VL5F Series

55VL5F-A

Key Features

Narrow bezel for more immersive viewing
IPS with wide viewing angle
Simple white balance adjustment

Impressive Immersion with Narrow Bezel

The 55VL5F provides impressive immersion thanks to its narrow 3.5 mm bezel-to-bezel image gap, while its outstanding IPS panel delivers minimal colour temperature variation from wide viewing angles. With its eye-catching and functional design, it can be used to deliver advertising and information in a variety of business environments.

Narrow Bezels

The 3.5mm narrow bezel size creates immersive and near seamless viewing experiences on assembled video wall screens.

Immersive Viewing Experience

Image Gap Reduction

The 55VL5F series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a near seamless viewing experience.

Wide Viewing Angle

LG IPS panels allow you to enjoy lifelike picture quality with minimal variation from wide viewing angles. Featuring excellent consistency in colour temperature and less change in contrast, LG IPS panels boast excellent image reproduction.

User Convenience

Easy Colour Adjustment

Depending on the content, the colour temperature of the screen can be easily adjusted by users with a remote control.

User Convenience

Simple White Balance Adjustment

In previous LG video walls, white balance was adjustable only in “full-white” mode, but the 55VL5F series allows you to modify the grey scale steps to achieve more detailed and precise white balance adjustment.

User-Friendly Smart Signage UX

Intuitive Menu Structure

The menu structure has been optimised for commercial use. It simplifies the user experience and groups similar functions together, allowing for a more intuitive GUI.

User Convenience

Intuitive GUI

The GUI(Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. The GUI also adopts a larger font for better visibility,which is necessary when users want to control displays from relatively far distances.

Narrow bezel for more immersive viewing
IPS with wide viewing angle
Simple white balance adjustment

All Spec

PANEL

Screen Size (Inch)
55
Panel Technology
IPS
Back Light Type
Direct
Aspect Ratio
16:9
Native Resolution
1920 x 1080 (FHD)
Refresh Rate
60Hz
Brightness
500nit (Typ.)
Contrast Ratio
1,200:1
Dynamic CR
500,000:1
Color Gamut
NTSC 72%
Viewing Angle (H x V)
178º x 178º
Color Depth (Number of Colors)
1.07 Billion colors
Response Time
8ms (G to G)
Surface Treatment (Haze)
Haze 3%
Life time
60,000Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
YES / YES
Transparency
N/A
QWP (Quarter Wave Plate)
N/A

CONNECTIVITY

HDMI In
YES (2ea)
HDMI In (HDCP Ver.)
1.4
DP In
YES (HDCP 1.3)
DVI-D In
YES (HDCP 1.4)
RGB In
NO
Audio In
YES
RS232C In
YES
RJ45(LAN) In
YES (1ea)
IR In
YES
USB In
USB2.0 Type A (1ea)
HDMI Out
NO
DP Out
YES
Audio Out
YES
Touch USB
NO
External Speaker Out
NO
RS232C Out
YES
RJ45(LAN) Out
NO
IR Out
NO
Daisy Chain
Input : HDMI, DP, DVI-D / Output : DP

MECHANICAL SPECIFICATION

Bezel Color
Black
Bezel Width
T/R/L/B : 2.25/1.25/2.25/1.25mm
Weight (Head)
20.3Kg
Weight (Head+Stand)
N/A
Packed Weight
33Kg
Monitor Dimensions (W x H x D)
1213.4 x 684.2 x 93.1mm
Monitor Dimension with Stand (W x H x D)
N/A
Carton Dimensions (W x H x D)
1353 x 980 x 263mm
Handle
YES
VESA Standard Mount Interface
600 x 400 mm

FEATURE - HARDWARE

Internal Memory (eMMC)
NO
Wi-Fi/BT (Built-in)
NO
Temperature Sensor
YES
Auto Brightness Sensor
NO
Pixel Sensor
NO
Proximity Sensor
NO
Current Sensor
NO
BLU Sensor
NO
Humidity Sensor
NO
Acceleration(Gyro) Sensor
NO
Power Indicator
NO
Local Key Operation
NO
FAN (Built-in)
NO

FEATURE - SOFTWARE

OS Ver. (webOS)
Non-webOS
Local Contents Scheduling
YES
Group Manager
NO
USB Plug & Play
YES
Fail over
YES
Booting Logo Image
YES
No Signal Image
YES
RS232C Sync
YES
Local Network Sync
NO
Backlight Sync
NO
PIP
NO
PBP
NO
Screen Share
NO
Video Tag
NO
Play via URL
NO
Screen Rotation
YES
External Input Rotation
NO
Gapless Playback
NO
Tile Mode Setting
YES
Setting Data Cloning
YES
SNMP
YES
ISM Method
YES
Auto Set ID
YES
Status Mailing
NO
Control Manager
NO
Cisco Certification
NO
Crestron Connected
YES
Smart Energy Saving
YES
PM mode
YES
Wake on LAN
YES
Network Ready
NO
Beacon
NO
HDMI-CEC
YES
SI Server Setting
NO
webRTC
NO
Pro:Idiom
NO
Brightness Compensation
NO
W/B Setting by Grey scale
YES
Scan Inversion
YES

ENVIRONMENT CONDITIONS

Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %

POWER

Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power

POWER CONSUMPTION

Typ.
130W
Max.
150W
BTU (British Thermal Unit)
444 BTU/Hr(Typ.), 512 BTU/Hr(Max.)
Smart Energy Saving (70%)
62W
DPM
0.5W
Power off
0.5W

SOUND

Speaker (Built-in)
NO

CERTIFICATION

Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
YES(EU Only) / Energy Star 8.0
ePEAT(US only)
NO

OPS COMPATIBILITY

OPS Type compatible
NO
OPS Power Built-in
NO

SOFTWARE COMPATIBILITY

SuperSign CMS
YES
SuperSign Control+
YES
SuperSign WB
YES
SuperSign Cloud
NO
Promota
NO
Mobile CMS
NO
Connected Care
NO

LANGUAGE

OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic

ACCESSORY

Basic
Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan cable, DP cable, IR Receiver, Guide Bracket, Screws, Manual
Optional
Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V)
