Certification
CE,FCC,ETL,CB
Controller
Embedded
Pixel Configuration
3 in 1 SMD
Pixel Pitch(mm)
1.56
Screen Resolution
1,920 x 1,080
Module Dimensions(WxH,mm)
250 x 281.25
No. of Modules per Screen (WxH)
12x6 (Total 72)
Screen Resolution (WxH)
1,920x1,080
Screen Dimensions (W x H x D, mm)
3,004.6 × 1,692.1 x 35.5
Screen Surface Area (㎡)
5.06
Screen Weight (kg)
131
Physical Pixel Density (pixels/m²)
409,600
Flatness of Cabinet (mm)
±0.2
Cabinet Material
Aluminum
Service Access
Front
Environment
RoHS, REACH
Brightness
800
Color Temperature
6,500
Visual Viewing Angle (H × V)
160 × 160
Brightness Uniformity
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000
Processing Depth (bit)
16
Power Consumption (W/Screen, Max.)
3,000
Power Consumption (W/Screen, Avg.)
1,200
Power Consumption (W/m², Max.)
593
Power Consumption (BTU/hr/Screen, Max.)
10,236
Power Consumption (BTU/hr/Screen, Avg.)
4,094
Power Consumption (BTU/hr/m², Max.)
2022
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
≥2880
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature(℃)
0°C to +40°C
Operating Humidity
<90%RH(without condensation)
IP Rating Front / Rear
IP40 / IP20
