Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.56
Module Resolution (WxH)
192x216
Module Dimensions(WxH,mm)
300x337.5x13
Weight per Module (kg)
0.95
No. of Modules per Cabinet (WxH)
4 x 2
Cabinet Resolution (WxH)
768x432
Cabinet Dimensions (W x H x D, mm)
1200x675x72
Cabinet Surface Area (㎡)
0.810
Weight per Cabinet (kg/unit)
23.0
Weight per Square Meter (kg/㎡)
28.0
Physical Pixel Density (pixels/㎡)
409,600
Flatness of Cabinet (mm)
±0.3
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
600
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
150
Brightness Uniformity(%)
97
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14
Power Consumption (W/Cabinet, Max.)
428
Power Consumption (W/Cabinet, Avg.)
182
Power Consumption (W/㎡, Max.)
530
Heat Dissipation (BTU/h/Cabinet, Max.)
1,460
Heat Dissipation (BTU/h/Cabinet, Avg.)
621
Heat Dissipation (BTU/h/㎡, Max.)
1,808
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-20℃ to +40℃
Operating Humidity
10~80%RH
IP rating Front
IP50
IP rating Rear
IP50
Certification
CE, FCC, cTUVus, CB, KC, CCC
Environment
RoHS, REACH
Controller
CVBA
