Optimus F5

  • AS870

Key Features

  • Fast, Smooth Android™ 4.1.2 (Jelly Bean)
  • Spacious 4.3" qHD AH-IPS Display
  • 5 MP Autofocus Camera with LED Flash & 1.3 MP Front-Facing Camera
  • Long-Lasting 2,460 mAh Li-ion Battery


You live life to the absolute fullest, and Optimus F5’s robust and dependable 2,460 mAh Li-ion battery, up to 17 hours usage time1, and 4G LTE, it’s the only thing that can keep up without weighing you down. Love what you do—and do it for as long as you can.

Express Yourself With QuickMemo™

Express Yourself With QuickMemo™

Capture any screen image, make notes with your finger, and share online, by text, email and more. Add a personal touch in all you do!



Android™ 4.1.2 Jelly Bean is a sweet Android interface. Packed with juicy new features, it adds flavor to even the simplest tasks—and makes your user experience more satisfying than ever.

Google Play™

Google Play™

At Google Play™, you can browse and download thousands of free and paid apps from around the world.

Mobile Accessories

Mobile Accessories

Get all the fixings for your LG mobile phone (accessories sold separately).

Technical Specifications
Form Factor Bar
Camera Yes
Smartphone Android™-Powered
Touch Screen Capacitive
Web Yes
Type Smart Phone
Form Factor Bar
Technology CDMA, LTE*
Processor ARMv7 rev 4 (v71)
Frequencies 1.9 GHz CDMA PCS, 800 MHz CDMA, 700 MHz LTE*
Data Transmission LTE, EVDO Rev. A, 1xRTT
Dimensions 4.82" (H) x 2.51" (W) x 0.38" (D)
Weight 4.06 oz
Display 4.3" qHD AH-IPS, 960 x 540 pixels
Touch Screen Yes
Battery Capacity 2,460 mAh
Standby Time Up to 9 days and 14 hours**
Internal Memory 8 GB (3.8 GB user available)
MicroSD™ Memory Slot Support up to 64 GB***
* All listed frequency support is network/carrier specific. When roaming, network specific frequency support may not be available. Check with your network provider to see if and to what extent they offer support for this device.
** Certain features may use more power and cause actual standby time to vary.
*** MicroSD™ cards sold separately
LG and Android™ Enhancements
Android™ Platform Android™ 4.1.2 Platform (Jelly Bean)
Preloaded Apps Chrome™, Gmail™, Google (with Search), Google+™, Local, Google Maps™, Messenger, Navigation, Play Books, Play Magazines, Play Movies & TV, Play Music, Play Store, Google Talk™, Google Voice Search™, YouTube™
Network 4G LTE Network*,**
Bluetooth® Version 4.0 with unlimited pairings***
Mobile Hotspot Share a 4G data connection with other compatible wireless devices.**,****
Wi-Fi® Connectivity 802.11a/b/g/n
File Share Use Wi-Fi Direct™ to share images, videos, music, and documents with compatible devices
GPS S-GPS For Enhanced Location Accuracy
* 4G LTE Network not available everywhere
** All listed frequency support is network/carrier specific. When roaming, network specific frequency support may not be available. Check with your network provider to see if and to what extent they offer support for this device.
*** Depends on available memory
**** Depends on network availability
Video Player Touch Lock, Resume Play Function, and Dolby® Mobile*; supports MP4, AVI, WMV, MOV, MKV, 3GP, 3G2 (Codec: MPEG4, H.263, H.264, VC-1, DivX®, and Xvid)
Music Player Dolby Mobile* for MP3, AAC, AAC+, WMA, and WAV Formats
* Headset required (sold separately)
Front-Facing Camera 1.3 Megapixel Front-facing Camera and Camcorder
Rear-Facing Camera 5 Megapixel Rear-Facing Autofocus Camera and Camcorder with LED Flash
Camera Resolutions Up to 2560 x 1920 (default)
Full HD Video Recording Up to 1920 x 1080 (1280 x 720 default)
Customizable Quick Menu Add most-used Camera and Video Camera features to the viewfinder menu.
Cheese Shutter Voice command picture taking
Time Catch Shot™ Take several pictures before pressing the shutter button.*
Shot Mode Choose from Normal, HDR, Panorama, and Continuous shot.
* Available on rear-facing camera or camcorder only
QuickMemo™ Create and share personalized memos by taking screen captures and adding handwritten drawings or messages.
Gesture Features Access common phone functions with simple gestures.
Connect to Social Networks Send quick updates to Google+™, Twitter®, Facebook®, and other social networks. Applications downloaded from Google Play
