Certification
Safety 62368-1,
EMC Class B
Controller
CEAA / CEAB / SBAA
Power Consumption (W/㎡, Max.)
311
Frame Rate (Hz)
48 / 50 / 60
Heat Dissipation (BTU/h/Cabinet, Avg.)
126
Heat Dissipation (BTU/h/Cabinet, Max.)
215
Heat Dissipation (BTU/h/㎡, Max.)
1,061
Power Consumption (W/Cabinet, Avg.)
37
Power Consumption (W/Cabinet, Max.)
63
Power Supply (V)
100 to 240
Refresh Rate (Hz)
7,680(V)
Environment
RoHs
LED Lifetime (Half brightness)
150,000
IP rating Front
IP50
IP rating Rear
IP20
Operating Humidity
10~80%RH
Operating Temperature(℃)
0℃ to +40℃
Visual Viewing Angle (Horizontal)
160
Brightness (After Calibration, nit)
Typ. 600 / Peak 1,500
Brightness Uniformity(%)
0.95
Color Temperature (K)
3,200~9,300 / Default 7,300
Color Uniformity
±0.02Cx,Cy
Contrast Ratio
40,000:1 @10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Visual Viewing Angle (Vertical)
160
Pixel Configuration
Micro
Cabinet Dimensions (W x H x D, mm)
600x337.5x39.8
Cabinet material
Mold / PC+ABS-GF20%
Cabinet Resolution (WxH)
640x360
Cabinet Surface Area (㎡)
0.2
Flatness of Cabinet (mm)
±0.5
Module Dimensions(WxH,mm)
300x112.5
Module Resolution (WxH)
320x120
No. of Modules per Cabinet (WxH)
2x3
Physical Pixel Density (pixels/㎡)
1,137,778
Pixel Pitch (mm)
0.93
Service access
Front
Weight per Cabinet (kg/unit)
5.6
Weight per Module (kg)
0.19
Weight per Square Meter (kg/㎡)
27.7
