23 cu. ft. Large Capacity Counter-Depth French Door Refrigerator w/CustomChill® Drawer

  • LMXC23746S

  • Stainless Steel

Key Features

  • 23 cu. ft. Capacity
  • Counter-Depth
  • Slim SpacePlus® Ice System
  • CustomChill® Drawer
  • Smart Cooling® Plus

J.D. Power Award Winner

“Highest in Customer Satisfaction with French Door Refrigerators”

What Is Counter-Depth?

LG counter-depth refrigerators align with countertops and cabinetry for a uniform profile, creating a sophisticated built-in look without the high-end price tag.

CustomChill™ Drawer

CustomChill® Drawer

This versatile drawer gives you additional refrigerator space when you need it. Featuring four temperature settings, it adapts to your needs and gives you the flexibility to store a range of foods from meats and fresh produce to cooking ingredients and cold drinks. Its adjustable dividers help with better organizing and accessing food.

Most shelf space.*

Ice makers are great, but not if it means you can't fit all of your food in the fridge. The Slim SpacePlus® Ice System provides more shelf space and allows even more space for door bins.

*Standard width french door refrigerator, excludes other LG manufactured products

Fresher is better.

Smart Cooling® Plus technology is designed to maintain superior conditions within the refrigerator. The Linear Compressor and Dual Evaporators react quickly to humidity and temperature levels and help keep your food fresher, longer.

CONVENIENT AUTOMATIC FILTER REPLACEMENT



Enjoy Fresh Water, Ice & Air with LG Filters.

Subscribe today and enjoy savings and maximum freshness. We’ll even ship your next refrigerator filter to you when you need it automatically.*

SUMMARY
Door Type French 4-Door
Refrigerator Type Counter Depth
CAPACITY
Refrigerator 13.50 cu. ft.
CustomChill® Drawer 2.80 cu. ft.
Freezer 6.40 cu. ft.
Total 22.7 cu. ft.
FEATURES
CustomChill® Drawer Yes
Energy Rating Yes (665 kWh/Year)
Ice & Water Dispenser Yes
Dispenser Type Tall Ice & Water Dispenser®
Ice System Slim SpacePlus®
Daily Ice Production 3.5 lbs / 3.8 (IcePlus™)
Ice Storage Capacity 3.0 lbs
Water Filtration System Filter LT800P
Smart Cooling® Plus System Yes
Multi-Air Flow Cooling Yes
Temperature Sensors 8
Temperature Controls Electronic/Digital
Linear Compressor Yes
Fresh Air Filter Yes, Air Filter LT120F
Dual Evaporator Yes
Display Type Smooth Touch Control (White LED)
CONVENIENCE
Temperature Controls Electronic/Digital
Door Alarm Yes
LoDecibel™ Quiet Operation Yes
SmartDiagnosis™ Yes
Auto Closing Door Hinge Yes
Child Lock Yes
REFRIGERATOR
No. of Shelves 4 Split (3 Fixed/1 Folding)
Folding Shelf Yes
Cantilevered Shelves Yes
Shelf Construction SpillProtector™ Tempered Glass
Crisper Bins 2 Humidity Crispers/1 Bonus Drawer
Refrigerator Light Premium LED (Ceiling and Side)
EasyReach™ Bins Yes
REFRIGERATOR DOOR
No. of Shelves/Bin 6 Total
Door Bin Construction Clear , Opaque, Silver Deco
Dairy Corner Yes
CUSTOMCHILL® DRAWER
Dividers 2
Temperature Range 29˚, 33˚, 37˚, 42˚ F
Handle Smart Pull®
FREEZER
Door Type Pull Drawer
Drawers 3-Tier Organization®
Handle Smart Pull® Freezer Handle
DuraBase™ Solid Drawer Base Yes
Drawer Divider Yes
Freezer Light Premium LED
MATERIALS AND FINISHES
Contour Door Yes
Hidden Hinges Yes
Surface Coated Metal, Stainless Steel
Back Flush & Metal Cover Over Mechanical Parts
Available Colors Stainless Steel (S), Black Stainless Steel (D)
Handles Matching Commercial Handles
SPECIFICATIONS
Depth with Handles 32 1/8"
Depth without Handles 29 5/8"
Depth without Door 24 3/4"
Depth (Total with Door Open) 44"
Height to Top of Case 68 7/8"
Height to Top of Door Hinge 70 1/4"
Width 35 3/4"
Width (Door Open 90° with Handle) 45"
Width (Door Open 90° without Handle) 40"
Door Edge Clearance with Handle 4 5/8"
Door Edge Clearance without Handle 2 1/4"
Installation Clearance Sides 1/8", Top 1", Back 2"
Weight (Unit/Carton) 331 lbs./364 lbs.
Carton Dimensions (WxHxD) 38" x 73" x 33"
WARRANTY
Limited Warranty 1 Year Parts and Labor, 7 Years on the Sealed System 10 Years on Linear Compressor
UPC 048231786225

