55” SUPER-NARROW 3.5mm BEZEL PREMIUM DISPLAY LV77A
Key Features
Temperature Sensor
Yes
Cooling FAN
Yes
Tile Mode
Yes, Up to 15 x 15
Natural Mode@Tile Mode
Yes
Source Selection
RGB / DVI-D / HDMI / Component / AV / Display Port / USB
Brightness/Contrast/Backlight
Yes
Position/Size
Yes
Language (OSD)
Korean, Chinese(Traditional), Chinese(Simplified), Japanese, German, English, French, Portuguese(Brazil), Portuguese(Europe), Spanish, Italian, Russian, Swedish(Sweden), Finnish(Finland), Norwegian(Norway), Danish(Denmark), Dutch(Netherlands), Cheskey(Czecho), Greek(Greece)
Language (USB Playback)
Korean, Chinese(Traditional), Chinese(Simplified), Japanese, German, English, French, Portuguese(Brazil), Portuguese(Europe), Spanish, Italian, Russian, Swedish(Sweden), Finnish(Finland), Norwegian(Norway), Danish(Denmark), Dutch(Netherlands), Cheskey(Czecho), Greek(Greece)
Language (Manual)
English, French, German, Spanish, Italian, Korean, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Japanese, Turkish, Czech, Taiwanese, Slovak
Language (ESG)
English, German, French, Italian, Spanish, Portugues, Greek, Polish, Czech, Slovak, Korean, Japanese
ISM Method
Normal, Orbiter, inversion, White wash
Advanced
Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction, Digital Noise Reduction, Gamma, Black Level
Time
Clock, On/Off Time, Sleep Timer, Power on Delay, Auto Off, Automatic Standby
Information
Model/Type, S/W Version, Serial Number, IP Address, Mac address, Homepage
Input Label
Yes
Auto Power/Source Memory
Yes
Included
Remote Controller, Power Cable, DP Cable, Manual, IR Receiver, RS-232C Cable,Tiling Guide, Screw
Input
------------------------------------
Digital (HDCP)
HDMI(1), DP(1), DVI(1)
Analog
RGB(1) Shared Component, AV(1)
Audio
AV(1)
External Control
RS232C(1), RJ45(1), External IR(1)
USB
Yes (1)
Output
------------------------------------
Digital (With HDCP)
DP (1) from HDMI/DVI/DP input
Audio
Yes (1)
External Control
RS232C (1)
Operation Temperature
0°C ~ 40°C
Operation Humidity
10% ~80%
Screen Size
55" (54.64" measured diagonal)
Panel Technology
IPS
Aspect Ratio
16 : 9
Native Resolution
1920 x 1080 (FHD)
Brightness
700cd/m2
Contrast Ratio
1,400:1
Dynamic CR
500,000:1
Color gamut
72%
Viewing Angle (H x V)
178 x 178
Color Depth
1.06 Billion
Response Time
12 ms
Surface Treatment
Hard coating (3H), Anti-reflection treatment of the front polarizer (Reflectance: <2%)
Life time
60,000 Hrs
Orientation
Portrait & Landscape
Color
Black
Monitor Dimension (W x H x D)
1213.4mm x 684.2mm x 88.5mm
Weight (head)
23.2kg
VESA Standard Mount Interface
600mm x 400mm
Power Supply
100-240V~, 50/60Hz
Power Type (Adapter or LIPS)
Built-in Power
Power Consumption (Typ.)
230W
Power Consumption (Smart Energy Saving)
130W
Power Consumption (DPM)
0.7W
Power Consumption (Power off)
0.5W
SuperSign-w lite
Yes
SuperSign-c
Yes
Safety
UL / c-UL / CB / TUV / KC
EMC
FCC Class "B" / CE / KCC
ErP / Energy Star
Yes / Yes (Energy Star 6.0)
Max Input Resolution
1920 x 1080@60Hz(RGB, HDMI, DVI-D, Display Port)
Recommended Resolution
1920 x 1080@60Hz(RGB, HDMI, DVI-D, Display Port)
H-Scanning Frequency
30 ~ 83kHz(RGB, HDMI, DVI-D, Display Port)
V-Scanning Frequency
56Hz ~ 75Hz (RGB), 56Hz ~ 60Hz (HDMI, DVI-D, Display Port)
Pixel Frequency
148.5MHz(RGB, HDMI, DVI-D, Display Port)
Sync Compatability
Separate / Digital
Video Input
RGB, HDMI, DVI-D, Display Port, AV, Component
Picture mode
Vivid, Standard, Cinema, Sports, Game
Color temperature
Warm, Medium, Cool
