CBV42-BP
Zero Client TERA2 V Series Box Type
  • Teradici TERA 2321 Chipset with PCoIP Protocol
  • Low Power Consumption
  • Fanless Design
  • Extended Connectivity Options
  • Easy Installation

component-OBScountrySelectDesc

Zero Client TERA2 V Series Box Type
*teradici TERA2321 PCoIP® Processor chipset.
**Actual power consumption may vary depending on network and use.
GENERAL
  • Product Type
    Box Type
OUTPUT(SIGNAL)
  • DVI Out
    DVI-I
    DisplayPort Out
    Yes
INPUT(AUDIO)
  • Mic In
    Yes
    [ Jack Location ]
    Front
OUTPUT(AUDIO)
  • Headphone Out
    Yes
    [ Jack Location ]
    Front
INTERACTIVE
  • USB
    USB 2.0 (6 down)
    Ethernet
    Yes (10/100/1000)
POWER
  • Type
    Adapter
    Input
    100~240V (50/60Hz)
  • Output
    24W(19V/1.3A)
    Consumption - Normal On(typ. / outgoing))
    6W
  • Consumption - DC Off(Max)
    0.5W
FREQUENCY
  • H-Frequency (D-sub)
    Depends on Display
    V-Frequency (D-sub)
    Depends on Display
  • H-Frequency (LAN)
    Depends on Display
    V-Frequency (LAN)
    Depends on Display
RESOLUTION
  • Signal Output - DVI out
    Yes(DVI-D 1ea, DVI-I 1ea)
CONTROL KEY
  • Key Number
    1
    Key Type
    Tact
  • LED Color(On mode)
    Red
    [ Key Location ]
    Front
COLOR
  • Front
    Black - Non Glossy
    Back Cover
    Black - Non Glossy
  • Stand
    Black - Non Glossy
    Base
    Black - Non Glossy
STAND
  • Base Detchable
    Yes
SIZE/WEIGHT
  • Dimension (WxDxH) - Set (with Stand, mm)
    70 x 144 x 189
    Dimension (WxDxH) - Set (without Stand, mm)
    185 x 144 x 31
  • Dimension (WxDxH) - Box (mm)
    266 x 155 x 199
    Dimension (WxDxH) - VESA / Wall Mount (mm)
    100 x 100 / 75 x 75 (VESA)
  • Weight - Set (with Stand, Kg)
    0.66
    Weight - Set (without Stand, Kg)
    0.66
  • Weight - Box (Kg)
    1.33
    Stuffing - Individual(20ft/40ft/40ft HC)
    3584/7350/8400
  • Stuffing - Pallet(20ft/40ft/40ft HC)
    2304/5184/6048
WRAP
  • Packing Material
    EPS
    Stacking Type
    Face Down
  • Stand Packing Type
    Cradle Detach
    Box Printing Type
    Flexo
STANDARD
  • UL(cUL)
    Yes
    TUV-GS
    Yes
  • CB
    Yes
    FCC-B
    Yes
  • CE
    Yes
    ROHS, REACH
    Yes
ACCESSORY
  • Power Cord
    Yes
    DisplayPort
    Yes
CATEGORY
  • Network Interface
    Ethernet(10/100/1000)
    Protocol
    PCoIP
  • Memory
    512MB
    Processor
    Tera2321
  • Certification
    VMware
    OS Support
    VDI Concept
  • VDI Support
    VMWare View
CLOUD HOME SCREEN
  • Languange
    English, French, Germany, Spanish, Italian, Portuguese, Korean, Japanese, Chinese, Simplified Chinese, Greek
    Number of Language
    11
  • Wake On LAN
    Yes
