LG MAGNIT - LSAB012-N22
Pixel Configuration
Micro
Pixel Pitch (mm)
1.25
Module Resolution (WxH)
240x90
Module Dimensions(WxH,mm)
300x112.5
Weight per Module (kg)
0.18
No. of Modules per Cabinet (WxH)
2x3
Cabinet Resolution (WxH)
480x270
Cabinet Dimensions (W x H x D, mm)
600x337.5x44.9
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
7.8
Weight per Square Meter (kg/㎡)
38.5
Physical Pixel Density (pixels/㎡)
640,000
Flatness of Cabinet (mm)
±0.5
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
600 / Peak 1,500
Color Temperature (K)
3,200~9,300 / Default 7,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
95
Color Uniformity
±0.02Cx,Cy
Contrast Ratio
40,000:1 @10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
60
Power Consumption (W/Cabinet, Avg.)
35
Power Consumption (W/㎡, Max.)
296
Heat Dissipation (BTU/h/Cabinet, Max.)
205
Heat Dissipation (BTU/h/Cabinet, Avg.)
120
Heat Dissipation (BTU/h/㎡, Max.)
1,013
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
10~80%RH
IP rating Front
IP50
IP rating Rear
IP20
Certification
Safety 60950-1, EMC Class B
Environment
RoHs
Controller
CSAD
