LED Type
R, G, B 3in1 Color Package (SMD2020)
Pixel Pitch(mm)
13.7±0.2mm
Resolution
48 x 36
Pixels per Panel
1,728
Pixel Density (point/㎡)
5,102
Brightness (cd/㎡)
Typ.2,100nit
Contrast Ratio
≥ 100,000:1
Luminance Uniformity
≥ 70%
Viewing Angle (H x V)
120 x 120
Life Time (Duration of Half Brightness in Hours)
50,000 Hrs
Daily Usage
24h / 7days
Warranty
2 years
Transparency
Typ 53%
Operating Temperature
0℃ ~ 45℃ (Indoor Glass Installation Only)
Film Trimming
Yes (Parallel to the Bezel Side Only)
Color Processing
(9bit) 500/500/500 Level (R, G, B)
Colors
125,000,000 Colors
Color Chromaticity
Cx: 0.25±0.03, Cy : 0.34±0.03
Dimension (W x H x D)
655 x 492 x 2.9mm(with front & back protection film)
Weight
1kg
Power Consumption
37W(Transparent panel 1EA + Common Bezel kit 2EA)
Accessory
ESG, Regulation book, Warranty Card
Dimension (W x H x D)
69.4 x 492 x 25mm (Cover)
Weight
0.4Kg
Dimension (W x H x D)
51.4 x 492 x 25mm (Cover)
Weight
0.3Kg
Resolution
960x540 (1/4 FHD)
Interface
Input : LVDSOutput : RJ45 x4EA
Maximum Transmission Length
100m (Cable : CAT5E, CAT6)
Dimension (W x H x D)
293 x 188.7 x 37mm
Weight
1.5Kg
Temperature Sensor
Yes
Power Consumption
20 W
Video (Max. Input Resolution)
DP : 1920x1080@60HzHDMI : 1920x1080@60HzDVI-D : 1920x1080@60Hz
Interface (Input)
HDMI, DP, DVI-D, RS-232C (Phone Jack Type), RJ45 (w/o LED Indicator), IR Receiver (Phone Jacke Type), USB 3.0,
Interface (Output)
DP, RS-232C (Phone Jack Type), RJ45 (w/o LED Indicator), LVDS
Dimension (W x H x D mm)
293 x193.3 x 40.1mm
Weight (Head, Kg)
1.6kg
Temperature Sensor
O
Light Sensor
O
Source Selection
HDMI, DVI-D, DP
Power Consumption
17W
CMS S/W
Yes (2.9)
Signage365care
Yes (2.7)
Accessory
Power cord, IR+Bright Sensor (1.5m), 4P Phone-to-RS232C Gender, ESG, Regulation book , Warranty Card
Dimension (W x H x D)
183 x 86 x 28mm
Weight
769g
Input
100~240V, 50~60Hz
Output
19.5V/10.8A (210W)
Color
White
DC output cable
14AWG, 1.5m
Type
L Type
