4.7 cu.ft. Capacity 30" Built-in Single Wall Oven with Crisp Convection

  • LWS3010ST

  • Stainless Steel

Key Features

  • Crisp Convection
  • Self Cleaning
  • SmoothTouch(TM) controls
AVAILABLE COLORS:
ADA - COMPLIANT OVEN

ADA - Compliant Ovens*

To be considered ADA-compliant, a freestanding slide in range must have a maximum high forward reach for controls and operating mechanisms is 48", maximum low forward reach is 15".

SUMMARY
Oven Type Single
Capacity 4.7 cubic ft.
Dimensions (W x H x D) 29 3/4" x 29 5/16" x 24 3/8"
Convection Bake Yes
Convection Roast Yes
Healthier Roast Yes
Crisp Convection Yes
Convection Conversion Yes
LCD Display Yes
Gourmet Recipe Bank Yes
Color / Finish Stainless Steel
Interior Color Blue
Self Cleaning Yes
Auto Shut-Off Yes
ADA Compliant Yes
CONTROLS
Display Type White VFD
OVEN SPECIFICATIONS
Variable Broil Full, Center/High, Med, Low
Broil Element 2,500W Inner/1,500W Outer
Broil Element Pass 8
Bake Element 2,500W
Bake Element Type Hidden (8 Pass)
No. of Racks 3 Heavy Duty Racks
No. of Rack Positions 5
Convection Element 2500W Carbon Heater
Variable Warm High, Med, Low
Specialized Cooking Healthier Roast (Reduced Fat Cook) on Upper Oven Only, Crisp Convection
Broiler Pan Yes
DIMENSIONS
Product (WxHxD) 29 3/4" x 29 5/16" x 24 3/8"
Cut-Out (WxHxD) 28 1/2" x 29" x 23 1/2"
Weight (Shipping) 179 lbs.
WARRANTY
Limited Warranty 1 Year
UPC Code 048231 317092

What People Are Saying

Rated 5 out of 5 by from Great fit and features! Love the features of this oven! It is so much easier to use than I feared!! Looks great and I also like the light inside - maybe it is because of the blue interior but it seems to be easier to see what is cooking. Really love it!
Date published: 2016-07-26
Rated 5 out of 5 by from Great fit and features! Bought this to replace one lost in a fire and am very pleased with this! I had it installed with the kit in the wall and it has so much more room than a typical built in microwave. Great features too!!
Date published: 2016-07-26
Rated 5 out of 5 by from Excellent Oven Installed early May 2016 the oven has been used numerous times since then. Really like the options and the clarity of the control panel. Of course the blue colored interior with the bright 3 bulb lighting is very nice and bright compared to the old gray enamel oven it replaced. The automatic reduced temp when using the convection feature saves a lot of time and effort, plus electricity. Very happy with this oven.
Date published: 2016-07-05
Rated 5 out of 5 by from Xmas cooking We are remodeling our kitchen & decided to put in a wall oven to go with our stove. I haven't used it yet as I don't want to use the new appliances until the kitchen is finished, but I can tell that it has some really good features, it has a lot of cooking room, looks great with the other appliances & I am going to really have a good time at Xmas cooking cookies, cakes & the big turkey. I can't wait to try all the features.
Date published: 2015-08-14
Rated 4 out of 5 by from Great oven with many features! I haven't had this unit very long so only used a few times but have been very pleased with my experience so far! IT's a sharp looking oven with so many neat features. I like the indicator tones allowing me to hear when oven is pre-heated, etc. Another feature I have not had with previous ovens that I will really like is the 5 position rack. Overall I'm very happy with my purchase of this oven!
Date published: 2015-07-06
Rated 5 out of 5 by from Great oven This oven is wonderful. It is also beautiful. The inside is a beautiful blue and I love how it plays a song instead of an annoying buzzer when the timer goes off. It cooks everything great and I love the convection capabilities, which I am just learning how to use. Very glad I chose this product.
Date published: 2014-10-22
Rated 5 out of 5 by from Electric Wall Oven My wife loves to cook and baking is her specialty. This oven has met her expectaions (which were high). It looks great, the controls are easy to understand. It heats up quickly and holds a consistent temp. needed for baking.. Great device.
Date published: 2014-07-22
Rated 1 out of 5 by from FAN NOISE Bought this unit and put it in the open wall space, turned it on and knew immediately that I had made a huge mistake in buying this oven. My wife and I looked at each other and our mouths wide open. The fan noise is almost like a practical joke its so loud. Not only can you not hear yourself think, you have to listen to this noise for over 55 minutes after you take something out of the oven. LG did not do their homework when it came to this product. This thing needs a whole remake. Do not waste your hard earned money!!!
Date published: 2014-04-21
  • 2016-07-29T08:31CST
  • bvseo_cps, prod_bvrr, vn_cps_3.3.0
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_9
  • loc_en_US, sid_MD00001189, PRD, sort_mostRecent
  • clientName_LG
  • bvseo_sdk, java_sdk, bvseo-2.3.0.0
  • CLOUD, getReviews, 449ms
  • REVIEWS, PRODUCT

