7.3 cu. ft. Ultra Large Capacity Dryer with Front Control Design and SteamFresh™ Cycle

  • DLGY1202V

  • Graphite Steel

Key Features

  • Ultra Large 7.3 cu. ft. Capacity
  • Front Control Design
  • SteamFresh™ Cycle
  • Smart Diagnosis™
AVAILABLE COLORS:
Big time saver

Big time saver

Do laundry a little less often. With 7.3 cubic feet of capacity, this dryer handles really large loads. Saving you time and energy.

A revolutionary spin on laundry.

A revolutionary spin on laundry.

LG puts a modern design spin on the traditional top load laundry pair. By moving the control panel from the back to the front, the buttons and LED display are easier to read and use. This simple change makes for a more intuitive and functional design and a look that is unlike anything you’ve ever seen.

The quick fix

The quick fix

Late for the party and no time to iron your favorite outfit? The SteamFresh™ Cycle refreshes, and reduces wrinkles in up to five garments at a time with one 20-minute dryer cycle.

Get wise

Get wise

If you ever experience an issue with your LG dryer, you don't have to worry. The SmartDiagnosis™ feature helps the service center diagnose problems over the phone, or with a simple app on your smart phone, helping you minimize costly, inconvenient service calls.

Really dry clothes

Really dry clothes

What’s worse than pulling clothes out of the dryer and finding they’re still damp? Our Sensor Dry system measures the moisture levels during the cycle and automatically adjusts the drying time, to help ensure you get dry laundry every time.

SUMMARY
Dryer Type Gas
SteamDryer™ Yes
CAPACITY
Capacity 7.3 cu. ft.
APPEARANCE
Design Look Front Control
Front Electronic Control Panel with LED Display Yes
DRYING PROGRAMS
Programs (Sensor Dry) Cotton/Normal, Perm. Press/Casual, Heavy Duty, Small Load, Bulky/Bedding, Anti-Bacterial, Towels, Delicates, SteamFresh™, Wrinkle Free
Programs (Manual Dry) Speed Dry, Air Dry
No. of Options 7
Options More Time, Less Time, Wrinkle Care, Custom Program, Child Lock, Damp Dry Signal, End of Cycle Signal
Temperature Settings High, Medium High, Medium, Low, Ultra Low
Drying Levels Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
Manual Dry Times 60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time
FABRIC CARE FEATURES
SteamFresh™ Cycle Yes
Wrinkle Free Cycle Yes
Sensor Dry Yes
Precise Temperature Control with Variable Heater Yes
CONVENIENCE FEATURES
LoDecibel™ Quiet Operation Yes
SmartDiagnosis™ Yes
FlowSense™ Duct Clogging Indicator Yes
Anti-Bacterial Cycle Yes
Wrinkle Care Option Yes
Remaining Time Display/Status Indicator(s) Yes
End of Cycle Signal Yes
Child Lock Yes
3 Minute Installation Check Yes
Drum Light Yes
Venting Option 3 Way Venting
Leveling Legs 4 Adjustable Legs
Reversible Door Yes
MATERIALS AND FINISHES
Aluminized Alloy Steel Drum Yes
Top Plate Plastic
Cabinet Painted Steel
Control Panel Plastic
Chrome Edged Diamond Glass Door Yes
Available Colors White (W), Graphite Steel (V)
POWER SOURCE
Ratings CSA Listed
Electrical Requirements 120V, 15 Amps
Type Gas
OPTIONS
LP Conversion Kit 4948EL4002B
Side Venting Kit 3911EZ9131X
DIMENSIONS
Product (WxHxD) 27" x 40 5/32" x 28 3/8" (50 1/4" D with door open)
Carton (WxHxD) 29 1/2" x 43 7/10" x 31 1/4"
Weight (Product/Carton) 125.4 lbs. / 143.3 lbs.
WARRANTY/UPC
Limited Warranty 1 Year Parts and Labor
UPC 048231 013383

