Modbus-RTU provides a connection between
LG air conditioners and BMS, providing integration.
The Modbus RTU communicates with the master control, providing convenient integration of all units.
The Modbus-RTU interface is used to communicate with automation systems.
Modbus is applicable to outdoor units such as the Multi V5, ERV and heating systems.
Air Purify
O
Cycle monitoring
O
Electricity Monitoring
O
Fan speed
O
History
O
Operation Mode
O
Operation Start/Stop
O
Schedule
X
Smart Diagnosis
X
Swing
O
Target Temperature
O
Communication - Ethernet
Max. 50 m (10/100 Mbps)
Communication - RS485
Max. 1 km (LGAP)
Communication - Wi-Fi
802.11b/g/n, 2.4 GHz
Compatibility with Product
Air conditioner, ERV, ERV DX, Thermal V
Digital Input(The number of ports)
1
Operating temperature
0~40℃
Power consumption
5W
Power Supply
12 V(Max. 50 m (Use of the output power of the outdoor unit.))
Size (W x H x D, mm)
120 x 120 x 29
Storage temperature
-20~60℃
