MULTI V Hydro Kit, Floor type - High Temperature, 25kW
Green energy solution through the reduction of CO2 emissions.
Wall mounted hydro kit with MULTI V S outdoor is suitable for residential application with its compact size and design.
Equivalent installation cost of traditional boiler with reduced operational costs.
Hydro Kit absorbs heat from the indoor space and utilises it for hot water.
#1
50/60 Hz 220-240 V~
Rated (kW)
25.2
Rated (kW)
5
Type
Twin Rotary inverter
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
4,000 x 1
Starting Method
Direct On Line
Oil Type
FVC68D(PVE)
Oil Charging (cc)
1300
Piston Displacement (cm³/rev)
52.5
Type
Brazed Plate HEX
Head loss ( kPa )
20
Rated Water Flow ( LPM )
36
Net(W x H x D) (mm)
520 x 1,080 x 330
Net (kg)
90.5
Type
R410A
t-CO₂ eq.
4.29
Control Type
Electronic Expansion Valve
Liquid (mm(inch))
Ø 9.52(3/8)
Gas (mm(inch))
Ø 19.05(3/4)
Inlet (inch)
Male PT 1
Outlet (inch)
Male PT 1
Cooling / Heating (dB(A))
- / 46