We're here to support you with our product.

View LWS3010ST Product Support

Contact us for any support inquiries.

ASK & ANSWER

Ask your questions. Share your answers.
Please first review the detailed product information and help guides in the Product Support section for this product prior to posting a question.

I bought this display model from the store. I don't know how to work the features. Would you please email me the owners manual.

Asked by: StevenJanet
We appreciate your interest in this wall oven. A copy of the owner’s manual can be downloaded from our website at http://www.lg.com/us/support-product/lg-LWS3010ST#manuals.
Answered by: NeilE
Date published: 2016-06-22

Why am I blessed with this horrible blue interior

Asked by: Texas girl
We regret your displeasure with the color of the interior of this oven. This blue enamel finish is the standard finish for most, if not all, of our ovens.
Answered by: NeilE
Date published: 2016-03-11

When will LG come out with a black stainless steel 30" wall oven?

Asked by: 23jacq
We currently do not have any information on when or if LG is going to come out with a Black Stainless Steel 30" Wall Oven. You can check the LG Site at http://www.lg.com/us/press-release or at http://www.lgnewsroom.com/category/news/ for any forthcoming official announcements on product releases...^IFV
Answered by: LGJoel
Date published: 2016-02-22

How do you change the clock from military time to standard time?

Asked by: Lisa4361
Touch the SETUP button on the display panel. Press the #7 for SETTING THE CLOCK TIME. Touch 12HR for a Standard 12-hour clock. Press the OK button, and then BACK. Next, enter the current time and press the OK button to store.
Answered by: NeilE
Date published: 2015-05-18

do you have a wall mount bracket for this oven

mod# lws3081st
Asked by: kitchenredo
I apologize, but no; there is no mounting bracket that is required for the installation of this range. All that is provided with this unit is the Metal Bottom Trim Kit and various screws needed for the process.
Answered by: NeilE
Date published: 2014-04-04

can this go under a gas Cooktop that is 36 inches tall 35 to the countertop

Asked by: tugger
We appreciate your interest in this Single Wall Oven. This model is designed for a total height of 29 5/16”. Beyond this, it will depend upon how deep the cooktop rests into the cabinet.
Answered by: NeilE
Date published: 2013-08-22

what is the amp for lg lws3010st single oven

Asked by: arturo
A single wall oven can consume up to 4,100 Watts at 240 VAC. A 30 Amp circuit breaker with wire gauge of at least #10 AWG must be used. A double wall oven can consume up to 7,800 Watts at 240 VAC. A 40 Amp circuit breaker with wire gauge of #8 AWG must be used.
Answered by: NeilE
Date published: 2012-12-05

CAN AN 30" OVEN LWS3010ST MOUNT UNDER COUNTER AND INSTALL A COOK TOP LCG3611ST OVER IT?

Asked by: HOWARDS
LG Electronics is a company that thrives on innovation. Our products and technologies enhance lives and introduce our customers to a whole new world of creative designs. We are committed to finding new ways to make your life better and easier-through simple user interfaces, stylish designs and intelligent, state-of-the-art technology. Each unit has special design features and specifications. You may visit our website at www.lg.com to review all information on all of our newest models.
Answered by: LGJoel
Date published: 2016-04-28