What People Are Saying

Rated 4.8 out of 5 by 61 reviewers.
Rated 5 out of 5 by Love Everything About This Dryer Purchased about a month ago - can't say enough good things about the dryer - beautiful looking and performing great. Clothes come out perfect, love the wrinkle free steam setting too. Couldn't be happier with my purchase. June 9, 2015
Rated 5 out of 5 by Newmom14 I bought this dryer along with the matching 4.3 cu. ft. washer in white and I absolutely love it. I mostly use the regular cycle and the towel cycle. My towels always come out completely dry, as do my clothes. If I have one negative thing to say, it's that when I do my sons clothing (he's 7+ months old and I do his clothes separate) they don't always dry completely. I think it has to do with the fact that each drying cycle is "Sensor Dry" and if the machine doesn't sense any moisture it will shorten the drying cycle. His loads aren't very big either so that could also be a factor. I haven't used the "wrinkle free" setting yet, but I can't wait to try it out! Also, I love that the controls are in the front of the dryer (and washer) instead of on the back. Much better to reach for us short people. :-P July 13, 2015
Rated 5 out of 5 by Perfect dryer! Everything about this appliance is perfect. I love how it dries your clothes, NOT cook them! And the steam feature is great when I just need to de-wrinkle an item. On top of that, IF a dryer can be pretty, this one is! July 7, 2015
Rated 5 out of 5 by I love my new dryer! What a great dryer! It's quiet, dries more quickly than my old gas dryer, and the front load makes it easy to get everything in and out. Many cycles to choose from, and I love the sleek design and color. Decent value for the quality. I highly recommend it. April 28, 2015
Rated 5 out of 5 by Excellent product We are very pleased with this product--high quality, quiet, easy to use, great features. Our gas company mailed us a check for $200.00 since we bought a high efficiency gas drier. April 22, 2015
Rated 5 out of 5 by GREAT FEATURES I just got this dryer a few months ago to replace a 23-year-old one and I was a bit intimidated with all of the features on it compared to my old dryer. There was a bit of a learning curve for me (so many options to select from!) but I now find it's quite easy to customize the various settings to make my clothes come out of dryer in much better shape than they had with the old dryer! The only thing I wish was different about this dryer was the angle at which the door opens. The door opens to the side, rather than downward (as my old dryer had). If I drop an article of dried clothing while taking it out of this dryer it lands on the floor rather than on the door - would prefer to have that door open downward and act as a "catch-safe" for any newly-laundered item I might drop. Other than that, I am quite please with the dryer and am hoping it will last as long as my last one had! March 3, 2015
Rated 1 out of 5 by great performance gas bill has been cut in half drying time extremely short clothes come out with minimum wrinkles March 3, 2015
Rated 5 out of 5 by What a Super Dryer The dryer is very attractive, functional and delivers great results. It has a host of handy and convenient features that make drying clothes a breeze. Highly recommended for all February 26, 2015
  • 2015-08-27T13:35:40.378-05:00
  • bvseo_lps, prod_bvrr, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasreviews, tv_61, tr_61
  • loc_en_US, sid_MD05036640, prod, sort_default
2 3 Next>>

We're here to support you with our product.

Contact us for any purchasing inquiries.

Product Support

ASK & ANSWER

Ask your questions. Share your answers.

14 Questions & 17 Answers

Ask Your Questions, Share Your Answers

Ask your questions. Share your answers.



« Back


Has staff answer
Has expert answer

2 answers

Matching Pedestal availability

In the manual, "For a garage installation, you will need to place the dryer at least 18 inches (46 cm) above the floor. If using a pedestal, you will need 18 inches (46 cm) to the bottom of the dryer."

Can you tell me if there is a matching LG Pedestal available for this model? Will my old LG pedestal work?
Category: I own this product
Interested in: How To use
2 years, 1 month ago
User Name:
SamD
Thousand Oaks, CA, USA

Please wait while more information about SamD is loaded.
Additional information about SamD could not be loaded.
0points
0out of 0found this question helpful.
HelpfulNot Helpful

Answers

Answer:
Yes and yes; the pedestals appear to be basically the same. I want to get the pedestal too but since my washer is a top load it might look kind of “wonky”.
Gender: female
1 year, 8 months ago
User Name:
Neet
Michigan, USA

Please wait while more information about Neet is loaded.
Additional information about Neet could not be loaded.
-1point
0out of 1found this answer helpful.
HelpfulNot Helpful

Answer:
We appreciate your interest in this dryer. There has not been a new pedestal designed for this dryer. The older model should be able to work, depending upon the model number. For this model, we would recommend the WDP4V pedestal.
2 years, 1 month ago
User Name:
NeilE

Please wait while more information about NeilE is loaded.
Additional information about NeilE could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful
Has staff answer
Has expert answer

2 answers

Is there a dryer rack that can be purchased, or other accessories?

