and vegetables. This refrigerator also features a full-width Glide-N-Serve™ pantry drawer, making it easy to find some space for all that food you want to keep fresh.

Great Light.

Great Light.

LED panels in the refrigerator provide an exceptionally bright interior and saves energy over traditional lighting.

Sophisticated style and Design.

Sophisticated style and Design.

Contoured doors, hidden hinges, and a host of great interior features like LED lighting give your refrigerator a look as sophisticated as it is functional.

Cold as ice.

Cold as ice.

An automatic ice maker means you'll always have ice on hand.

SUMMARY
Door Type Top Mount Freezer
CAPACITY
Refrigerator 17.6 cu. ft.
Freezer 6.2 cu. ft.
Total 23.8 cu. ft.
FEATURES
ENERGY STAR® Qualified Yes (501 kWh/Year)
Temperature Sensors Yes
Temperature Controls Electronic
LoDecibel™ Quiet Operation Yes
Freezer Door Type Top Swing Door
Display Internal Membrane / Green LED
REFRIGERATOR
No. of Shelves 2 Full
Shelf Construction Tempered Glass
Crisper Bins 2 Humidity Crispers
Full Width Pantry Drawer Yes
Gallon Storage 2 Gallons
Refrigerator Light Premium LED
Daily Ice Production 3.7 lbs
Ice Storage Capacity 5.5 lbs
Multi-Air Flow Cooling Yes
Temperature Sensors 4
Compressor Type Inverter
Full Snack Tray/2 Bottle Guides Yes
REFRIGERATOR DOOR
Dairy Bin 1
No. of Door Bins 3 (2 Gallon Sized)
Tall Item Retainer Yes
FREEZER
Ice Maker Yes
Ice Bin Yes
No. of Shelves 1
Shelf Construction Tempered Glass
Freezer Light Premium LED
No. of Door Bins/Shelves 2
Auto Defrost Yes
MATERIALS AND FINISHES
Contour Door Yes
Reversible Doors Yes
Surface Coated Metal, Stainless Steel
Back Flush & Metal Cover Over Mechanical Parts
Available Colors Stainless Steel (S), Smooth White (W), Smooth Black (B)
SPECIFICATIONS
Dimensions (W case x H top of hinge x D with handles) 32 3/4" x 68 1/2" x 33 3/8"
Depth including Door 33 3/8"
Depth without Door 29"
Depth (Total with Door Open) 63"
Height to Top of Case 67 7/8"
Height to Top of Door Hinge 68 1/2"
Width 32 3/4"
Installation Clearance 2"
Weight (Unit/Carton) 224 lbs./248 lbs.
Carton Dimensions (WxHxD) 34 4/5" x 71 3/7" x 38 1/7"
RATINGS
Amps 20 Amp
Requirements 120V, 60Hz, 15 Amp
UL Listed Yes
Energy Consumption 438kWh
WARRANTY
Limited Warranty 1 Year Parts and Labor, 7 Years on the Sealed System
UPC 048231 786553

What People Are Saying

Rated 5 out of 5 by from Excellent Refrigerator Our refrigerator died 2 weeks before Christmas and we had to purchase one. My husband knew he wanted an LG model. We initially had every intention of purchasing a model with the freezer on the bottom. However, once I saw I did not like. As soon as I saw this model I knew it was what I wanted. I love this refrigerator, very large capacity and the middle draw is a great feature. I put whole cookie trays in on a couple of shelves and still had plenty of room. I say it all the time to my husband that I love my new refrigerator and it is the best purchase we have made in a long time. Next I plan to replace my stove and dish washer with LG Stainless steel models.
Date published: 2016-02-05
Rated 5 out of 5 by from Great Stainless Great clean design stainless. No ugly handles. Great LED lighting. Easy to clean. Quite and efficient. Looks and performs great.
Date published: 2016-02-02
Rated 5 out of 5 by from great room more storage than bigger side by sides i have - lights in door are great
Date published: 2016-01-31
Rated 5 out of 5 by from Very nice!!! We've only had this for a few days. Lots of room & very quiet. I do agree with the person who said the lighting could be better. There needs to be a little more light on top or lights in the back. The light in the freezer area is nice didn't have that in our old one. Do wish it was smudge proof. But a towel takes the finger prints right off-make sure you go with the grain so you don't scratch it.
Date published: 2016-01-12
Rated 4 out of 5 by from The No handle Feature very Sleek I Just had it delivered 3 days after Christmas, and Overall I'm happy with the overall Roomy features, for gallons of milk on the door etc, BUT do not overload the door more then 2 gallons or so, because the door seems to close a little on the rattle side instead of smooth possibly because of the weight I'm loading on the door ? I will call LG and ask if that's the problem ? The other Negative, that LG needs to correct on this Nice Refrig, is the Sleek LED lighting on the front sides of the Refrig< BUT what about the rest of the interior background of the refrig? Its a little too Dim in the rest of the refrigerator, to be honest. The engineering builders should have placed some more LED lighting in the background of the refrig. which is lacking light.
Date published: 2016-01-05
Rated 4 out of 5 by from Great interior space Here are the positives: Holds a lot. Love the big pantry drawer. Quiet. The negatives are: Lightning. The L.E.D. lights are nice but there needs to a strip on the ceiling of the refrigerator. The back of the top shelf is dark and they need to move the light strips on the sides down to give coverage to the bottom shelf. Here's a tip for those who are experiencing a plastic smell and taste from their ice. Do not turn the ice maker off when the bucket is full. The water sits to long in the plastic line and picks up the odor and taste. I dump my ice out before bedtime and there is a good amount in there by morning. Hopefully this problem will disappear in a couple of months. Overall, I would recommend this top freezer model.
Date published: 2015-12-31
Rated 4 out of 5 by from Nice but needs colors and options Nice size and features but would like to see a SLATE and have the texture of the sides and top on the front. More light at the top of the refrigerator would be nice. Not sure why the shelves can't be half-width and then could be configured in more ways. The deli drawer could be half-width as well and if you position it right, you don't have to open the door all the way to open the drawer. Overall, a nice fridge.
Date published: 2015-12-30
Rated 5 out of 5 by from We bought this in October! We really liked the lighting. What sold us on the product was no handles. It was really sleek looking. This was really what he needed for his man cave. Now we do not have to worry about people running into them. He can store all he wants since it was bigger than most without handles--plus we had already gotten an LG for the kitchen--went with the same brand. love the LG
Date published: 2015-11-27
  • 2016-02-10T06:38CST
  • bvseo_cps, prod_bvrr, vn_cps_3.1.6
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_80
  • loc_en_US, sid_MD05130500, PRD, sort_mostRecent
  • clientName_LG
  • bvseo_sdk, java_sdk, bvseo-2.3.0.0
  • CLOUD, getReviews, 5ms
  • REVIEWS, PRODUCT