What People Are Saying

Rated 1 out of 5 by from Disappointed At 17 months this fridge has died. Called CustomerSupport for smart diagnostics, was told we need a technician. One day the freezer seemed to be thawing, a few days later water poured out of the ice dispenser. Until it stopped cooling this was the LOUDEST fridge I have ever owned. Consumers beware. If you purchase buy the extended warranty.
Date published: 2017-10-15
Rated 5 out of 5 by from Love this fridge So after living with this as our main fridge for almost a year, it's time to give feedback. Honestly, this has been a great appliance. It is quiet, very cold and has worked great. The Ice maker is a little small but we have only run out of ice once in 11 months son, non-issue. The 2 slide out drawers in the freezer are a little funky at times but once we've figured out what fits, again, non-issue. It's very bright and shinny. Glad my kids are grown but it looks great when clean. Got so say I'm very happy.
Date published: 2017-09-26
Rated 5 out of 5 by from Just Perfect This is exactly what I wanted. It works so well in my kitchen and for the needs of the household.
Date published: 2017-09-25
Rated 5 out of 5 by from Great Features Very pleased with this fridge, so far. Only issues... using crushed ice clogs the passageway where the ice comes down. running a few whole ice cubes after crushed ice, seems to clear the passageway to avoid the buildup of ice. Also, I could not twist off the plastic air filter at the top rear of the fridge. Online and phone customer support was lacking. However, LG serviceman making a home visit was able to force it off using gripping gloves. He also noted, that the ice maker was upgraded in my unit; there's an additional metal rod that helps break up the ice accumulating in the ice maker to encourage the ice to descend down the shoot without icing and jamming. Note; the pullout draw is really not useful as a freezer. The temperature rises quickly when the drawer is opened and does not get cold enough soon enough to keep items frozen. Still, it's useful to store easy to reach things in the drawer. We will see how this holds up over time.
Date published: 2017-09-25
Rated 5 out of 5 by from Perfect size and features Am very pleased with this refrigerator. The features give me max flexibility for food & beverage storage. Love almost everything. Would like a bigger ice storage bin.
Date published: 2017-09-24
Rated 4 out of 5 by from Love the look of the LG Refrigerator I find the independent drawer an excellent feature. It is my go to place for breads, and cold cuts. I have not found a use for the easy reach pockets as they are not deep enough to put items as small snacks, like cut up carrots.
Date published: 2017-09-24
Rated 4 out of 5 by from Great space in compartments I love my refrigerator with exception of the ice maker. It continues to freeze up for some reason and I have to continuously take the container out and break up the ice.
Date published: 2017-09-23
Rated 5 out of 5 by from awesome refridgerator We bought this refridgerator because of the doors and the middle drawer. The top door allows us to open our dishwasher and not be hindered by a full size door. We also are loving the black stainless. It is so modern and not the traditional stainless steel look.
Date published: 2017-09-23
  • y_2017, m_10, d_18, h_19
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.3
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_122
  • loc_en_US, sid_MD05149921, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-2.3.0.0
  • CLOUD, getReviews, 3ms
  • REVIEWS, PRODUCT

We're here to support you with our product.

View LMXC23746S Product Support

Contact us for any support inquiries.

ASK & ANSWER

Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

When was this product LMXC23746D in black stainless first released? Was there more than 1 release?

Asked by: Aharr3
The ENERGY STAR® Qualified LG Black Stainless Steel Series 23 cu. ft. Counter-Depth 4- Door French Door Refrigerator w/ CustomChill® Drawer, Model # LMXC23746D is a recent release as Black Stainless Steel but the regular Stainless Steel was first available in the market on 09/01/2014...^IFV
Answered by: LGJoel
Date published: 2017-06-28

The highest freezer drawer gets ice crystals on it, and the ice cream bars get really soft.  What's wrong?

Asked by: Barbidoll100
We regret the trouble you have experienced with this refrigerator. The description provided suggests there may be an air leak near this upper drawer, allowing warm air into the freezer, allowing crystallization on the leaking humidity, and thawing of items near the leaking area. For additional help, please contact our Customer Interactive Center at 800-243-0000.
Answered by: NeilE
Date published: 2017-03-06

What is the power consumption for the LMXC23746S refrigerator?

Asked by: Jolind
The Energy Guide label attached to the ENERGY STAR® Qualified LG 23 cu. ft. Large Capacity Counter Depth French Door Refrigerator w/CustomChill® Drawer, Model # LMXC23746S lists the Estimated Yearly Electricity Use as being 665 kWh...^IFV
Answered by: LGJoel
Date published: 2017-02-27

The chill drawer sensor does not recognize when it's closed. Light stays on the bottom of the French doors along with display and alarm even though the door is completely closed. Please advise where the door closed sensor for chill and freezer drawer are?

Asked by: Vikingleif
We regret the trouble you have experienced with this refrigerator. As we are not technicians, it will not be possible to assist with the drawer sensors mentioned. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2017-01-30

Need to know amperage. Or watts so I can calculate amperage. This is not the same as kw/year.

Asked by: Sammi Amm
We appreciate your interest in this refrigerator. According to our product documentation, this model should always be connected to an electrical outlet rated for 115V at 60Hz, and fused for 15 to 20 Amps. Such is required to guarantee sufficient amperage for the starting operation of the compressor system.
Answered by: NeilE
Date published: 2016-10-17

Does lg have counter depth refrig with drawer being freezer instead of refrigerator? ?

Asked by: Pugg
The CUSTOMCHILL® DRAWER in the ENERGY STAR® Qualified LG 23 cu. ft. Large Capacity Counter Depth French Door Refrigerator w/CustomChill® Drawer, Model # LMXC23746S is the drawer between the freezer compartment and the refrigerator compartment and has a variable temperature range of 29˚, 33˚, 37˚, 42˚ F. The other LG Counter Depth refrigerators that do not have that configuration just have a bottom mounted freezer and refrigerator compartment...^IFV
Answered by: LGJoel
Date published: 2016-09-26

Is this appliance available without the water/ice dispenser?

Asked by: Martha from Wisconsin
I would love for this to be true.  We like this refrigerator but are dismayed by all the negative feedback on the ice dispenser.  As of 7/2016, there is no option of this model/style without the dispenser.
Answered by: Tony P
Date published: 2016-07-31

Freezer drawer does not automatically close

Asked by: Kathwin
The refrigerator doors and freezer drawers close automatically when you push them slightly. (The door only closes automatically when it is open at an angle of less than 30°.)
Answered by: NeilE
Date published: 2016-07-05