DLGY1202V
Just purchased, looking forward to delivery. Bought the washer last month. Love it!!
Category: I own this product
1 year, 11 months ago
User Name:
TLBM
Granite Bay, CA, USA

Please wait while more information about TLBM is loaded.
Additional information about TLBM could not be loaded.
-1point
0out of 1found this question helpful.
HelpfulNot Helpful

Answers

Answer:
Yes, there is a dryer rack available; I didn’t purchase it because I had one with a previous dryer and rarely used it.
Gender: female
1 year, 8 months ago
User Name:
Neet
Michigan, USA

Please wait while more information about Neet is loaded.
Additional information about Neet could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful

Answer:
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/conte.... The part number for this drying rack is 3750EL0001C.
1 year, 11 months ago
User Name:
NeilE

Please wait while more information about NeilE is loaded.
Additional information about NeilE could not be loaded.
+1point
1out of 1found this answer helpful.
HelpfulNot Helpful
Has staff answer
Has expert answer

2 answers

Steam fresh setting shooting water

I tried out the steam fresh setting on dryer, it didn't seem to spray steam as it just shot water out into the tub and clothes came out damp after going in dry. Is this how it is suppose to work or is it suppose to spray steam?
Category: I own this product
Interested in: Troubleshooting
1 year, 6 months ago
User Name:
Farmer330xi

Please wait while more information about Farmer330xi is loaded.
Additional information about Farmer330xi could not be loaded.
0points
0out of 0found this question helpful.
HelpfulNot Helpful

Answers

Answer:
Yes, it is a freshener not designed to dry clean. You need to allow time for these items to air dry. I have used this myself and it works wonderfully. I think the steam is generated from the heat of the dryer and the water that is applied. I did not observe the process but this is my best guess. I really like this feature for freshening up my husband's suits and my wool coat. I live a really long way from a dry cleaners.
Gender: female
1 year, 4 months ago
User Name:
Candace60
Irons, MI 49644, USA

Please wait while more information about Candace60 is loaded.
Additional information about Candace60 could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful

Answer:
It is normal for the SteamFresh cycle to leave clothing damp. Moisture is expected to remain in the fabrics to make it easier to iron.
1 year, 6 months ago
User Name:
NeilE

Please wait while more information about NeilE is loaded.
Additional information about NeilE could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful
Model DLGY1202V

Is there a product to buff out these scratches?
Category: I own this product
Interested in: Troubleshooting
1 year, 6 months ago
User Name:
DiBeck
Mequon, WI, USA

Please wait while more information about DiBeck is loaded.
Additional information about DiBeck could not be loaded.
0points
0out of 0found this question helpful.
HelpfulNot Helpful

Answers

Answer:
If they are not too deep and it is in the metal part the same product you would use on a car will do the trick, if it is in the plastic part then you would need a product designed for plastic......I think they have a product for eye glass lenses that may work.
Gender: female
1 year, 4 months ago
User Name:
Candace60
Irons, MI 49644, USA

Please wait while more information about Candace60 is loaded.
Additional information about Candace60 could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful

Answer:
We regret the inconvenience you have experienced with this gas dryer. Unfortunately, there are no products available that we might recommend for this purpose.
1 year, 5 months ago
User Name:
NeilE

Please wait while more information about NeilE is loaded.
Additional information about NeilE could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful
Has staff answer
Has expert answer

2 answers

How do we keep dryer door from closing?

What is the trick or setting to keep the dryer door from closing? The dryer was just delivered today and the door seems to be on immediate auto-close mode or something. We need it to stay open for at least long enough to put the clothes in!
Category: I own this product
Interested in: Troubleshooting
1 year ago
User Name:
LeslieRS
CA

Please wait while more information about LeslieRS is loaded.
Additional information about LeslieRS could not be loaded.
0points
0out of 0found this question helpful.
HelpfulNot Helpful

Answers

Answer:
The only thing I have found is to somehow prop it open. I happen to have a clothes sorter next to mine and the hooks that hold the bags on do a wonderful job. Probably not what you wanted to hear, but it is one solution. Good luck!
Gender: female
7 months ago
User Name:
adopt
Lake Elsinore, California, USA

Please wait while more information about adopt is loaded.
Additional information about adopt could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful

Answer:
We regret the inconvenience you have experienced with this dryer. This unit is not designed with a motorized door, nor with any specific feature to automatically close the door. As such, there is no mechanism to keep the door from closing.
10 months ago
User Name:
NeilE

Please wait while more information about NeilE is loaded.
Additional information about NeilE could not be loaded.
0points
0out of 0found this answer helpful.
HelpfulNot Helpful