We're here to support you with our product.

View LTCS24223S Product Support

Contact us for any support inquiries.

ASK & ANSWER

Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

Can a new stainless steel freezer door be purchased for it?  Current one is pretty smashed up. If so how much will the door cost?

Asked by: ZachS21
We regret the inconvenience you have experienced with this refrigerator and its door. Yes, the door can be replaced. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2015-12-16

Can it pass my door of 30 Inch width?

Asked by: Eric tang
The ENERGY STAR® Qualified LG 24 cu.ft. Largest Capacity 33” Wide Top-Mount, Model # LTCS24223S is too wide to fit through a 30 inch door so the door will have to be removed to get it through a 30" opening. The refigerator has a depth of 29" without the door...^IFV
Answered by: LGJoel
Date published: 2015-10-18

How do you clean the coils on model LTC24223S?

I have dogs and am used to cleaning the coils once a month. This modle sits very close to the floor, has no front grate, and when I looked underneath could not see any coils. Where are they located and how do I access for cleaning?
Asked by: LinCarolina
We appreciate your interest in this refrigerator and its maintenance. The lower back panel would have to be removed in order to access the coils. Normally this should not prove necessary. It may be possible to clean the vents on the back panel instead.
Answered by: NeilE
Date published: 2015-10-18

Can I get the large capacity top freezer model without an ice maker?

If so, what model should I shop for? If not, is there any way to have the ice maker removed after purchase? I don't have a water line to the refrigerator and an ice maker is a big waste of space for me. Thank you.
Asked by: ErinK
Just don't hook it up & you'll be fine. I am in the same position.
Answered by: Doro
Date published: 2015-10-18

Does the LTCS24223S Refrigerator have a water filter?

Asked by: Jim9814
The LG 24 cu.ft. Largest Capacity 33” Wide Top-Mount, Model # LTCS24223S does not have a water filter. If you would like to have filtration, you would have to connect an inverted osmosis water filtration system to the cold water line...^IFV
Answered by: LGJoel
Date published: 2016-01-07

can the door be reversed

shows as opening to the right ... can it also be switched to open to the left?
Asked by: KevinL
If it is more convenient for you to convert the doors from the left opening type (factory installed) to the right opening type on the LG 24 cu.ft. Largest Capacity 33” Wide Top-Mount, Model # LTCS24223W, there are explicit instructions in the owner's manual on how to do that...^IFV
Answered by: LGJoel
Date published: 2015-12-14

Its been 33 hours now and still no ice has been made. What do i need to do? The Led light is still in the middle.

Model: LTCS24223B
Asked by: Twoods107
We regret the trouble you have experienced with this refrigerator. Check to ensure the water is flowing properly. Check the temperature of the freezer to make sure it is able to freeze. If these are both operating properly, and there is still no ice, then the unit may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2015-10-18

Can I purchase an extra shelf for the freezer?

There is another spot for the one shelf in the freezer. I would like to purchase a second shelf, is this possible?
Asked by: adrinaelaine
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for the Freezer Shelf is AHT73455102.
Answered by: NeilE
Date published: 2015-10-18
