Certification
Safety 60950-1, EMC Class A
Controller
CSAB-009X
Driver-IC Type
Common Cathode
Power Consumption (W/cabinet, Max.)
125
Power Consumption (W/cabinet, Avg.)
85
Power Consumption (W/m², Max.)
617
Power Consumption (BTU/h/cabinet, Max.)
427
Power Consumption (BTU/h/cabinet, Avg.)
290
Power Consumption (BTU/h/m², Max.)
2,108
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature
0°C to +40°C
Operating Humidity
10-80% RH
IP Rating (Front / Rear)
IP50 / IP20
Min. Brightness (After Calibration)
1,200 nit (Peak.) / 600 nit (Max.)
Color Temperature
7,300 K / 3,200~9,300 K (Adjustable by LED Assistant on PC)
Visual Viewing Angle (H×V)
160° × 160°
Brightness Uniformity
≥95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio (10 lux)
150,000 : 1
Processing Depth (bit)
20
HDR Compatibility
HDR10, HDR10 Pro* * HDR10 Pro is LG's own HDR solution to process HDR signal by using enhanced dynamic tone mapping.
Optional Accessory
Wall Mount Kit, Frame Kit
Pixel Configuration
1R, 1G, 1B (Chip on Board)
Pixel Pitch (mm)
0.93
Module Resolution (W x H)
160 × 180
Module Dimensions (W x H, mm)
150 × 168.8
Weight per Module (g)
150
No. of Modules per Cabinet (W × H)
8 (4 × 2)
Cabinet Resolution (W × H)
640 × 360
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/cabinet)
7.0
Weight per Square Meter (kg/m²)
34.6
Physical Pixel Density (pixels/m²)
1,137,778
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-casting Aluminum
Service Access
Front and Rear (Module : Front Only)
Environment
RoHS
