MULTI V 5 PRO, Heatpump, Outdoor Unit, 22HP, R410A
  • High Reliability1

    High Reliability

    MULTI V 5 PRO is equipped with the 5th generation inverter compressor. It reduces vibration and bearing loads, and increases bearing performance in oil-free operation.

  • Dual Sensing Control 1

    Dual Sensing Control

    Dual Sensing Control senses both humidity and temperature. Also, it controls temperature and amount of air according to the surrounding environment for economical and comfortable operation.

  • Corrosion Resistance1

    Corrosion Resistance

    LG’s exclusive “Black Fin” heat exchanger brings durability and long-lasting performance. This coating offers strong protection from various corrosive external substances.

Close
POWER SUPPLY
  • Case 1 (V, Phase, Hz)
    50 Hz 380-415 V 3N~
    Limit Range of Voltage(Case 1) (V)
    342 - 456
  • Case 2 (V, Phase, Hz)
    60 Hz 380 V 3N~
    Limit Range of Voltage(Case 2) (V)
    342 - 418
COOLING CAPACITY
  • Rated (kW)
    61.6
    Rated (Btu/h)
    210 200
HEATING CAPACITY
  • Rated (kW)
    61.6
    Rated (Btu/h)
    210 200
Power Input(Cooling)
  • Rated (kW)
    16.80
POWER INPUT(HEATING)
  • Rated (kW)
    17.80
EFFICIENCY
  • EER(Rated) (W/W)
    3.67
    COP(Rated) (W/W)
    3.46
POWER FACTOR(COOLING/HEATING)
  • Rated
    0.93 / 0.93
OUTDOOR FAN
  • Type
    Propeller fan
    Air Flow Rate(High) (m³/min x No.)
    320 X 2
  • Discharge direction(Side / Top)
    Top
OUTDOOR FAN MOTOR
  • Type
    BLDC
    Drive
    DC INVERTER
  • Output (W x No.)
    900 × 2
COMPRESSOR
  • Type
    Hermetically Sealed Scroll
    Piston Displacement (cm3/rev)
    87.6
  • Number of Revolution (rev/min)
    3,600
    Oil Charging amount (cc x No.)
    7500 x 1
  • Starting Method
    Inverter
    Oil Type
    FW68D(PVE)
HEAT EXCHANGER
  • Type
    Fin & Tube
    No.
    1
  • Fin Type
    Wide Louver Plus
Dimensions
  • Net(W x H x D) (mm)
    1240 x 1690 x 760
    Shipping(W x H x D) (mm)
    1280 x 1825 x 796
WEIGHT
  • Net (kg)
    230
    Shipping (kg)
    247
EXTERIOR
  • Color
    Morning Gray / Dawn Gray
    RAL (Classic)
    RAL 7038 / RAL 7037
PROTECTION DEVICE
  • High Pressure Prevention
    High pressure sensor / High pressure switch
    Frost Prevention
    O
  • Discharge Tempreature Control
    O
    Compressor/Fan Protection
    Over-heat protection / Fan driver overload protector
  • Inverter Protection
    Over-heat protection / Over-current protection
