- 像素間距:1.25 mm
- 亮度:600 nit
- 訊號偵測的狀態指示器
- 正向式操作
- 易於處理的輕型機架
- 兼容 LG 軟件解決方案
所有規格
ELECTRICAL SPECIFICATIONS
Power Consumption (W/㎡, Max.)
600
Frame Rate (Hz)
50 / 60
Power Consumption (W/Cabinet, Avg.)
40
Power Consumption (W/Cabinet, Max.)
120
Power Supply (V)
AC 100-240 V (50-60 Hz)
Refresh Rate (Hz)
3,840
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness)
100,000
IP rating Front
IP5X
IP rating Rear
IP5X
Operating Humidity
10-80% RH
Operating Temperature(℃)
-20 to +40
OPTICAL SPECIFICATIONS
Visual Viewing Angle (Horizontal)
160
Brightness Uniformity(%)
97%
Max. Brightness (After Calibration)
600
Color Temperature (K)
3,200-9,300
Color Uniformity
±0.003 Cx,Cy
Contrast Ratio
5,000 : 1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Visual Viewing Angle (Vertical)
140
PHYSICAL PARAMETERS
Pixel Configuration
3 in 1 SMD
Cabinet Dimensions (W x H x D, mm)
600 × 337.5 × 56
Cabinet material
Die Casting Aluminum
Cabinet Resolution (WxH)
480 × 270
Cabinet Surface Area (㎡)
0.203
Flatness of Cabinet (mm)
0.5
Module Dimensions(WxH,mm)
150 × 337.5
Module Resolution (WxH)
120 × 270
No. of Modules per Cabinet (WxH)
4 × 1
Physical Pixel Density (pixels/㎡)
640,000
Pixel Pitch (mm)
1.250
Service access
Front
Weight per Cabinet (kg/unit)
6.0
Weight per Module (kg)
0.50
Weight per Square Meter (kg/㎡)
30.0
