- Accurate Color
- Wide Viewing Angle for Color Uniformity
- Enhanced User Experience
- Low Grayscale Image Clarity
- Long Range Data Transmission
All Spec
STANDARD
Certification
Safety 62368-1,
EMC Class B
CONTROLLER
Controller
CEAC / SBAA
ELECTRICAL SPECIFICATIONS
Frame Rate (Hz)
96 / 100 / 120
Heat Dissipation (BTU/h/Cabinet, Avg.)
119
Heat Dissipation (BTU/h/Cabinet, Max.)
205
Heat Dissipation (BTU/h/㎡, Max.)
1,009
Power Consumption (W/Cabinet, Avg.)
35
Power Consumption (W/Cabinet, Max.)
60
Power Consumption (W/㎡, Max.)
296
Power Supply (V)
100 to 240
Refresh Rate (Hz)
7,680(V)
ENVIRONMENT
Environment
RoHs
OPERATION SPECIFICATIONS
IP rating Front
IP50
IP rating Rear
IP20
LED Lifetime (Half brightness)
150,000
Operating Humidity
10~80%RH
Operating Temperature(℃)
0℃ to +40℃
OPTICAL SPECIFICATIONS
Brightness Uniformity(%)
0.95
Brightness (After Calibration, nit)
Typ. 600 / Peak 1,200
Color Temperature (K)
3,200~9,300 / Default 7,300
Color Uniformity
±0.02Cx,Cy
Contrast Ratio
35,000:1 @10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
PHYSICAL PARAMETERS
Cabinet material
Mold / PC+ABS-GF20%
Cabinet Dimensions (W x H x D, mm)
600x337.5x39.8
Cabinet Resolution (WxH)
480x270
Cabinet Surface Area (㎡)
0.2
Flatness of Cabinet (mm)
±0.5
Module Dimensions(WxH,mm)
300x112.5
Module Resolution (WxH)
240x90
No. of Modules per Cabinet (WxH)
2x3
Physical Pixel Density (pixels/㎡)
640,000
Pixel Configuration
Micro
Pixel Pitch (mm)
1.25
Service access
Front
Weight per Cabinet (kg/unit)
5.6
Weight per Module (kg)
0.19
Weight per Square Meter (kg/㎡)
27.7
