Case 1
50/60 Hz 220-240 V~
Limit Range of Voltage(Case 1) (V)
198 ~ 264
Case 2
50/60 Hz 220-240 V~
Nominal (kW)
14.10
Nominal (Btu/h)
48100
Sensible Heat (Btu/h)
34804
Nominal (kW)
15.9
Nominal (Btu/h)
54200
H/M/L (W)
110 / 76 / 61
H/M/L (A)
0.95 / 0.69 / 0.56
Type
3D Turbo Fan
Air Flow Rate(H/M/L) (m³/min)
34 / 30 / 28
Type
Brushless DC
Drive
Direct
Output (W)
135
Output (No.)
1
Rows x Columns x FPI
3 x 12 x 21
No.
1
Face Area (m²)
0.50
Net(W x H x D) (mm)
840 x 288 x 840
Shipping(W x H x D) (mm)
922 x 360 x 917
Net (kg)
27
Shipping (kg)
31.5
Color
White
Type
Long life filter
Temperature Control
Microprocessor, Thermostat for cooling and heating
Sound Absorbing / Thermal Insulation Material
Foamed polystrene
Type
R410A/R32
Additional Charging amount (kg(each))
0.49 / 0.41
Control Type
EEV
O.D / I.D (mm(inch))
32 / 25
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
Liquid
Flare
Gas
Flare
Cooling((SH)/H/M/L) (dB(A))
- / 48 / 44 / 42
Heating((SH)/H/M/L) (dB(A))
- / 48 / 44 / 42
Cooling((SH)/H/M/L) (dB(A))
- / 58 / 54 / 53
Heating((SH)/H/M/L) (dB(A))
- / 58 / 54 / 53
Communication Cable(VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Minimium Circuit Amperes (MCA) (A)
2.29
Indoor Fan Motor_Full Load Amperes (FLA) (A)
1.83
Type
Dual Vane
