Pixel Pitch
13.7±0.2mm (14)
LED Type
R, G, B 3in1 Color Package (SMD2020)
Resolution
48 x 36
Pixels per Film
1,728
Physical Pixel Density(pixels/㎡)
5,102
Brightness
Typ.4,000nit
Contrast Ratio
≥ 100,000:1
Luminance Uniformity
≥ 70%
Chromaticity Uniformity
Δu’v’≤0.015
Viewing Angle (H x V)
120 x 120
Life Time (Brightness 50%)
50,000 Hrs
Daily Usage
24h / 7days
Warranty
2 year
Transparency
Typ 53%
Operating Temperature
0℃ ~ 45℃ (Instaliling at indoor glass)
Curved Installation
2,000 R (Concave and Convex available on Glass)
Film Trimming
Yes (horizontal direction according to Bezel only)
Color Processing
(9bit) 500/500/500 Level ( R, G, B)
Colors
125,000,000 Colors
Color Chromaticity
Cx: 0.25±0.03, Cy : 0.33±0.03
Dimension (W x H x D)
655 x 492 x 2.9mm
(with front & back protection film)
Weight
1kg
Power Consumption
75W per Film
Interface
Input : RGMII
Output : Differential Serial
Dimension (W x H x D)
69.4 x 492 x 25mm
Weight
0.4Kg
Power Consumption
75W(Transparent panel 1EA + First(1EA) & Common(1EA) Bezel kit)
Accessory
DC Jack Connection cable(1100mm) 1ea, DC Jack Connection cable(240mm) 1ea Screw 2 type, Gasket Rubber 3 type, Cable hole cover 1 type, ESG, Regulation book, Warranty Card
Interface
Input : Differential Serial
Output : Differential Serial
Dimension (W x H x D)
51.4 x 492 x 25mm
Weight
0.3Kg
Power Consumption
75W per Film
Accessory
DC Jack Connection cable(240mm) 2ea, Screw 2 type, Gasket Rubber 2 type, Cable hole cover 2 type, ESG, Regulation book, Warranty Card
Resolution
960x540 (1/4 FHD)
Interface
Input : LVDS
Output : RJ45 x4EA
Maximum Transmission Length
100m (Cable type: CAT5E, CAT6)
Dimension (W x H x D)
293 x 188.7 x 37mm
Weight
1.5Kg
Temperature Sensor
Yes
Power Consumption
20 W
Accessory
Power cord, LVDS MCX cable, ESG, Regulation book, Warranty Card
Video - Max. Input Resolution
DP : 1920x1080@60Hz
HDMI : 1920x1080@60Hz
DVI-D : 1920x1080@60Hz
Interface - Digital (w/ HDCP) - HDMI
Input : 1EA
Interface - Digital (w/ HDCP) - DP
Input : 1EA
Output : 1EA
Interface - Digital (w/ HDCP) - DVI-D
Input : 1EA
Interface - Comm. Port - RS-232C
Input : 1EA (Phone Jack Type)
Output : 1EA (Phone Jack Type)
Interface - Comm. Port - RJ-45
Input : 1EA (without LED indicator)
Output : 1EA (without LED indicator)
Interface - Comm. Port - IR Receiver (w/ Light Sensor)
1EA (Phone Jack Type) : Used for installation
Interface - USB3.0
1EA
Interface - LVDS
Output : 1EA
Dimension (W x H x D mm)
293 x193.3 x 40.1mm
Weight (Head, Kg)
1.6kg
Temperature Sensor
Yes
Light Sensor
Yes
Source Selection
HDMI, DVI-D, DP
TPC (Temporal Peak luminance Control)
Yes
Motion Eye Care
Yes
Power Consumption
17W
CMS S/W
Yes (2.9)
Signage365care
Yes (2.7)
Accessory
Power cord, IR+Bright Sensor (1.5m), 4P Phone-to-RS232C Gender, ESG, Regulation book , Warranty Card
Model No.
ACC-LATP1
Dimension (W x H x D)
183*86*28mm
Weight
769g
Input
100~240V, 50~60Hz
Output
19.5V/10.8A (210W)
Color
White
DC output cable
14AWG, 1.5m
Type
L Type
Accessory
Power Cord, Regulation Book
Resolution
480x270 (1/16 FHD)
Maximum Transmission Length
100m (Cable type : CAT5E, CAT6)
Dimension (W x H x D)
333 x186.8 x 40.1mm
Weight
1.8.2Kg
Video - Max. Input Resolution
HDMI : 1920x1080@60Hz
Interface - Digital (w/ HDCP) - HDMI
Input : 1EA
Interface - Comm. Port - RS-232C
Input : 1EA (3.5⌀ headphone jack type)
Output : 1EA (3.5⌀ headphone jack type)
Interface - Comm. Port - RJ-45
Input : 1EA
Output : 2EA (1EA to connect film with LED Indicator)
Interface - Comm. Port - IR Receiver (w/ Light Sensor)
1EA (Phone Jack Type) : Used for installation
Interface - USB3.0
1EA
Interface - LVDS
-
Temperature Sensor
Yes
Light Sensor
Yes
TPC (Temporal Peak luminance Control)
Yes
Motion Eye Care
Yes
Power Consumption
30
CMS S/W
Yes (3.0)
Signage365care
Yes (2.7)
Accessory
Power cord, IR+Bright Sensor (1.5m), 4P Phone-to-RS232C Gender, ESG, Regulation book Warranty Card
